Side 1/25

USB 3.1 Gen 1 to

HDMI Alternate Mode

Adapter

Models:

U444-06N-HD-AM, U444-06N-HDB-AM

Español 8 • Français 14 • Русский 20

Quick Start Guide

PROTECT YOUR INVESTMENT!

peace of mind. You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

17-10-150-933753.indb 1 10/27/2017 3:53:14 PM

Product Features

• Supports USB DisplayPort Alternate Mode for

displaying audio/video signals on an HDMI monitor

or projector via your computer, tablet, laptop or

smartphone’s USB-C™ or Thunderbolt™ 3 port

• Supports Ultra High Deﬁnition (UHD) 4K x 2K

video resolutions up to 3840 x 2600 (@ 60 Hz)*

or 3840 x 2160 (@ 24/25/30 Hz)

• Supports 36-bit Deep Color (12 bits per channel)

• Supports per-lane transfer rates of 5.4 Gbps

(HBR2), 2.7 Gbps (HBR) and 1.62 Gbps (RBR)

• Supports USB 3.1 Gen 1 data transfer rates up to

5 Gbps

• No external power supply or drivers required

*3840 x 2600 @ 60 Hz supported in Single Stream

Transport (SST) mode only. Additional monitors cannot be

connected using Multi Stream Transport (MST) mode.

USB Type-C™ and USB-C™ are trademarks of USB

Implementers Forum.

17-10-150-933753.indb 2 10/27/2017 3:53:14 PM

System Requirements

Installation

Package Contents

• USB-C or Thunderbolt™ 3 device that supports

USB DisplayPort Alternate Mode

• HDMI-enabled monitor

1. Connect the adapter’s USB Type-C connector to

the USB Type-C port on your computer, tablet,

laptop or smartphone.

2. Connect the adapter’s HDMI port to a monitor

using an HDMI cable (such as Tripp Lite’s

P568-Series cables).

3. The video image will appear on the add-on

monitor. Use your device’s display settings to

customize how video is displayed on the add-on

monitor.

• U444-06N-HD-AM (White) or U444-06N-HDB-AM

(Black)

• Quick Start Guide

17-10-150-933753.indb 3 10/27/2017 3:53:14 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	hub & dokkstasjon
Modell:	U444-06N-HDB-AM
Vekt:	20 g
Bredde:	12.5 mm
Dybde:	35 mm
Høyde:	6.7 mm
Maksimal oppløsning:	3840 x 2160 piksler
Opprinnelsesland:	Vietnam
Pakkevekt:	30 g
Antall HDMI-porter:	1
HDCP:	Ja
HDMI-versjon:	1.4
Vertsgrensesnitt:	USB 3.2 Gen 2 (3.1 Gen 2) Type-C
Antall porter:	1
Tilkobling 1:	HDMI Type A (Standard)
Tilkobling 2:	USB Type-C
Kabellengde:	0.15 m
Produktfarge:	Sort
Pakkedybde:	100.1 mm
Pakkehøyde:	20.1 mm
Pakkebredde:	119.9 mm
Støttede grafikkoppløsninger:	3840 x 2160
Driftstemperatur (T-T):	0 - 45 °C
Oppbevaringstemperaturomåde (Celsius):	-10 - 70 °C
Lagringsrelativ fuktighet:	5 - 90
Harmonisert system (HS)-kode:	84733080
Relativ luftfuktighet under drift (H-H):	10 - 85
Kontaktplettering:	Nickel
Grensesnitt (hub):	HDMI
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332210668
Masterkassens (ytterkassens) bruttovekt:	520 g
Masterkassens (ytterkassens) lengde:	119.9 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	255 mm
Masterkassens (ytterkassens) høyde:	115.1 mm
Connector 1 kjønn:	Hankjønn
Connector 2 kjønn:	Hunkjønn
Tilkobling 1 formfaktor:	Rett
