Tripp Lite U280-005-ST Bruksanvisning

Tripp Lite Batterilader U280-005-ST

Les nedenfor 📖 manual på norsk for Tripp Lite U280-005-ST (16 sider) i kategorien Batterilader. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/16

Quick Start Guide

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an

ISOBAR6ULTRA surge protector—

a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

5-Port USB

Charging Station with

Built-in Storage

Model: U280-005-ST

Español 5 • Français 9 • Русский 13

16-09-543-933653.indb 1 10/26/2016 10:11:50 AM

Product Features

Package Contents

Optional Accessories

• Provides up to 5V, 2.4A of power per port

• USB Battery Charging (BC) Speciﬁcation 1.2 compliant

• Removable brackets allow customization of unit’s storage space according to number

and size of devices being charged

• Doubles as a USB charger and storage device, providing space to neatly organize

devices as they charge and to store divider brackets and power supply when charging

is ﬁnished

• Provides overheating, overcurrent and overvoltage protection

• U280-005-ST USB Charging Station with 5 Ports

• External Power Supply (Input: 100V-240V, 50/60Hz, 1.5A; Max Output: 12V, 4A)

• C7 to 1-15P Power Cord, 5 ft. (1.5 m)

• Removable Storage Brackets (x 7)

• Quick Start Guide

• M100-Series USB to Lightning

Cables

• M110-Series USB to Apple

30-Pin Cables

• P012-006: C7 to 1-15P Power Cord, 6 ft.

• U030-Series USB 5-Pin Mini-B Cables

• UR030-Series Reversible USB 5-Pin Mini-B Cables

• UR050-001-24G 24 AWG Reversible USB 2.0 Micro-B Cable, 1 ft.

• UR050-003-24G 24 AWG Reversible USB 2.0 Micro-B Cable, 3 ft.

• UR050-006-24G 24 AWG Reversible USB 2.0 Micro-B Cable, 6 ft.

• UR05C-Series 20 AWG Reversible USB Micro-B Charging-Only Cables

• U326-Series USB 3.0 Micro-B Cables

16-09-543-933653.indb 2 10/26/2016 10:11:50 AM

Removable Storage Brackets

Speciﬁcations

Customize the unit’s storage space according to the number and size of devices being

charged. To install, simply insert a storage bracket into the desired slots.

To charge USB devices, simply connect the included external power supply and power

cord to the U280-005-ST and to a power source, then plug devices into the available

ports. The ﬁve USB-A ports provide a maximum of 5V, 2.4A of power.

Ports

USB USB-A (Female x 5)

Protection

Overcurrent YES

Short Circuit YES

Overheating YES

Overvoltage YES

Environmental

Operating Temperature 41° to 95°F (5° to 35°C)

Operating Humidity 20-80%

Storage Temperature -4° to 122°F (-20° to 50°C)

Power Requirements

Power Input 100-240V, 50/60Hz, 1.5A

USB-A Port Power Output Up to 5V, 2.4A per port

Mechanical

Dimensions (H x W x D) 6.6 x 4.9 x 2.6 in. / 16.8 x 12.5 x 6.6 cm

Weight 1.5 lbs. / .68 kg

Regulatory Approvals CE, FCC

USB Charging

16-09-543-933653.indb 3 10/26/2016 10:11:51 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Batterilader
Modell:	U280-005-ST
Vekt:	680 g
Bredde:	125 mm
Dybde:	66 mm
Høyde:	168 mm
Plassering:	Bord
Opprinnelsesland:	China
Pakkevekt:	930 g
Sertifisering:	RoHS
Inngangsspenning:	100 - 240 V
Utgangsstrøm:	4 A
Produktfarge:	Sort
Pakkedybde:	256.5 mm
Pakkehøyde:	68.6 mm
Pakkebredde:	152.4 mm
Kabler inkludert:	AC
Modell/Type:	Skrivebordsmontert
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332199581
Masterkassens (ytterkassens) bruttovekt:	9120 g
Masterkassens (ytterkassens) lengde:	330.2 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	370.8 mm
Masterkassens (ytterkassens) høyde:	281.9 mm
Innput-strøm:	1.5 A
Antall støttede enheter:	5
Virkningsprinsipp:	Kontakt
Egnet for bruk i land/region:	USA
