Side 1/16

Quick Start Guide

WARRANTY REGISTRATION

win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Dual 10-Watt Wireless

Fast-Charging Pad, Black

Model: U280-Q02FL-BK

Español 5 • Français 9 • Русский 13

20-06-111-933CB0.indb 120-06-111-933CB0.indb 1 11/18/2020 9:59:22 AM11/18/2020 9:59:22 AM

Product Features

Package Contents

• Universally compatible with all Qi-certiﬁed smartphones and

other devices*

• Charges your smartphone through its protective case (up to

5 mm) to avoid the hassle of removing it

• Prevents overheating and overcharging to protect your device

from damage

• Intelligent 2-color LED indicates charging status, error or

over-temperature warning

• Slim, lightweight, portable design saves space on your desk,

bureau or bedside table

• Transmitting input: 12V 2.5A; output: 5W/7.5W/10W

* Compatible with Apple

iPhone

XS Max/XR/XS/X/8/8 Plus and Samsung Galaxy S10/S10 Plus/

S10E/S9/S9 Plus/S8/S8 Plus/Note 9/Note 8/S7/S7 Edge/S6 Edge Plus/Note 5

• U280-Q02FL-BK Dual Wireless Fast-Charging Pad

• External Power Supply (12V 2.5A)

• Quick Start Guide

20-06-111-933CB0.indb 220-06-111-933CB0.indb 2 11/18/2020 9:59:22 AM11/18/2020 9:59:22 AM

Operation

Notes:

• Phone cases thicker than 5 mm may result in slower charging speeds

• Magnetic or metal attachments will prevent charging

• Compatible with Apple iPhone XS Max/XR/XS/X/8/8 Plus and

Samsung Galaxy S10/S10 Plus/S10E/S9/S9 Plus/S8/S8

Plus/Note 9/Note 8/S7/S7 Edge/S6 Edge Plus/Note 5

1. Connect the included external power supply to the Dual Wireless

Fast-Charging Pad. The intelligent LED will ﬂash blue one time.

2. Place your Qi-compatible device on the pad. The LED will ﬂash

continuously to indicate charging is in progress.*

3. Remove your device from the pad when it is fully charged.

* The LED will ﬂash green to indicate FOD (a foreign object), over-temperature protection or charging error.

Speciﬁcations

Input 12V 2.5A

Output 5V 1A (5W), 5V 1.5A (7.5W) or 9V 1.1A (10W)

Qi Compatible Yes

Switch Frequency 111K-205K

Operating Temperature Range 32° to 95°F (0° to 35°C)

Storage Temperature Range -4° to 158°F (-20° to 70°C)

Operating Humidity Range 10% to 80% RH, Non-Condensing

Storage Humidity Range 5% to 95% RH, Non-Condensing

Size (H x W x D) 7.7 x 0.5 x 3.5 in. / 19.5 x 1.2 x 9 cm

Weight 0.3 lb. / 143.5 g

20-06-111-933CB0.indb 320-06-111-933CB0.indb 3 11/18/2020 9:59:22 AM11/18/2020 9:59:22 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Batterilader
Modell:	U280-Q02FL-BK
Vekt:	150 g
Bredde:	12.3 mm
Dybde:	90 mm
Høyde:	195 mm
LED-indikatorer:	Ja
Strømkildetype:	DC
Opprinnelsesland:	Vietnam
Pakkevekt:	400 g
Trådløs lading:	Ja
Antall per pakke:	1 stykker
Inngangsspenning:	100 - 240 V
Utgangsspenning (maks.):	9 V
Produktfarge:	Sort
Pakkedybde:	105 mm
Pakkehøyde:	67 mm
Pakkebredde:	200 mm
AD-adapter utgangsstrøm:	2.5 A
Pakketype:	Boks
Driftstemperatur (T-T):	0 - 35 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 70 °C
Lagringsrelativ fuktighet:	5 - 95
Bærekraftsertifikater:	CE, REACH, RoHS
Inngangsfrekvens:	50/60 Hz
Strømbeskyttelsesfunksjoner:	Over current, Overcharge, Overheating
Inkluderte kraftpluggtyper:	AU, EU, NA, UK
Relativ luftfuktighet under drift (H-H):	10 - 80
AC-adapter bunt:	Ja
Laderype:	Innendørs
Laderkompabilitet:	Smartphone, Tablet
Maksimal styrke:	10 W
Bærekraftsamsvar:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332257267
Masterkassens (ytterkassens) bruttovekt:	4200 g
Masterkassens (ytterkassens) lengde:	230 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	350 mm
Masterkassens (ytterkassens) høyde:	210 mm
Innput-strøm:	0.8 A
Utgangsspenning (min.):	5 V
Virkningsprinsipp:	Kontaktløs
