Side 1/16

Owner’s Manual

Warranty

Registration:

chance to win a FREE Tripp Lite

product—www.tripplite.com/warranty

Remote Control

for Sine Wave

Inverter/Charger

Model: APSRMSW

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

Español 5

Français 9

Ðóññêèé 13

201009089.indb 1 1/6/2011 12:32:29 PM

2 3

Overview

Product Features

The APSRMSW Remote Control is designed for use with Tripp Lite Sine Wave DC-to-

AC Inverter/Chargers (APS1012SW / APS2012SW / APSX1012SW / APSX2012SW).

It allows the user to power the Inverter/Charger ON and OFF and monitor inverter

and battery status from up to 32 ft. away.

Note: This manual serves as a quick reference guide to the remote and its

functions. The remote acts as a mirror of the LEDs on the Inverter/Charger, and you

should therefore reference the manual provided with your Inverter/Charger for a

more detailed description of the LEDs.

DC Mode Inverter: This LED illuminates to indicate that the system is working in

inverter mode (supplying power from battery).

Note: The LED will ﬂash when inverter is in search mode.

AC Mode Charger: The LED ﬂashes during the charging process and remains

illuminated once the battery is fully charged.

Inverter Condition: When the inverter temperature exceeds the default setting,

this LED will illuminate and the inverter will shut down automatically. After the

temperature returns to normal, depress the Power ON/OFF button to restart.

Battery Limits: This LED illuminates when the battery charge is too low or too

high.

Battery Voltage LED Bar: These LEDs show the remaining battery capacity.

Power ON/OFF Button: Press to power the Inverter/Charger ON or OFF.

Communication Port (RJ45): Receives data from Inverter/Charger via

Communication Cable.

201009089.indb 2 1/6/2011 12:32:38 PM

3.68 in. (93.5 mm)

1.875 in. (47.6 mm)

Accessories

•MountingScrews

•PlasticConicalAnchors

Installation Dimensions

Note: The APSRMSW has a depth of .84 in. (21.3 mm). Please consider before

installation.

Product Features continued

Communication Cable (32 ft.): Connects APSRMSW to Inverter/Charger via an

RJ45 connection.

Mounting Holes: Allow APSRMSW to be mounted on a ﬁxed, ﬂat surface.

201009089.indb 3 1/6/2011 12:32:50 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	kontroll
Modell:	APSRMSW
Vekt:	450 g
Kompatibilitet:	Tripp Lite APS1012SW, APS2012SW, APSX1012SW, APSX2012SW
Dimensjoner (B x D x H):	48 x 66.1 x 98 mm
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Antall AC outlets:	- AC-utganger
