Side 1/40

Owner’s Manual

USB 3.2 Gen 1 USB-C

Docking Station

Models: U442-DOCK1, U442-DOCK1-B

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Español 9 • Français 17 • Русский 25 • Deutsch 33

Package Contents

System Requirements

Optional Accessories

• U442-DOCK1 (Silver) or U442-DOCK1-B (Black)

• Owner’s Manual

• Computer* with USB-C port that supports USB DisplayPort Alternate

Mode

• DisplayPort**, Mini DisplayPort, VGA, DVI** or HDMI monitor

• Ethernet network with speeds up to 10/100/1000 Mbps

* The host computer should have administrative rights in order for the dock's drivers

to install automatically the rst time it is connected. If this is not an option, the

drivers can be downloaded and installed manually via the product's webpage at

tripplite.com.

** Requires an adapter. See Optional Accessories.

USB Type-C and USB-C are trademarks of USB Implementers Forum

• N201-Series Cat6 Gigabit Snagless Patch Cables

• P312-Series 3.5 mm Mini Stereo Audio Cables

• P502-Series High-Resolution VGA Cables

• P566-Series HDMI to DVI Adapter Cables

• P568-Series High-Speed HDMI Cables

• P583-Series mDP to DP Adapter Cables

• P584-Series mDP Cables

• U322-Series USB A/B Device Cables

• U326-Series USB Micro-B Device Cables

• U420-003 USB 3.2 Gen 1 USB-C M/M Cable, 3 ft.

Product Features

• Supports USB DisplayPort Alternate Mode for connecting VGA, HDMI

or Mini DisplayPort (mDP) monitor via USB-C port

• Supports connection of DVI monitor via HDMI to DVI adapter

(see Optional Accessories)

• Supports connection of DisplayPort monitor via mDP to DisplayPort

adapter (see Optional Accessories)

• mDP and HDMI ports support video resolutions up to 3840 x 2160

(4K x 2K) @ 30 Hz

• VGA port supports video resolutions up to 1920 x 1200

(including 1080p) @ 60 Hz

• Ethernet port supports true 10/100/1000 Mbps network speeds

• USB-A hub ports support data transfer rates up to 5 Gbps

• Dedicated 5V/1.5A USB ports provide fast charging power to mobile

devices

• Micro SD and SD/MMC memory card slots support simultaneous use

for external memory access

• USB-C charging port supports power input up to 20V 5A (100W)

• 15W of USB-C input power dedicated to unit and its USB hub ports

with remaining power going to USB-C device the unit is connected to

• 3.5 mm mini stereo jack for connecting speaker or microphone

• Automatically resumes operation from hibernation and suspend

modes

• Complies with IEEE 802.3az (Energy E󰀩cient Ethernet)

• Supports full- and half-duplex operations

• Supports IPv4 and IPv6 pack Checksum O󰀪oad Engine (COE) to

reduce CPU loading

• Supports Wake-on-LAN

• Plug and play—no software, drivers or external power supply required

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	hub & dokkstasjon
Modell:	U442-DOCK1
Vekt:	100 g
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Strømkildetype:	USB
Opprinnelsesland:	Vietnam
Pakkevekt:	200 g
Antall HDMI-porter:	1
Merkekompatibilitet:	Alle merker
Kombinert hodetelefon/mikrofonport:	Ja
Vertsgrensesnitt:	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Dataoverføringshastighet:	5 Gbit/s
Produktfarge:	Sølv
Pakkedybde:	135.1 mm
Pakkehøyde:	23.1 mm
Pakkebredde:	165.1 mm
Minnekortenhet:	MicroSD (TransFlash), SD
Maksimal digital oppløsning:	3840 x 2160 piksler
Antall VGA (D-Sub)-porter:	1
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Bærekraftsertifikater:	RoHS
Innebygd kortleser:	Ja
Harmonisert system (HS)-kode:	84733020
Antall Mini DisplayPorts:	1
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Ethernet/bredbåndsforbindelse:	Ja
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	3
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332193831
Masterkassens (ytterkassens) bruttovekt:	2200 g
Masterkassens (ytterkassens) lengde:	175 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	240 mm
Masterkassens (ytterkassens) høyde:	145 mm
Innput-strøm:	3 A
Maksimal analog oppløsning:	1920 x 1200 piksler
