Secure KVM Switches, NIAP

Protection Prole Version 4.0

DisplayPort Models:

B002-DP1AC2-N4, B002-DP2AC2-N4, B002-DP1AC4-N4,

B002-DP2AC4-N4, B002-DP1AC8-N4

HDMI Models:

B002-H1AC2-N4, B002-H2AC2-N4, B002-H1AC4-N4, B002-H2AC4-N4

DP to HDMI Models:

B002-HD1AC2-N4, B002-HD2AC2-N4, B002-HD1AC4-N4,

B002-HD2AC4-N4

DVI:

B002-DV1AC2-N4, B002-DV2AC2-N4, B002-DV1AC4-N4,

B002-DV2AC4-N4, B002-DV1AC8-N4

TrippLite.Eaton.com/support

Owner’s Manual

Español 17

Français 33

Deutsch 49

Italiano 65

Package Includes ............................................................................... 3

Optional Accessories ......................................................................... 3

System Requirements ....................................................................... 4

Features .............................................................................................. 4

Important Safety Instructions ......................................................... 6

Installation ......................................................................................... 8

KVM LEDs .......................................................................................... 10

Port-Selection LEDs .................................................................................... 10

Push-Button LEDs ....................................................................................... 10

Port-Selection and Push-Button LEDs ................................................... 10

Console Video Port LED ............................................................................ 10

Console CAC Port LED ............................................................................... 10

Miscellaneous KVM Functionality .................................................. 11

Disabling CAC Functionality ...................................................................... 11

Enabling CAC Functionality ....................................................................... 11

 CACPortConguration .............................................................................. 11

AUDITING: Dumping the Event Log ........................................................ 13

RESET: Restore Factory Defaults ............................................................. 14

Power Up Self-Test ..................................................................................... 15

Warranty ........................................................................................... 16

Table of Contents

• B002-Series Secure KVM Switch

• 12V 3A External Power Supply*

• Owner’s Manual

*Includes NEMA 1-15P (North America), CEE 7/16 Schuko (Europe), BS 1363 (UK)

and AS/NZS 3112 (Australia) plugs.

• P312-Series 3.5 mm Stereo Audio Cables

• P569-XXX-CERT Premium High-Speed HDMI Cables

• P782-XXX-HA HDMI/USB KVM Cable Kit

• P782-XXX-DH HDMI/DVI/USB KVM Cable Kit

• P783-Series DisplayPort KVM Cable Kit

• P580-Series DisplayPort Cables

• U022-Series USB 2.0 A/B Device Cables

*XXX refers to length (e.g. 006 = 6 ft., 010 = 10 ft., and so on)

Package Includes

Optional Accessories

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Videokonferansesystem
Modell:	B002-DP1AC8-N4
Innebygd skjerm:	Nei
Vekt:	2860 g
Bredde:	317 mm
Dybde:	169 mm
Høyde:	43 mm
Strømkilde:	DC
LED-indikatorer:	Ja
Bruksanvisning:	Ja
USB-kontakttype:	USB Type-A, USB Type-B
Maksimal oppløsning:	3840 x 2160 piksler
Opprinnelsesland:	USA
Pakkevekt:	2720 g
Sertifisering:	CE; UKCA; cUL, NOM (Mexico), NIAP PP4.0; RoHS; CE (Europe); UKCA; FCC (USA)
HDCP:	Ja
Antall DisplayPorts:	9
Antall brukere:	1 bruker(e)
Utgangsstrøm:	12 V
DisplayPort-versjon:	1.2
AC-inngangsfrekvens:	50 - 60 Hz
Antall datamaskiner:	8
Kabellengde:	1.5 m
Produktfarge:	Sort
HD-type:	4K Ultra HD
Pakkedybde:	406.4 mm
Pakkehøyde:	101.6 mm
Pakkebredde:	279.4 mm
Kabler inkludert:	DC
Pakketype:	Boks
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Lagringsrelativ fuktighet:	0 - 80
Bærekraftsertifikater:	RoHS, Federal Communications Commission (FCC), UKCA, CE
Harmonisert system (HS)-kode:	8471.80.4000
Kroppsmateriale:	Metall
Ekstern strømadapter:	Ja
DC-inngangskontakt:	Ja
Støttede Windows operativsystemer:	Ja
Antall USB 2.0 Type-B-porter:	16
Relativ luftfuktighet under drift (H-H):	0 - 80
Rack-montering:	Nei
Støttede Mac operativsystemer:	Ja
Støttede Linux operativsystemer:	Ja
Masterkassens (ytterkassens) bruttovekt:	20410 g
Masterkassens (ytterkassens) lengde:	635 mm
Produkter per masterkasse (ytterkasse):	8 stykker
Masterkassens (ytterkassens) bredde:	482.6 mm
Masterkassens (ytterkassens) høyde:	482.6 mm
Innput-strøm:	1.3 A
Video tilkoblingstype:	DisplayPort
Tastatur tilkoblingstype:	USB
Mus tilkoblingstype:	USB
Konsoll porter:	3.5mm headphone, DisplayPort, USB A
Antall konsoll USB porter:	3
Trykk på knapp:	Ja
