Tripp Lite U442-DOCK14-MS Bruksanvisning

Tripp Lite hub & dokkstasjon U442-DOCK14-MS

Les nedenfor 📖 manual på norsk for Tripp Lite U442-DOCK14-MS (40 sider) i kategorien hub & dokkstasjon. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/40

USB-C Dock with 4K HDMI,

USB Hub and Gigabit Ethernet

for Microsoft

Surface

Model: U442-DOCK14-MS

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Owner's Manual

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Español 9 • Français 17 • Русский 25 • Deutsch 33

Optional Accessories:

Product Features

Package Contents

• Adds 4K HDMI, USB-C and USB-A ports, Gigabit Ethernet and

100W PD 3.0 charging to your Surface tablet

• Supports HDMI resolutions up to 3840 x 2160 @ 30 Hz

• USB hub ports include two USB 3.2 Gen 2 (10 Gbps) ports

and one USB 2.0 port

• Adjustable bracket clamps to the rear of select Microsoft

Surface devices. See Compatible Models for details.

• Connect to a wired Gigabit Ethernet network via the RJ45 port

• USB-C PD 3.0 port supports 20V 5A (100W) power output for

charging host Surface and 10 Gbps for connecting a peripheral

• Plug-and-play--no software or drivers required to operate

• N201-Series Cat6 Gigabit Snagless Patch Cables

• P569-Series High-Speed HDMI Cables

• U322-Series USB 3.2 Gen 1 USB-A to USB-B Device Cables

• U420-Series USB 3.2 Gen 1 USB-C Cables

• U428-Series USB 3.2 Gen 1 USB-A to USB-C Cables

• M100-Series USB Sync/Charge Cable – USB-A to Lightning

• U442-DOCK14-MS USB-C Dock for Microsoft Surface

• Owner’s Manual

Product Overview

USB-C (Male) Input Connector:

Connect to the USB-C port on a Microsoft Surface device

USB-C Data/PD 3.0 Port (Female):

Provides up to 100W (20V 5A) of power via PD 3.0 charging

to the Surface, or capable of USB 3.2 Gen 2 (10 Gbps) data

transfer rates

HDMI Port (Female):

Connect a 4K HDMI monitor

USB 3.2 Gen 2 Ports (x2, Female):

Connect up to two USB 3.2 peripherals

USB 2.0 Port (Female):

Connect a USB 2.0 peripheral, such as a mouse or keyboard

RJ45 Port (Female):

Connect to a wired Ethernet network

2 3 4 4 5 6

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	hub & dokkstasjon
Modell:	U442-DOCK14-MS
Vekt:	250 g
Bruksanvisning:	Ja
Bluetooth:	Nei
Maksimal oppløsning:	3840 x 2160 piksler
Strømkildetype:	USB
Opprinnelsesland:	China
Pakkevekt:	260 g
Antall USB 2.0-porter:	1
Antall HDMI-porter:	1
Maksimal oppdateringshastighet:	30 Hz
Lydutgang:	Nei
Materiale:	Plast
HDMI:	Ja
HDMI-versjon:	2.0
Merkekompatibilitet:	Microsoft
USB-hub:	Ja
Kompatibilitet:	Surface GO, Surface GO 2, Surface GO 3, Surface Pro 7, Surface Pro 8, Surface Pro X
Antall skjermer som støttes:	1
Antall USB Type-C-porter:	1
Kabellengde:	0.3 m
Produktfarge:	Sort
HD-type:	4K Ultra HD
Pakkedybde:	110 mm
Pakkehøyde:	45 mm
Pakkebredde:	279.9 mm
HDMI-kontakttype:	Full-size
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	5 - 35 °C
Oppbevaringstemperaturomåde (Celsius):	-10 - 50 °C
Bærekraftsertifikater:	CE, Federal Communications Commission (FCC), REACH, RoHS
Harmonisert system (HS)-kode:	8517.62.0090
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	20 - 80
Bærekraftsamsvar:	Ja
Masterkassens (ytterkassens) bruttovekt:	3000 g
Masterkassens (ytterkassens) lengde:	300 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	480.1 mm
Masterkassens (ytterkassens) høyde:	134.9 mm
Antall:	1
USB Power Delivery:	Ja
USB Power Delivery opp til:	100 W
USB Type-C DisplayPort Alternate Mode:	Ja
USB Power Delivery-revisjon:	3.0
Dokkingtilkoblingstype:	USB Type-C
Enhetsgrunntype:	Nettbrett
