Side 1/12

Owner’s Manual

USB 3.0 Mini Dock

Model: U342-SHG-001

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $50 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

14-08-078-93339C.indd 1 8/19/2014 9:49:49 AM

Product Features

System Requirements

• Add a monitor, USB 3.0 port, and Gigabit Ethernet to your computer

or laptop

• Portable design with built-in cable is perfect for travel, tucking into your

laptop bag when not in use

• USB 3.0 is 10 times faster than USB 2.0, supporting data transfer

rates up to 5 Gbps

• Backward compatible with USB 2.0 and 1.1

• Connect a DVI*, HDMI or VGA monitor or projector

• Supports video resolutions up to 2048 x 1152

• Automatically resumes from hibernation and suspend modes

• Gigabit Ethernet port supports true 10/100/1000 Mbps network

speeds

• A USB 3.0 port is available for the connection of a USB peripheral

device

* Requires an HDMI to DVI adapter, such as Tripp Lite’s P566-Series cables

• Supports computers running Windows

XP, Vista, 7, 8, and 8.1

• Supports Surface™ tablets running non-RT Windows 8 or 8.1

• USB port (USB 3.0 port required for USB 3.0 speeds)

• DVI*, HDMI or VGA monitor

* Requires an HDMI to DVI adapter, such as Tripp Lite’s P566-Series cables

14-08-078-93339C.indd 2 8/19/2014 9:49:49 AM

Package Includes

• U342-SHG-001

• Driver CD

• Owner’s Manual

Optional Accessories

• N201-Series Cat6 Snagless Patch Cables

• P502-Series High Resolution VGA Cables with RGB Coax

• P566-Series HDMI to DVI Adapter Cables

• P568-Series High Speed HDMI Cables

• U322-Series USB 3.0 A/B Device Cables

• U326-Series USB 3.0 A/Micro-B Device Cables

Installation

Note: Do not connect the U342-SHG-001 to your computer until you have installed

the product driver.

1. Insert the CD that came with the product into your computer’s CD

drive. If your computer does not have a CD drive, you can obtain the

product drivers via the Tripp Lite website (www.tripplite.com/support).

2. Locate the driver applicable to your computer’s operating system and

run it.

3. Follow the installation prompts that appear.

4. When ﬁnished, connect the U342-SHG-001 to an available port on

your computer using the built-in USB 3.0 A/B cable. Upon connecting

the unit to your computer, the device drivers will ﬁnish installing.

5. Restart your computer to complete the installation.

Note: A restart is needed for all drivers to install properly.

6. Once installation is complete, you can connect your monitor,

10/100/1000 Mbps network, and USB device.

Note: When connecting monitors to the HDMI and VGA ports at the same time,

the adapter defaults to HDMI, disabling the VGA port.

14-08-078-93339C.indd 3 8/19/2014 9:49:49 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	hub & dokkstasjon
Modell:	U342-SHG-001
Vekt:	70 g
Bredde:	123.8 mm
Dybde:	54 mm
Høyde:	17.5 mm
Bruksanvisning:	Ja
USB-kontakttype:	USB Type-A
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Opprinnelsesland:	China
Pakkevekt:	180 g
Antall HDMI-porter:	1
Vertsgrensesnitt:	USB 3.2 Gen 1 (3.1 Gen 1) Type-A
Produktfarge:	Sort
Pakkedybde:	137.2 mm
Pakkehøyde:	40.6 mm
Pakkebredde:	165.1 mm
Antall VGA (D-Sub)-porter:	1
Mikrofon, linje-inn-støpsel:	Nei
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Bærekraftsertifikater:	RoHS
Innebygd kortleser:	Nei
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Ethernet/bredbåndsforbindelse:	Ja
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	1
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332185348
Masterkassens (ytterkassens) bruttovekt:	8350 g
Masterkassens (ytterkassens) lengde:	345.4 mm
Produkter per masterkasse (ytterkasse):	40 stykker
Masterkassens (ytterkassens) bredde:	439.4 mm
Masterkassens (ytterkassens) høyde:	297.2 mm
