Tripp Lite IN3009KB Bruksanvisning

Tripp Lite Tastatur IN3009KB

Les nedenfor 📖 manual på norsk for Tripp Lite IN3009KB (7 sider) i kategorien Tastatur. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/7

1111 W. 35th Street

Chicago, IL 60609 USA

Customer Support: (773) 869-1234

www.tripplite.com

Flexible Keyboards—

USB, PS/2 and Wireless

Models: IN3008KB, IN3009KB and IN3010KB

Owner’s Manual

Special Features

Important Warnings

System Requirements

IN3008KB & IN3009KB Installation

IN3010KB Installation

Warranty Registration

Limited Warranty

Español

Français

WARRANTY

REGISTRATION:

chance to win a FREE Tripp Lite

product! www.tripplite.com/warranty

IN3010KB Installation

1. Your IN3010KB (2.4 GHz) Wireless Multimedia

Flexible Keyboard package includes a wireless

flexible keyboard, USB receiver, CD with driver

and AAA batteries.

2. Remove the battery compartment lid on the left side

of the keyboard and insert two AAA batteries

provided. Be careful not to load the batteries

incorrectly—look for guide marks inside the

compartment to check correct battery orientation.

Replace the battery compartment lid.

3. Connect the USB receiver to an open USB port on

your computer or to a port on an additional USB

hub. The blue LED indicator on the receiver will

flash. This indicates that the receiver is connected

and functioning.

4. Next, press the Windows key on the keyboard. If this key is functional, the connection is complete and

the keyboard is operating normally.

5. If you have Windows 98 or 2000 operating system, install and run the CD driver included to make all

the multimedia keys functional. The driver will automatically start to guide you step-by-step in

activating all multimedia functions and completing the installation. NOTE: The maximum transmission

distance is approximately 30ft (10m). The operational distance will vary based on the environment the

keyboard is used in and the amount of interference encountered.

Troubleshooting Your IN3010KB Wireless Multimedia Flexible Keyboard

If you have completed all installation steps and the

keyboard still does not function, the receiver and

transmitter have lost auto-recognition and must be

reconnected. (The receiver and transmitter have auto-

recognition capability and have been preset to the same

channel during production. Normally you should not

need to reset them during installation.) To re-establish

the connection, press the connect button on the receiver

and the connect button on the bottom of the keyboard at

the same time. The receiver's blue LED should flash quickly, indicating the recognition procedure was

successful. Next, press the Windows key and the keyboard should be fully functional. Repeat the

recognition process until the receiver and keyboard are linked.

If after extended use the keyboard begins to respond slowly, replace the batteries. Alkaline, Li Ion or

rechargeable batteries are recommended replacements and should provide many hours of use.

Hot Keys Guide

Your IN3010KB Wireless Multimedia Flexible Keyboard comes preset with the following multimedia hot keys:

CONNECT

Button

Indicator

1111 W. 35th Street

Chicago, IL 60609 USA

Soporte a Clientes: (773) 869-1234

www.tripplite.com

Todas la marcas registradas son totalmente propiedad de sus respectivos dueños.

Teclados Flexibles—

para USB, PS/2, e inalámbrico

Modelos: IN3008KB, IN3009KB e IN3010KB

Manual del Propietario

Características Especiales

Advertencias Importantes

Requerimientos del Sistema

Instalación del IN3008KB e IN3009KB

Instalación del IN3010KB

Garantía Limitada

English

Français

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Tastatur
Modell:	IN3009KB
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Kompatible operativsystemer:	Windows 98/2000/ME/XP
Vekt (imperial):	0.69 Ibs
Produktfarge:	Hvit
Enhetsgrensesnitt:	USB + PS/2
Mus inkludert:	Nei
Intern:	Nei
