TRT-BA-TDPDSP-TC2019-61-003-EN
TDS DSP
EN
OPERATING MANUAL
PRESSURE SWITCH
2 EN
pressure switch TDS DSP
Table of contents
Information about the device................................................5
Transport and storage...........................................................6
Assembly and installation.....................................................6
Errors and faults....................................................................9
Maintenance ........................................................................10
Technical annex...................................................................10
Notes regarding the operating manual
Symbols
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Note
This signal word indicates important information
(e.g. material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
operating manual must be observed.
You can download the current version of the operating manual
and the EU declaration of conformity via the following link:
TDP DSP
https://hub.trotec.com/?id=44132
Safety
Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use!
Warning
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/ or serious injury.
Save all warnings and instructions for future
reference.
This appliance can be used by children aged
from 8years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
General safety
• Do not use the device in potentially explosive rooms.
• Do not use the device in aggressive atmosphere.
• Check accessories and connection parts for possible
damage prior to every use of the device. Do not use any
defective devices or device parts.
• Before carrying out maintenance, care or repair work on
the device, remove the mains plug from the mains socket.
Hold onto the mains plug while doing so.
• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.
EN 3
pressure switch TDS DSP
General safety warnings – Electrical safety
• The device is to be supplied with a rated residual current
of no more than 30mA by means of an RCD (Residual
Current protective Device).
• Ensure that all electric cables outside of the device are
protected from damage (e.g. caused by animals). Never
use the device if electric cables or the power connection
are damaged!
• The electrical connection must correspond to the
specifications in chapter Technical data.
• Insert the mains plug into a properly secured mains
socket.
• Do not under any circumstances use the device if you
detect damages on the mains plug or power cable.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Defective power cables pose a serious health risk!
• Should the connection line of the device be damaged, it
must be replaced by the manufacturer, his customer
service or similarly qualified personnel in order to avoid
hazards.
• Should there be a risk of flooding, install the plug
connections in a flood-proof area. There is a risk of
electric shock!
• Make sure that the mains voltage corresponds to the
specifications on the nameplate.
• Have all electrical installations carried out by an expert
according to the national regulations and the device-
specific requirements.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Protect the power supply cable against heat, oil and sharp
edges. Make sure that the power supply cable is not
crushed, kinked or subjected to other mechanical stresses.
• Only use splash-proof extension cables intended for
outdoor use whilst observing the device's power input.
Before using cable drums, always unroll the cable
completely. Check the cable for damage. The use of
extension cables which are not approved for outdoor use
can result in injuries due to electric shock.
• Before performing any work on the device, in case of leaks
in the water system, before taking work breaks or when
not in use, remove the mains plug from the mains socket.
General safety warnings – Personal safety
• Never insert any objects or limbs into the device.
• This appliance is not a toy! Keep away from children and
animals. Do not leave the device unattended during
operation.
Warning
Device-specific safety warnings for pressure
switches
• Before taking the device into operation, have the following
checked by an expert:
– Earthing, neutral conductor and RCD must be
functioning properly and correspond to the national
regulations,
– electrical plug connections must be protected from
moisture.
• Provide appropriate frost protection.
• Never operate the device in the rain. Keep the device away
from environmental influences such as wet conditions or
frost. In particular, keep the electrical connections dry and
make sure they are located in a flood-proof area.
• Do not use the device at freezing temperatures or
temperatures above 60°C.
• Do not use the device for drinking water supply, and do not
integrate it into the drinking water circuit. In addition,
please observe the local regulations of the water and
wastewater authorities.
Intended use
The device serves for switching a connected garden or deep
well pump on and off. It is used to pump rainwater or service
water into private areas (e.g. into the garden) in compliance
with the regulations specified in the technical data. It is installed
in the water line between a pump and one or more extraction
points. From there, it activates or deactivates the connected
pump depending on the present water pressure and the flow
rate volume.
Clean fresh water is permitted as pump water (e.g. rainwater
from a cistern or ground water from a private well). The
temperature of the pumped water must not exceed 60°C.
