Side 1/31

Issue Date : August, 2011

TS06

Manual

External USB slim optical drive enclosure with

2.5” SSD/HDD conversion tray

NO.G11214610

Installation and system optimization guide:

The following manual and guides were carefully prepared by the SilverStone

engineering team to help you maximize the potential of your SilverStone product.

Please keep this manual for future reference when upgrading or performing

maintenance on your system. A copy of this manual can also be downloaded

from our website at:

http://www.silverstonetek.com

Specifications

Instruction

Installation procedure (Lenovo)

Installation procedure (Toshiba)

Optical drive installation

P.2

P.3

P.7

P.16

P.27

Features

Enclosure built-in retractable USB 2.0 cable

Interchangeable optical drive slot to 2.5” SATA SSD or HDD

Compatible with 12.7mm slimline SATA optical drive

Improve laptop performance and capacity with extra hard drive

Enclosure Material

Color

Power Requirement

ODD Size Support

ODD Interface Support

Enclosure Interface

Operating System Support

Net Weight

Dimension

Plastic with diamond shape exterior

Black (TS06B), White (TS06W)

5Vdc from USB VBus

12.7mm optical disc drive

13Pin slimline SATA

Built-in retractable USB 2.0 cable

Windows XP, Vista, 7, Mac OS and Linux

150g

140mm x 132mm x 17mm

Tray Material

Color

Drive Size Support

Drive Interface Support

Tray Interface

LED indicator

Net Weight

Dimension

Plastic

Black (TS06B), White (TS06W)

9.5mm thickness 2.5" HDD or SSD

22Pin SATA

13Pin slimline SATA

Green light for power on, Blue light for read/write access

50g

128mmx128mmx13mm

Enclosure Specifications

Conversion tray Specifications

External USB slim optical drive enclosure with

conversion tray

2.5” SSD/HDD

TS06

TREASURE

SERIES

Produkspesifikasjoner

Merke:	SilverStone
Kategori:	Harddisk
Modell:	TS06
Vekt:	50 g
Bredde:	128 mm
Dybde:	128 mm
Høyde:	13 mm
Vertsgrensesnitt:	SATA
Utgangsgrensesnitt:	USB 2.0
Produktfarge:	Sort
Intern:	Nei
Formål:	Laptop
