Advanced 2/4/8 HDMI KVM Switch 1
1-800-284-2131
www.smartavi.com
USER MANUAL
Advanced 2/4/8-Port HDMI KVM Switch
SM-UHN-2S 2-Port Single-Head 4K/60Hz HDMI KVM switch
SM-UHN-2D 2-Port Dual-Head 4K/60Hz HDMI KVM switch
SM-UHN-4S 4-Port Single-Head 4K/60Hz HDMI KVM Switch
SM-UHN-4D 4-Port Dual-Head 4K/60Hz HDMI KVM Switch
SM-UHN-4Q 4-Port Quad-Head 4K/60Hz HDMI KVM Switch
SM-UHN-8S 8-Port Single-Head 4K/60Hz HDMI KVM Switch
SM-UHN series
Advanced 2/4/8 HDMI KVM Switch 2
TECHNICAL SPECIFICATIONS_____________________________________________________________ 3
WHAT’S IN THE BOX?_____________________________________________________________________ 4
SM-UHN FRONT AND REAR_______________________________________________________________ 4
INSTALLATION____________________________________________________________________________ 5-8
LED’s BEHAVIOR__________________________________________________________________________ 11
SYSTEM OPERATION______________________________________________________________________ 12
TROUBLESHOOTING______________________________________________________________________ 12
TECHNICAL SUPPORT_____________________________________________________________________ 12
LIMITED WARRANTY STATEMENT________________________________________________________ 13
Table of content
Advanced 2/4/8 HDMI KVM Switch 3
VIDEO
Format HDMI
Host Interface
SM-UHN-2S (2) HDMI 19-pin (female)
SM-UHN-2D / SM-UHN-4S (4) HDMI 19-pin (female)
SM-UHN-4D / SM-UHN-8S (8) HDMI 19-pin (female)
SM-UHN-4Q (16) HDMI 19-pin (female)
User Console
Interface
SM-UHN-2S / SM-UHN-4S / SM-UHN-8S (1) HDMI 19-pin (female)
SM-UHN-2D / SM-UHN-4D (2) HDMI 19-pin (female)
SM-UHN-4Q (4) HDMI 19-pin (female)
Max Resoluon 3840 x 2160 @ 60Hz
DDC 5 volts p-p (TTL)
Input Equalizaon Automac
Input Cable Length Up to 20 .
Output Cable Length Up to 20 .
AUDIO
Input (2) / (4) / (8) Connector Stereo 3.5mm Female
Output (1) Connector Stereo 3.5mm Female
CONTROL
Front Panel Push Buons with LED indicators
RS232 Via Serial @ 115200 bps
Hot Keys Via Keyboard
POWER
Power Requirements
12V DC, 2A (minimum) power adapter with center-pin posive polarity. Quad head models
require a 12V DC 3A (minimum) power adapter with center-pin posive polarity.
ENVIRONMENT
Operang Temp 32° to 104° F (0° to 40° C)
Storage Temp -4° to 140° F (-20° to 60° C)
Humidity 0-80% RH, non-condensing
OTHER
Emulaon Keyboard, Mouse and Video
Control Front Panel Buons
Technical Specifications
USB
Signal Type USB 2.0, 1.1, and 1.0 w/ internal hub
Type A to B
SM-UHN-2S / SM-UHN-2D (2)
SM-UHN-4S / SM-UHN-4D / SM-UHN-4Q (4)
SM-UHN-8S (8)
User Console Interface (2) USB Type-A for keyboard and mouse connecon only
