1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Owner’s Manual

Thunderbolt

Docking Station with

Dual 4K Video

Models: MTB3-DOCK-03, MTB3-DOCK-03INT

Español 9 • Français 17 • Русский 25 • Deutsch 33

Product Features

• For use with Mac OS and Windows host computers via either Thunderbolt 3 or

Multi-Function DisplayPort (MFDP) USB-C ports (product features vary based on port

type, see Speciﬁcations Table for exact product features).

• Thunderbolt 3 input port supports data transfer rates up to 40 Gbps when used with

a Thunderbolt 3-enabled host computer; data transfer rates up to 26.2 Gbps are

supported via a MFDP-enabled host computer.

• Included 120W DC power supply provides up to 20V 3A (60W) to the host device.

• MTB3-DOCK-03INT includes 120W DC power supply with AUS, EU, UK and US plugs

for international use.

• Thunderbolt 3 output port supports daisy-chaining up to six devices with source

capability of 15W (5V 3A), and supports Thunderbolt 3-enabled devices such as

monitors, RAID memory and more*.

• DisplayPort connector supports 4-Lane DP1.4 video resolutions up to 8K

(7680 x 4320) @ 30 Hz when used with a Thunderbolt 3-enabled host computer

and 2-Lane DP1.4 video resolutions up to 4K (3840 x 2160) @ 60 Hz via a

MFDP-enabled host computer (requires DP1.4 Alt Mode).

• Supports DisplayPort Multi-Stream Transport (MST) Mode to allow two displays to

be connected, one to the Thunderbolt 3 output port and a second to the DisplayPort

connector for combined resolutions of 8K @ 30 Hz + 4K @ 30 Hz, or dual 4K @

60 Hz.

Note: See Multi-Monitor Requirements for details.

• RJ45 port supports Gigabit Ethernet speeds to connect to a wired network.

• Includes two USB 3.2 Gen 2 Type-A ports, both of which support 10 Gbps data

transfer speeds. One USB-A port supports BC1.2 charging speeds up to 5V 1.5A

and the other supports charging up to 5V 900mA.

• Includes one USB 3.2 Gen 2 Type-C port that supports 10 Gbps data transfer speed

and USB charging up to 5V 1.5A.

• Includes one 3.5 mm audio jack for stereo audio with auto-detection and auto-

switching between OMTP and CTIA.

• SD 4.0 and Micro SD 4.0 slots are available for memory cards. Both can be used

simultaneously.

• Plug-and-play; no external drivers or software are needed

*Only applies to Thunderbolt 3 devices, USB Type-C devices are not supported in the chain.

System Requirements

Package Includes

Optional Accessories

• Windows or Mac OS computer with Thunderbolt 3 or Multi-Function DisplayPort

(MFDP)-enabled USB Type-C port

• DisplayPort or Thunderbolt 3 compatible monitor

• Ethernet network with speeds up to 10/100/1000 Mbps

• MTB3-DOCK-03 or MTB3-DOCK-03INT

• Thunderbolt 3 Cable, M/M, 1.6 ft. (0.5m)

• External Power Supply (Input: 100-240V, 50/60 Hz, 3.0A,

Maximum Output: 20V 6A)

• International Power Adapters (AUS, EU, UK, US), (MTB3-DOCK-03INT only)

• Owner’s Manual

• MTB3-Series 40 Gbps Active Thunderbolt 3 Cables

• N201-Series Cat6 Gigabit Snagless Patch Cables

• P580-Series DisplayPort Cables

• U322-Series USB 3.0 A/B Cables

• U326-Series USB 3.0 Micro-B Device Cables

• U420-003-G2-5A USB 3.1 Gen 2 USB-C M/M Cable (3 ft.)

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	hub & dokkstasjon
Modell:	Thunderbolt MTB3-DOCK-03
Vekt:	270 g
Bredde:	80 mm
Dybde:	147.1 mm
Høyde:	17 mm
LED-indikatorer:	Data, Power
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Strømkildetype:	DC
Opprinnelsesland:	Vietnam
Pakkevekt:	380 g
Hodetelefonutganger:	1
HDCP:	Ja
Antall DisplayPorts:	1
Antall per pakke:	1 stykker
Kombinert hodetelefon/mikrofonport:	Ja
Utgangsstrøm:	20 V
Vertsgrensesnitt:	Thunderbolt 3
DisplayPort-versjon:	1.4
HDCP-versjon:	1.4/2.2
Antall skjermer som støttes:	2
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Ladefunksjon:	Ja
Visningsmoduser:	Extended, Mirror
Dataoverføringshastighet:	40 Gbit/s
Produktfarge:	Black, Grey
HD-type:	8K Ultra HD
Pakkedybde:	180.1 mm
Pakkehøyde:	66 mm
Pakkebredde:	264.9 mm
Minnekortenhet:	MicroSD (TransFlash), SD
Hodetelefontilkobling:	3,5 mm
Kabler inkludert:	Thunderbolt
Maksimal digital oppløsning:	7680 x 4320 piksler
Mikrofon, linje-inn-støpsel:	Nei
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 45 °C
Oppbevaringstemperaturomåde (Celsius):	0 - 70 °C
Lagringsrelativ fuktighet:	5 - 90
Bærekraftsertifikater:	REACH, RoHS
Innebygd kortleser:	Ja
Kroppsmateriale:	Acrylonitrile butadiene styrene (ABS), Aluminium, Polycarbonate (PC)
DC-inngangskontakt:	Ja
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	10 - 85
AC-adapter bunt:	Ja
Antall USB 3.2 Gen 2 (3.1 Gen 2)Type-C-porter:	1
Bærekraftsamsvar:	Ja
Antall USB 3.2 Gen 2 (3.1 Gen 2) Type-A-porter:	2
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332250329
Masterkassens (ytterkassens) bruttovekt:	4400 g
Masterkassens (ytterkassens) lengde:	350 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	380 mm
Masterkassens (ytterkassens) høyde:	279.9 mm
Innput-strøm:	3 A
USB Power Delivery opp til:	60 W
Strømkabelens lengde:	1.2 m
Thunderbolt 3-porter antall:	2
