1111 W. 35th Street, Chicago, IL 60609 USA

tripplite.com/support

USB-C to 3.5 mm Audio Adapter

with PD Charging

Model: U437-001-C

Español 9 • Français 17 • Русский 22

Owner’s Manual

WARRANTY REGISTRATION

entered to win an ISOBAR surge

protector in our monthly drawing!

tripplite.com/warranty

Product Features

Installation

• Stereo digital-to-analog converter (DAC) with 93dB

signal-to-noise ratio (SNR) for audio output

• Supports digital high-resolution audio

• DAC supports 44.1/48/96/192 kHz/384K Sample

Rate, 16/24/32-bit

• Analog-to-digital (ADC) input conversion supports

48 kHz sample rate, 16 bit

• Compatible with CTIA headphone jacks; not

compatible with OMTP jacks

• Supports QC 2.0 and BC 1.2

• Supports PD charging up to 60W (20V 3A)

• Plug-and-play, no drivers needed

Notes:

• This product is compatible with USB Type-C hosts that

support USB digital audio. It cannot work on Type-C

hosts that support only analog audio mode.

• When using Apple headsets that support volume

adjustments, the volume can only be adjusted

when used with other Apple products.

• This product does not support phone calls on Samsung

S8, Note 9 or Blackberry Keynote.

• When connecting a Type-C mobile phone without

the PD charging function, the audio port will become

inoperable while charging is in use.

The audio port will become operable again when

charging port is not in use.

Installation

• When used with Type-C mobile phones that do not

support data role swap, the audio may stop as the

power adapter is plugged in.

Connect the USB-C male connector to the host

smartphone or laptop.

Connect headphones, speakers or a microphone

to the 3.5 mm connector.

Connect the USB-C input connector to a USB-C

power adapter, such as a PD charging adapter.

The unit can charge the host device while the

adapter is in use.

USB-C Power

Adapter

Connector

3.5 mm Headphone/

Speaker/Microphone

Jack

USB-C

Connector

to Host

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Hi-fi system
Modell:	U437-001-C
Vekt:	20 g
Bruksanvisning:	Ja
Minimum driftstemperatur:	0 °C
Opprinnelsesland:	China
Pakkevekt:	40 g
Sertifisering:	RoHS, REACH, CE, FCC, WEEE
Utgangsstrøm:	3 A
Vertsgrensesnitt:	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Antall porter:	2
Kabelhylsemateriale:	Termoplastisk elastomer (TPE)
Kabellengde:	0.09 m
Produktfarge:	Sølv
Type strømforsyning:	USB
Pakkedybde:	100.1 mm
Pakkehøyde:	20 mm
Pakkebredde:	119.9 mm
Pakketype:	Boks
Driftstemperatur (T-T):	0 - 45 °C
Oppbevaringstemperaturomåde (Celsius):	-10 - 70 °C
Lagringsrelativ fuktighet:	5 - 90
Harmonisert system (HS)-kode:	8536.69.8000
Andre støttede operativsystemer:	ChromeOS
Kroppsmateriale:	Acrylonitrile butadiene styrene (ABS), Aluminium, Polycarbonate (PC)
Line-in:	Ja
Støttede Windows operativsystemer:	Ja
Relativ luftfuktighet under drift (H-H):	10 - 85
Intern:	Nei
Støttede Mac operativsystemer:	Ja
Støttede Linux operativsystemer:	Ja
Antall USB 3.2 Gen 1 (3.1 Gen 1) Type-C-porter:	1
Grensesnitt (hub):	3.5mm, USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Overføringshastighet (Mbps):	5000 Mbit/s
Maksimal opereringstemperatur:	45 °C
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332253900
Masterkassens (ytterkassens) bruttovekt:	610 g
Masterkassens (ytterkassens) lengde:	115.1 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	255 mm
Masterkassens (ytterkassens) høyde:	119.9 mm
USB Power Delivery:	Ja
USB Power Delivery opp til:	60 W
USB Power Delivery-revisjon:	3.0
