1ty and User Manual
SMART RACKGUARD iQ
RF11iQ
8 X REMOTE CONTROLLED
DUAL CIRCUIT PROTECTION
AND FILTRATION
USER MANUAL
thortechnologies.com.au
MODEL: RF11iQ
2 RF11iQ Warranty and User Manual
RF11iQ Warranty & User Manual
Thor Technologies Pty Ltd reserves the right to alter or change the specifications and/or product
as and when deemed necessary to keep in line with the Company policy of ongoing improvement
in research, development and features of the product range.
1. INTRODUCTION
Thank you for choosing the THOR Smart Rack Guard iQ (RF11iQ).
The Smart Rack Guard iQ (RF11iQ) has been designed with industry leading technology of
integration of secure IP based monitoring functions with the ability to communicate via a web
browser or Smartphone application. This remote access will allow users, particularly service
technicians, immediate advice of any high voltage incident or damage affecting the premium-
filtered protector. This manual will explain how to setup and use these features of the product to
ensure integrity and security standards are maintained.
Purpose
Why is there a need to communicate with a filtered surge protector? Today many electrical
appliances have the ability to be turned on or off remotely. In many instances service personnel
can monitor systems and equipment to ensure they are performing correctly. Instant advice of a
problem can save on downtime and reduce associated call outs. Early detection to faults and the
ability to reset equipment remotely can relieve expensive call out costs.
The RF11iQ can alert via email should the product sustain any damage from a power surge or
other high voltage incident. If either of the two separate inbuilt power circuits are affected, an email
will be sent immediately to advise of such an event. At the same time an automated on board
alarm sounds (within the unit), if damage has been sustained and the product needs replacing.
Once the email has alerted a service technician of a problem they can log into the site through a
web browser or mobile application, diagnose and make a decision on what needs to happen next.
The alarm can be turned off remotely by the service technician. The ability to switch off the alarm
may alleviate concern or potential annoyance once the fault has been detected and the need for
an alarm expires.
If connected equipment is not functioning correctly service personnel are able to log in and reset
this equipment. The ability to turn each circuit on or off becomes an invaluable time and cost
saving function.
Conventions
The product programming software will run a web server that serves simple and uncluttered HTML
and/or XML pages to indicate system status. Industry Standard Internet Protocols are used. In
addition the software has inbuilt email functionality.
3RF11iQ Warranty and User Manual
2. OVERVIEW
The RF11iQ has two isolated circuits. One circuit set contains 7 individually controlled Australian
pin outlets while the other circuit set contains a single control for 4 IEC outlets giving a combined
11 outlet configuration. Each circuit has spike and surge protection as well as filtered technology
to ensure safe and clean power is supplied to any connected devices.
Given the nature of rack applications often being in mission critical installations, the design of the
RF11iQ provides an immediate alert that it has reduced or exhausted its protection capacity but
still continues to allow power through. This allows service technicians to work on a replacement
unit while not affecting the site operations
2.1 FEATURES
Current Limits
240VAC Total unit current is 10A Max
NOTE: Each Australian pin outlet (1 – 7) has capacity to supply 10A maximum per outlet; REAR
CIRCUIT 8 – IEC x 4 outlets combined can supply 10A output in total.
Individually controlled switchable circuits
Seven individually controlled Australian pin outlets and a single control for 4 IEC outlets via the
Smartphone App or through the web browser. This allows the user to select outlets to be switched
of when not in use or required remotely as well as controlling individual circuits if a fault condition
is apparent while allowing other sections to still remain operational (Providing the RF11iQ unit is
fully functioning and has not sustained any damage)
NOTE: If a circuit is switched “OFF” via the Smartphone App or the web browser or by Factory
Reset Default condition, if the RF11iQ is powered “OFF” and then “ON” with the power switch or a
natural power outage … ONLY THE OUTLETS THAT WERE SET TO ACTIVE “ON”: before the events
outlined, will; automatically be switched “ON” . To activate the outlets that are “OFF” you must
use the Smartphone App or the web browser to switch the outlets “ON”. The unit MUST be LAN
connected and all the parameters in your browser and server network set correctly… See the
section on setting up the web browser and Smartphone App outlined later in this booklet.
Soft Start
The RF11iQ has an in built ‘Soft Start” feature to allow the unit to be switched on without causing
a major overload of the 10A Circuit Breaker in the unit as may connected devices have a 4 to 7
times greater inrush current then the final current drawn.
