Side 1/41

Owner’s Manual

Portable USB 3.1 Gen 1 USB-C™

Docking Station - Black

Model: U442-DOCK3-B

Español 12 • Français 22 • Русский 32

PROTECT YOUR INVESTMENT!

and ultimate peace of mind. You could also win an

ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

17-11-242-9337B5.indb 1 1/29/2018 4:30:40 PM

Optional Accessories

Package Contents

• N201-Series Cat6 Gigabit Snagless Patch Cables

• P502-Series High-Resolution VGA Cables

• P566-Series HDMI to DVI Adapter Cables

• P568-Series High-Speed HDMI Cables

• U322-Series USB 3.0 A/B Device Cables

• U326-Series USB 3.0 Micro-B Device Cables

• U420-003-G2-5A USB 3.1 Gen 2 USB-C M/M

Cable, 3 ft.

• U442-DOCK3-B

• Owner’s Manual

System Requirements

• Computer with USB-C or Thunderbolt™ 3 port

that supports USB DisplayPort Alternate Mode

• VGA, DVI* or HDMI monitor

• Ethernet network with speeds up to

10/100/1000 Mbps

*Requires an adapter, such as Tripp Lite’s P566-Series.

See Optional Accessories.

USB Type-C and USB-C are trademarks of USB

Implementers Forum.

17-11-242-9337B5.indb 2 1/29/2018 4:30:40 PM

Product Features

• Supports USB DisplayPort Alternate Mode for

connecting a VGA or an HDMI monitor via a USB-C

or Thunderbolt 3 port

• Supports connection of DVI monitor via HDMI to

DVI adapter (see Optional Accessories)

• HDMI port supports video resolutions up to

3840x2160 (4K x 2K) @ 30 Hz

• VGA port supports video resolutions up to

1920x1200, including 1080p @ 60 Hz

• Ethernet port supports true 10/100/1000 Mbps

network speeds

• USB-A hub and Type-C data ports support data

transfer rates up to 5 Gbps

• Dedicated BC 1.2-compliant USB-A port provides

up to 1.5A of fast charging power to mobile

devices

• USB-C PD charging port for charging your device;

supports power input up to 20V 5A (100W)

• Micro SD and SD/MMC Memory Card Slots

allow external memory access via a USB-C or

Thunderbolt port

• Two USB-A and one Type-C data ports share a

maximum 10W (5V 2A) of power

• Supports PD 3.0 Fast Role Swap to maintain

data and power connection upon removal of

charging power

17-11-242-9337B5.indb 3 1/29/2018 4:30:40 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	hub & dokkstasjon
Modell:	U442-DOCK3-B
Vekt:	90 g
Dybde:	210.8 mm
LED-indikatorer:	Activity, Power
Bruksanvisning:	Ja
USB-kontakttype:	USB Type-C
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Strømkildetype:	USB
Opprinnelsesland:	Vietnam
Pakkevekt:	120 g
Antall HDMI-porter:	1
Sertifisering:	CE, FCC
HDMI-versjon:	1.4
Antall per pakke:	1 stykker
Nettverksstandard:	IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Vertsgrensesnitt:	USB 3.2 Gen 2 (3.1 Gen 2) Type-C
Auto MDI/MDI-X:	Ja
Ladefunksjon:	Ja
Dataoverføringshastighet:	5 Gbit/s
Produktfarge:	Sort
Pakkedybde:	85.1 mm
Pakkehøyde:	20.1 mm
Pakkebredde:	140 mm
Minnekortenhet:	MicroSD (TransFlash), SD
Maksimal digital oppløsning:	3840 x 2160 piksler
Strømforbruk (vanlig bruk):	5 W
Antall VGA (D-Sub)-porter:	1
Mikrofon, linje-inn-støpsel:	Nei
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 45 °C
Oppbevaringstemperaturomåde (Celsius):	-10 - 70 °C
Lagringsrelativ fuktighet:	5 - 90
Bærekraftsertifikater:	RoHS
Innebygd kortleser:	Ja
Harmonisert system (HS)-kode:	84733020
Kroppsmateriale:	Plast
Ethernet LAN dataoverføringshastigheter:	1000 Mbit/s
Støttede Windows operativsystemer:	Ja
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	10 - 85
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	3
Støttede Mac operativsystemer:	Ja
Antall USB 3.2 Gen 2 (3.1 Gen 2)Type-C-porter:	4
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332213492
Masterkassens (ytterkassens) bruttovekt:	1320 g
Masterkassens (ytterkassens) lengde:	154.9 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	220 mm
Masterkassens (ytterkassens) høyde:	100.1 mm
Kompatibel med Mac:	Ja
