Side 1/16

OPERATING INSTRUCTIONS

LINE ARRAY SPEAKERS

EXTENSION PLATE

(optional)

PROTECTION PAD (optional)

SR-S4L

SR-S4S

SR-EP4

SR-PP4

SR-S4L

SR-S4S

Thank you for purchasing TOA's Line Array Speakers and their associated products.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

TABLE OF CONTENTS

1. SAFETY PRECAUTIONS ............................................................................................ 3

2. GENERAL DESCRIPTION .......................................................................................... 5

3. FEATURES ...................................................................................................................... 5

4. COVERAGE AREA ....................................................................................................... 6

5. DIMENSIONAL DIAGRAM

5.1. Line Array Speaker SR-S4L ......................................................................................... 7

5.2. Line Array Speaker SR-S4S ........................................................................................ 7

6. SINGLE-AMPLIFIER DRIVE AND BI-AMPLIFIER DRIVE ............................... 8

7. INTERNAL WIRING DIAGRAM ................................................................................ 8

8. CHANGING TO HIGH IMPEDANCE ........................................................................ 9

9. JOINING SPEAKERS ................................................................................................. 10

10. ATTACHING THE PROTECTION PAD TO THE SPEAKER EDGE ............. 11

11. CHANGING SINGLE-AMPLIFIER DRIVE

TO BI-AMPLIFIER DRIVE SYSTEM

...................................................................... 12

12. INTERNAL WIRING DIAGRAM

FOR THE BI-AMPLIFIER DRIVE SYSTEM

......................................................... 13

13. DIGITAL PROCESSOR FILTERING

13.1. Single-Amplifier Drive (Factory-Setting) .................................................................... 14

13.2. Bi-Amplifier Drive ...................................................................................................... 14

14. SPECIFICATIONS

14.1. Line Array Speaker SR-S4L, SR-S4S ...................................................................... 15

14.2. Extension Plate SR-EP4 (optional) .......................................................................... 16

14.3. Protection Pad SR-PP4 (optional) ............................................................................ 16

Produkspesifikasjoner

Merke:	Toa
Kategori:	høyttalerstøtte
Modell:	SR-EP4
Vekt:	1100 g
Bredde:	140 mm
Dybde:	2.3 mm
Høyde:	220 mm
Materiale:	Stål
Kompatibilitet:	TOA SR-S4L, SR-S4S
Produktfarge:	Hvit
Skruer inkludert:	Ja
Antall medfølgende produkter:	2 stykker
