Side 1/14
WEEE Number: 80133970
TECHNICAL DATA
MODEL
VT-6005 VT-1225
SKU
6318, 6319
216318, 216319
6320, 6321
216320, 216321
WATTS
8W 16W
LUMENS@SPHERE360
880 Lm 1760 Lm
LED TYPE
SMD SMD
CRI
>80 >80
PF
>0.9 >0.9
BEAM ANGLE
160° 160°
BODY TYPE
Glass with PET Glass with PET
HOLDER
G5 G5
ON/O FF
>15,000 >15,000
LIFE SPAN
20,000 Hours 20,000 Hours
INP UT POWER
AC:220-240V,50Hz AC:220-240V,50Hz
DIMENSION
19x549mm 19x1149mm
EL
LED Tubes not suitable for
emergency operations
LED Tubes are NOT suitable for
dimming
LED Lamps suitable for 50Hz
operation
LED Lamps to be used in dry conditions
or in a luminaire that provides protection
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
INSTRUCTION MANUAL
T5 LED GLASS TUBE
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC LED Glass Tube. V-TAC will serve you the best. Please read these
instructions carefully before starting the installing and keep this manual handy for future reference. If you have
any another query, please contact our dealer or local vendor from whom you have purchased the product.
They are trained and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase.
The warranty does not apply to damage caused by incorrect installation or abnormal wear and tear. The
company gives no warranty against damage to any surface due to incorrect removal and installation of the
product. The products are suitable for 10-12 hours daily operation. Usage of product for 24 hours a day would
void the warranty. This product is warranted for manufacturing defects only.
PRODUCT INTRODUCTION
Thank you for selecting and buying V-TAC LED Glass Tube, which is equipped with the most advanced lighting
technology today, oering the most significant energy saving, environmental protection, long life span with no
maintenance required. It has 100% better eciency and significantly better brightness than any other old
fixtures.
PRODUCT OVERVIEW
Power saving, no maintenance, easy to install, high eciency, low energy consumption, long life span, low
temperature and no bad glare.
APPLICATION AND USES
The LED glass tube can be used in hotels, oces, factories, conference rooms, meeting rooms, commercial
complexes, residential buildings, schools, colleges, universities, hospitals, etc.
INSTALLATION REQUIREMENTS
• Installation should only be done by a certified electrician
• Operation environment temperature: from -20°C to +45°C
• Do not use DC electricity
• Do not use with electronic ballasts and magnetic ballasts
• Do not modify the fitting to be used with the LED Tube.
• This lamp is not suitable to be used in emergency
luminaires designed for double-capped fluorescent lamp(s).
WIRING DIAGRAM
1. Switch o the power before starting the installation.
2 & 3. To remove the old tube from the fitting, rotate the tube (90°) counterclockwise. [Ensure that electronic ballast
and starter are removed from the fittings].
4. Replace the conventional lamp into the fitting with the LED Lamp.
5. Rotate the LED Tube by 90° clockwise to secure the position of the LED Tube.
6. Switch on the power to test the light.
INSTALLATION INSTRUCTIONS
Single Side Power Only
Le
Right
(L)
(N)
V-TAC
INPUT
LED TUBE
AC:220-240V
50Hz
(L)
(N)
PACKING:
• LED Tube (1PC)
• Instruction Manual (1PC)
