Side 1/60

Thunderbolt 3 Dual-Monitor Docking

Station with 8K DisplayPort, 4K HDMI,

USB-A Hub Ports, 3.5 mm Audio, Gigabit

Ethernet and 60W PD 3.0 Charging

Model: MTB3-DOCK-04

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Owner's Manual

WARRANTY REGISTRATION

win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Español 13 • Français 25 • Русский 37 • Deutsch 49

• MTB3-DOCK-04

• Owner’s Manual

• P568-Series High-Speed HDMI Cables

• U428-Series USB 3.1 A/C Cables

• N201-Series High-Speed Cat6 Gigabit Ethernet Cables

• P580-Series DisplayPort Cables

• Thunderbolt 3 input supports data transfer rates up to 40 Gbps

when used with a Thunderbolt 3-enabled host computer

Note: Product is compatible only with a Thunderbolt 3 port and will not

work with a standard USB-C port

• DisplayPort output supports 4-lane DP 1.4 video resolutions up

to 8K (7680 x 4320) @ 30 Hz

• HDMI output supports UHD 4K @ 60 Hz (HDR and 4:4:4), as

speciﬁed by HDMI 2.0

Package Contents

Optional Accessories

Product Features

• Source computer with Windows 10 or Mac OS 10.15.3 and

above and Thunderbolt 3 port

• Displays with DisplayPort and/or HDMI input

• Ethernet network with speeds up to 10/100/1000 Mbps

(1 Gbps)

System Requirements

Product Features

• Transmits video from both ports simultaneously to two displays

Note: See Multi-Monitor Requirements for exact product features

• RJ45 port supports 10/100/1000 Mbps Gigabit Ethernet

speeds to connect to a wired network

• Dual USB 3.2 Gen 2 ports individually support 10 Gbps data

transfer speeds for connecting USB-A peripherals

• Supports self-powered mode when using the PD Charging port

and bus-powered mode when plugged into the host laptop or

computer

Note: Product features vary based on type. See Speciﬁcations Table

for exact product features

• 3.5 mm audio port enables connection of speakers or headset

• USB-C Power Delivery (PD) 3.0 port supports 20V 3A (60W)

power output for charging host computer

• Plug-and-play operation with no software required for easy,

immediate installation

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	datatilbehør
Modell:	MTB3-DOCK-04
Vekt:	220 g
Bredde:	106 mm
Dybde:	106 mm
Høyde:	25 mm
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Strømkildetype:	Thunderbolt 3
Opprinnelsesland:	China
Pakkevekt:	280 g
Antall HDMI-porter:	1
HDCP:	Ja
HDMI-versjon:	2.0
Antall DisplayPorts:	1
Antall per pakke:	1 stykker
Kombinert hodetelefon/mikrofonport:	Ja
Vertsgrensesnitt:	Thunderbolt 3
DisplayPort-versjon:	1.4
HDCP-versjon:	2.2
Antall skjermer som støttes:	2
Visningsmoduser:	Extended, Mirror
Dataoverføringshastighet:	40 Gbit/s
Produktfarge:	Sort
HD-type:	8K Ultra HD
Pakkedybde:	132.6 mm
Pakkehøyde:	38.1 mm
Pakkebredde:	165.1 mm
Maksimal digital oppløsning:	7680 x 4320 piksler
Mikrofon, linje-inn-støpsel:	Nei
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 35 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 70 °C
Lagringsrelativ fuktighet:	0 - 90
Innebygd kortleser:	Nei
Harmonisert system (HS)-kode:	84733020
Ethernet LAN dataoverføringshastigheter:	1000 Mbit/s
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 90
Antall USB 3.2 Gen 2 (3.1 Gen 2)Type-C-porter:	1
Antall USB 3.2 Gen 2 (3.1 Gen 2) Type-A-porter:	2
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332258509
Masterkassens (ytterkassens) bruttovekt:	6500 g
Masterkassens (ytterkassens) lengde:	343.9 mm
Produkter per masterkasse (ytterkasse):	20 stykker
Masterkassens (ytterkassens) bredde:	420.1 mm
Masterkassens (ytterkassens) høyde:	149.1 mm
USB Power Delivery:	Ja
USB Power Delivery opp til:	60 W
