Quick Start Guide

USB-C 3.1 SATA SSD/HDD

Water-Resistant Enclosure with

Built-In Cable for 2.5-Inch Drives

Models: U457-025-G1-WPG (USB 3.1 Gen 1, 5 Gbps),

U457-025-G2-WPB (USB 3.1 Gen 2, 10 Gbps)

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Español 5 • Français 9 • Русский 13

Product Features

Package Contents

System Requirements

• U457-025-G1-WPG (SuperSpeed USB 3.1 Gen 1, 5 Gbps) or

U457-025-G2-WPB (SuperSpeed USB 3.1 Gen 2, 10 Gbps)

• Mini Screwdriver

• Screws (x10)

• Washers (x10)

• Quick Start Guide

• USB 3.1 Gen 1 (5 Gbps) port required to achieve maximum speeds for

U457-025-G1-WPG

• USB 3.1 Gen 2 (10 Gbps) port required to achieve maximum speeds

for U457-025-G2-WPB

• UASP-enabled host controller required to achieve UASP performance

• 2.5 in. SATA HDD or SSD with maximum height of 9.5 mm

• Converts any 2.5 in. internal SATA SSD (solid state drive) or HDD

(hard disk drive) into an external hard drive for storing data

• Designed for 2.5 in. SATA drive heights between 7 mm and 9.5 mm

• Supports SATA III (6 Gbps), II (3 Gbps) and I (1.5 Gbps) drives

• Backward compatible with USB 3.0, 2.0 and 1.1 devices

• Water-resistant and dust-tight to comply with IP66 standards

• UASP-compatible for enhanced performance

• Bus-powered plug-and-play operation with no software or external

power required

Installation

Remove the back cover (side with the screw holes) of the SSD/HDD

enclosure.

Connect your 2.5 in. SATA SSD/HDD to the SATA connector.

Once the SATA SSD/HDD is securely in place, replace the back cover,

ensuring the screw holes line up with one another.

Using the included screwdriver, screws and washers, fasten the 10

screws and washers securely to the enclosure.

In order to comply with IP66 standards, screws need to be properly Note:

tightened to the enclosure.

Connect the built-in USB 3.1 Type-C cable to an available USB port on

your computer.

Drive Connection 22-Pin SATA Data + Power

USB Connection USB Type-C (Male)

Maximum Data Transfer Rate 10 Gbps (U457-025-G2-WPB)

5 Gbps (U457-025-G1-WPG)

SSD/HDD Supported 2.5 in. SATA I/II/III HDD/SSD

Operating Temperature 50° to 122°F (10° to 50°C)

Relative Humidity 10% to 80% RH, Non-Condensing

Dimensions 0.94 x 3.7 x 5.8 in. (24 x 94 x 148 mm)

Speciﬁcations

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Harddisk
Modell:	U457-025-G2-WPB
Produkttype:	HDD/SSD-kabinett
Vekt:	230 g
LED-indikatorer:	Ja
USB-kontakttype:	USB Type-C
Strømkildetype:	USB
Opprinnelsesland:	China
Pakkevekt:	230 g
Sertifisering:	CE, FCC, REACH
USB-versjon:	Thunderbolt 3
Materiale:	Akrylonitril-butadien-styren (ABS)
USB-tilkobling:	Ja
Maksimal lagringskapasitet:	2 TB
Støttede lagringsstasjonshøyder:	9.5 mm
UASP-støtte:	Ja
Dataoverføringshastighet:	10 Gbit/s
Kabellengde:	0.185 m
Produktfarge:	Sort
Pakkedybde:	140 mm
Pakkehøyde:	34.8 mm
Pakkebredde:	180.1 mm
Pakketype:	Boks
Driftstemperatur (T-T):	10 - 50 °C
Oppbevaringstemperaturomåde (Celsius):	0 - 65 °C
Lagringsrelativ fuktighet:	10 - 80
Bærekraftsertifikater:	RoHS
Skruer inkludert:	Ja
Støttede lagringsgrensesnitt:	Serial ATA, Serial ATA II, Serial ATA III
Antall lagringsdrivere som støttes:	1
Relativ luftfuktighet under drift (H-H):	10 - 80
Plugg inn og spill:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332250510
Masterkassens (ytterkassens) bruttovekt:	2490 g
Masterkassens (ytterkassens) lengde:	192 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	367 mm
Masterkassens (ytterkassens) høyde:	146 mm
Kjønn på USB-kontakt:	Hankjønn
Lagringsstasjonens størrelse:	2.5 "
Skrutrekker inkludert:	Ja
