Side 1/12

Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

High Speed USB 2.0

Over Cat5 Extender Kit

Model: B203-101

Package Contents 2

Product Features 2

Optional Accessories 2

Installation Instructions 2

USB LAN Extender Software 3

Warranty & Warranty Registration 4

Español 5

Français 9

Warranty

Registration:

chance to win a FREE Tripp Lite

product—www.tripplite.com/warranty

201201175-93-3116.indb 1 1/20/2012 11:39:55 AM

Package Contents

Product Features

• B203-101 local unit

• B203-101 remote unit

• 1-ft. USB A/B Cable

• External power supply (Input: 100-240V, 50/60Hz, 0.5A Ouput: 5V, 2A)

• Driver CD

• Owner’s Manual

• Locate a high speed USB 2.0 device up to 328 ft. (100 m) from a computer over

a single Cat5e/6 cable

• Supports high speed data transfer rates up to 480Mbps

• Backwards compatible with USB 1.1

• Compatible with Windows XP and later

Optional Accessories

• U022-Series High Speed USB 2.0 Gold A/B Device Cables

• N001-Series Cat5e Snagless Patch Cables

• N002-Series Cat5e Patch Cables

• N201-Series Cat6 Snagless Patch Cables

Installation Instructions

Note: Test to make sure that the entire installation works properly before pulling

cables through ceilings or walls.

1. Before connecting the B203-101 local unit to the computer, locate the driver le

on the included CD and double-click on it to start the installation process.

2. Follow the installation prompts, choosing to “proceed anyway” when prompted

if the driver is from a trusted source. At the end of the installation, you will be

prompted to restart the computer. Click yes to proceed.

201201175-93-3116.indb 2 1/20/2012 11:39:55 AM

3. After the computer has restarted, connect the B203-101 local unit to an

available USB 2.0 port on the computer using the included USB A/B cable.

Upon connecting the local unit, the red power LED will illuminate, and the driver

will nish installing. Note: USB LAN Extender software will be installed on your

computer, with a Launch USB 2.0 Extender shortcut icon placed on your computer

desktop, and a USB 2.0 Extender icon displayed in the lower-right corner of your

computer screen. (See the USB LAN Extender Software section below for details.)

4. Connect the RJ45 ports on the local and remote units using Cat5e/6 cabling.

5. Connect the external power supply to the remote unit, and plug it into a Tripp Lite

Surge Suppressor, Power Distribution Unit (PDU), or Uninterruptible Power Supply

(UPS). The red power LED will illuminate. In addition, the USB LAN Extender

software will recognize that the B203-101 units are connected, and the icon in

the lower-right corner will turn from blue with a red circle on it, to a blue icon.

6. Connect your USB device to the remote unit. The USB 2.0 Extender icon in the

lower-right corner will turn from blue to green when the device is recognized. It

may take a few seconds for the device to be recognized.

Installation Instructions

The USB LAN Extender software installs with the driver, and a shortcut is placed

on your computer desktop, and a status icon in the lower-right corner of your

screen. Upon normal operation, you will not need to use the desktop shortcut,

or click on the status icon. The desktop shortcut is used to launch the USB LAN

Extender software in the event that it has been turned off or does not launch on its

own. When launched, the status icon will appear in the lower-right corner of your

computer screen. Depending on the status of the B203-101 installation, the icon

will be displayed differently. These different statuses are described below.

• When the USB LAN Extender software is launched, but the B203-101 is not

connected to the computer, the status icon will be displayed in blue with a red circle.

• When the B203-101 local unit is connected to the computer, and to the powered-

on remote unit via Cat5e/6 cable, the status icon will be displayed in blue.

• When a USB device is connected to the B203-101, the status icon will display in

green to indicate that the device is recognized.

Right-clicking the status icon pulls up two options; About and Quit. The About option

displays the current USB LAN Extender software version, and the Quit option turns

off the software.

USB LAN Extender Software

201201175-93-3116.indb 3 1/20/2012 11:39:55 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	wifi-repeterer
Modell:	B203-101
Strømkildetype:	DC
Antall USB 2.0-porter:	2
Utgangsstrøm:	5 V
Produktfarge:	Sort
Bærekraftsertifikater:	RoHS
Modell/Type:	Konsollsender og -mottaker
Antall RJ45-porter:	2
AC-adapter bunt:	Ja
Overføringshastighet (Mbps):	480 Mbit/s
Innput-strøm:	0.5 A
Maksimal overføring avstand:	100 m
Kabeltyper som støttes:	Cat5, Cat6
