Side 1/48

Owner’s Manual

USB-C

™

3.1 Gen 1 Portable

Docking Station, Gray

Model: U442-DOCK6-GY

USB Type-C and USB-C are trademarks of

USB Implementers Forum

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

WARRANTY REGISTRATION

win an ISOBAR surge protector in our monthly drawing!

www.tripplite.com/warranty

Español 13 • Français 25 • Русский 37

Product Features

• Supports DisplayPort Alternate Mode for

connecting an HDMI monitor via USB-C or

Thunderbolt

™

3 port

• Supports connection of DVI monitor

via HDMI to DVI adapter (see Optional

Accessories for more information)

• Mirror Mode allows HDMI and VGA ports to

work simultaneously with a max resolution of

1080p for both ports*

• HDMI port supports 4096 x 2160 30 Hz

4:4:4 video resolutions

• VGA port supports video resolutions up to

1920 x 1200, including 1080p @ 60Hz

• Ethernet port supports true

10/100/1000 Mbps network speeds

• USB-A and Type-C data ports support data

transfer rates up to 5 Gbps

• All USB-A 3.0 ports support data and

charging

• Dedicated BC 1.2-compliant USB port

provides up to 1.5A of fast charging power

to mobile devices (when connected to

power)

Product Features

• USB-C device port supports data and Power

Delivery (PD) charging with power input up

to 20V 5A (100W)

• 5V 1.6A (8W) of power dedicated to the

USB-A ports when connected to a

PD 3.0-compliant charger**

• Supports PD 3.0 Fast Role Swap to maintain

data and power connection upon removal of

charging power

• Automatically resumes operation from

hibernation and suspend mode

• IEEE 802.3az (Energy Efﬁcient Ethernet)

compliant

• Supports full-duplex and half-duplex

operations

• Supports Wake-On LAN

•

Compact design ﬁts easily into your laptop bag

• Plug-and-play—no software or drivers

required

*If connecting two monitors simultaneously, the VGA

port becomes the main extended monitor and the

HDMI monitor mirrors the VGA monitor

** When no power supply is connected, the output

of the USB-A ports are dependent on the connected

source

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	hub & dokkstasjon
Modell:	U442-DOCK6-GY
Vekt:	80 g
Bredde:	95 mm
Dybde:	49 mm
Høyde:	14 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Strømkildetype:	USB
Opprinnelsesland:	Vietnam
Pakkevekt:	100 g
Antall HDMI-porter:	1
Sertifisering:	CE, FCC, REACH
HDMI-versjon:	1.4
Antall per pakke:	1 stykker
Nettverksstandard:	IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Vertsgrensesnitt:	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Auto MDI/MDI-X:	Ja
Ladefunksjon:	Ja
Dataoverføringshastighet:	5 Gbit/s
Produktfarge:	Grå
HD-type:	4K Ultra HD
Pakkedybde:	100.1 mm
Pakkehøyde:	23.1 mm
Pakkebredde:	140 mm
Maksimal digital oppløsning:	4096 x 2160 piksler
Antall VGA (D-Sub)-porter:	1
Mikrofon, linje-inn-støpsel:	Nei
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 45 °C
Oppbevaringstemperaturomåde (Celsius):	-10 - 70 °C
Lagringsrelativ fuktighet:	5 - 90
Bærekraftsertifikater:	RoHS
Innebygd kortleser:	Nei
Harmonisert system (HS)-kode:	84733020
Kroppsmateriale:	Aluminium
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	10 - 85
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	2
Plugg inn og spill:	Ja
Antall USB 3.2 Gen 1 (3.1 Gen 1) Type-C-porter:	1
Full tosidig:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332240771
Masterkassens (ytterkassens) bruttovekt:	1000 g
Masterkassens (ytterkassens) lengde:	134.9 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	294.9 mm
Masterkassens (ytterkassens) høyde:	119.9 mm
Strømtilkobling:	USB Type-C
USB Power Delivery:	Ja
USB Power Delivery opp til:	100 W
Wake-on-LAN-forberedt:	Ja
USB Power Delivery-revisjon:	3.0
