Side 1/16

Owner’s Manual

USB Type-C

™

HDMI/VGA Converter

Model: U444-06N-HV4K

USB Type-C and USB-C are trademarks of USB Implementers Forum

Español 5 • Français 9 • Русский 13

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

19-02-344-933719.indb 1 3/11/2019 7:39:15 PM

Product Features

Package Contents

System Requirements

• Connect a VGA and/or HDMI monitor to the USB-C or Thunderbolt™ 3

port on your laptop or desktop*

• Supports USB DisplayPort Alternate Mode for transmitting audio/video via

USB-C port

• HDMI port supports 4K x 2K Ultra High Deﬁnition (UHD) video resolutions

up to 3840 x 2160 @ 30 Hz

• VGA port supports video resolutions up to 1920 x 1200 @ 60 Hz,

including 1080p

• HDCP 1.4 compatible

• Supports 30-bit Deep Color (10 bits per channel)

• 7.1 channel surround sound audio supported via HDMI port

• Supports 300 MHz/3 Gbps per channel bandwidth (9 Gbps total)

• Designed for use with the MacBook

, Google Chromebook Pixel™, and all

USB Type-C supported computers, tablets and other devices

• Low-proﬁle design is perfect for travel and stores easily in a laptop bag

when not in use

• Plug and play – no software or drivers required

* If connecting two monitors simultaneously, the VGA port is the main extended

monitor. The HDMI monitor will mirror the VGA monitor.

• U444-06N-HV4K

• Owner’s Manual

• USB Type-C device that supports USB DisplayPort Alternate Mode

• Monitor with a VGA or HDMI port

19-02-344-933719.indb 2 3/11/2019 7:39:15 PM

Optional Accessories

Speciﬁcations

Installation

• P502-Series High-Resolution VGA Cables with RGB Coax

• P569-XXX-CERT Premium High-Speed HDMI Cables

Input Signal

USB Type-C

Output Signal

VGA and HDMI

Maximum HDMI Resolution 3840 x 2160 @ 30 Hz

Maximum VGA Resolution 1920 x 1200, including 1080p @ 60 Hz

Maximum Cable Length 6 ft. (1.8 m) for HDMI / 10 ft. (3 m) for VGA

Color Depth 30-bit Deep Color (10 bits per channel)

Environmental

Operating Temperature 32 to 113°F (0 to 45°C)

Storage Temperature 14 to 158°F (-10 to 70°C)

Operating Humidity 10% to 85% RH, Non-Condensing

Storage Humidity 5% to 90% RH, Non-Condensing

Maximum Power Consumption

1.25W (5V @ 250mA)

Notes:

• If connecting two monitors, the maximum resolution will be renegotiated

automatically to the lowest video format, in this case 1080p.

•

To connect a Mac to an HDMI monitor with audio, go to “System Preferences” and

select “Sound.” Then click the “Output” tab and select your HDMI device from the list.

• When connecting an HDMI monitor, the distance between the converter and monitor

must be no longer than 16 ft. (4.8 m) when using 28 AWG or heavier gauge

cabling.

1. Connect the USB Type-C connector on the adapter to the USB Type-C

port on your smartphone, tablet, Ultrabook or computer.

2. Connect a monitor to the VGA or HDMI port on the converter.

19-02-344-933719.indb 3 3/11/2019 7:39:15 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	hub & dokkstasjon
Modell:	U444-06N-HV4K
Vekt:	30 g
Bredde:	40 mm
Dybde:	60 mm
Høyde:	14 mm
Maksimal oppløsning:	3840 x 2160 piksler
Opprinnelsesland:	Vietnam
Pakkevekt:	40 g
Tilkobling 1:	USB Type-C
Tilkobling 2:	HDMI + VGA (D-Sub)
Kabellengde:	0.1524 m
Produktfarge:	Hvit
Pakkedybde:	100.1 mm
Pakkehøyde:	20.1 mm
Pakkebredde:	119.9 mm
Støttede grafikkoppløsninger:	3840 x 2160
Driftstemperatur (T-T):	0 - 45 °C
Oppbevaringstemperaturomåde (Celsius):	-10 - 70 °C
Harmonisert system (HS)-kode:	84733080
Kontaktplettering:	Nickel
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332205701
Masterkassens (ytterkassens) bruttovekt:	660 g
Masterkassens (ytterkassens) lengde:	119.9 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	255 mm
Masterkassens (ytterkassens) høyde:	115.1 mm
Connector 1 kjønn:	Hankjønn
Connector 2 kjønn:	Hunkjønn
