JSD-80 Instruction Manual

Page 1

3rd Edition. February, 2006

1. Introduction

....................................

1.1 Safety notice

1.2 Unpacking

1.3 The JSD-80 Overview

1.4 Technical Speciﬁ cations

1.5 Certiﬁ cations

2. Installation

......................................

2.1 System Hardware Mounting

and Grounding

2.2 System Cooling and Ventila-

tion

3. Block Diagrams

............................

3.1 Audio Block Diagram

3.2 Two-Channel Analog Inputs

Block Diagram

3.3 Eight-Channel Input Block

Diagram

3. Control Block Diagram

4. System Modules

...........................

4.1 Input Module

4.2 Output Module

4.3 Control Module

5. Front Panel

....................................

5.1 Overview

5.2 Adjusting Format Levels

5.3 Adjusting Projector Gains

6. Back Panel

....................................

6.1 Rear Wiring Diagram

6.2 Back Panel Input Connec-

tions

6.3 Back Panel Signal Output

Connections

6.4 Other Back Panel Connec-

tions

7. JSD-80 Interface Software

............

7.1 Installation Procedure

7.2 Opening screen

7.3 Proﬁ le Screen

7.4 Formats Screen

7.5 Inputs Screen

7.6 Equalizer Screen

7.7 Outputs Screen

7.8 Slit Eq Analyzer

7.9 Creating, Saving and Loading

Conﬁ guration Files

8. “A” Chain Alignment

....................

8.1 Preparing the Soundhead

8.2 Alignment of Solar Cell and

Preampliﬁ er

8.3 Sum and Difference Mode

8.4 Mono EQ and Bypass Level

8.5 Optical Surround Gain and

Delay

8.6 Optical Subwoofer

8.7 Analog Non-Sync, Aux and

Mic levels

8.8 Digital Non-Sync, Digital Aux,

and Digital eight-channel

inputs

8.9 Digital Time Delays

9. “B” Chain Alignment

....................

9.1 Channel conﬁ guration

9.2 Headroom settings

9.3 Main channels

9.4 Subwoofer channel

9.5 Saving Settings After Align-

ment

10. Other Options

..............................

10.1 Pre-set Format Levels

10.2 Startup Mode

10.3 Remote Fader

10.4 System Restore from Person-

ality Module

11. Trouble Shooting

.........................

12. Connector Pinouts

.......................

13. Installation Check List

.................

Table Of Contents

JSD-80

Cinema Sound Processor

USL, Inc.

JSD-80 Instruction Manual

Page 2

3rd Edition. February, 2006

One Year Limited Warranty

★★★★★

USL, Inc. warrants that each product manufactured by it will be free

from defects in material and workmanship under normal usage for

a period of one (1) year after its purchase new from an authorized

dealer. Our obligation under this warranty is limited to repairing or

replacing any product or component which we are satisﬁ ed does not

conform with the foregoing warranty and which is returned to our fac-

tory, freight paid, or serviced by one of our authorized contractors.

The foregoing warranty is exclusive and in lieu of all other warranties,

whether expressed or implied. Such warranty shall not apply to any

product or component (A) repaired or altered by anyone other than

USL, Inc. or an authorized service contractor; (B) tampered with or

altered in any way or subjected to misuse, negligence or accident

or (C) which has been improperly connected, installed or adjusted

other than in accordance with USL, Inc. instruction.

USL, Inc.

JSD-80 Instruction Manual

Page 3

3rd Edition. February, 2006

Please read the entire manual before begin-

ning your installation.

1.1 Safety Notices

General Safety Summary European

Review the following safety precautions

to avoid injury and prevent damage to

this product. To avoid potential risk, use

this product only as speciﬁ ed and only for

the purpose described in the instruction

manual.

To Avoid Fire and Personal Injury:

• Use Correct Power Cable. Use only

the power cable provided. Ensure

that the AC power outlet is located

near the product and is easily acces-

sible.

• Use a Correctly Grounded Power

Source. The Power Supply earth

ground is established through the

ground conductor in the power cable.

To avoid the potential of electric

shock, the ground conductor must be

correct.

• Observe Source Ratings. To avoid risk

of ﬁ re or electric shock, the power

source must be 100 - 240 V AC 50-60

Hz. (European Models)

• Do Not Operate with Suspected Fail-

ures. If you suspect there is damage

or malfunction with this product, call

the factory.

• Do Not Attempt Repair. Only a trained

factory service person is authorized

to repair this product.

• Do Not Operate this Product Near

Heat Sources. This product should

not be located near heat sources such

as radiators, heat registers, or stoves.

• Provide Proper Ventilation. The oper-

ating temperature range is between

0° C and 40° C. The humidity range is

between 20% and 80%, non-condens-

ing. The cooling method is by convec-

tion.

• Keep Product Surfaces Clean and Dry.

Disconnect the power cable from the

power source before cleaning. Do not

use liquid cleaners or aerosol clean-

ers. Use a damp cloth for cleaning.

• Do Not Push Objects Into Opening

of this Product. Never insert objects

into the product through openings.

• Do Not Operate In Wet or Damp Con-

ditions.

• Do Not Operate in an Explosive Atmo-

sphere.

• Prevent the Spilling of Liquids onto

the System Components.

• Inspect the Power Cable and all

Cables prior to Use. Conﬁ rm that the

power cable and other interconnect-

ing cables are free from damage.

Safety Standard

The EN 60950 standard specifies safety

design requirements that reduce or elimi-

nate the risk of personal injury to both the

product user and service personnel. This

product is designed and tested to meet the

standards of the International Electrotech-

nical Commission (IEC) European Norm EN

60950, IEC 60950 (The Standard for Infor-

mation Technology Equipment Including

Electrical Business Equipment).

Section 1. Introduction
