Side 1/27

Installation Guide for

ConferenceSHOT 10

Enterprise-Class PTZ Conferencing Camera

Document 411-0002-31 Rev D

October 2019

Contents

Overview 1

What's in this Guide 1

Features 1

Unpacking the Camera 2

A Quick Look at the Camera 3

Front of the Camera 3

Back of the Camera 4

Installation 5

Don’t Void Your Warranty! 5

Before You Install the Camera 5

Installing the Wall Mount 6

About Ceiling-Mounted Cameras 6

Camera Behavior Settings 7

RS-232 Serial Communication Settings 7

RS-232 Connector Pin-Out 8

Cabling Notes 8

Connecting the Camera 9

Installing the Camera 10

Powering Up the Camera 11

Status Indicator Light 11

Next Steps 12

Operation, Storage, and Care 12

Glossary 13

Compliance and Conformity Statements 16

FCC Part 15 Compliance 16

ICES-003 Compliance 16

European Compliance 17

Warranty and Return Policy 18

Photo Credits 22

Index 23

Overview

This guide covers the ConferenceSHOT™ 10 enterprise-class PTZ conferencing camera:

n North America – 999-9990-000 (silver/black), 999-9990-000W (white)

n Europe and UK – 999-9990-001 (silver/black), 999-9990-001W (white)

n Australia and New Zealand – 999-9990-009 (silver/black), 999-9990-

009W (white)

What's in this Guide

This guide covers:

n Unpacking the camera

n Tips for a successful installation

n Instructions for installing the camera mount

n Information on connecting and mounting the camera

n Camera power-on

Complete product information is available in the Complete Manual for the ConferenceSHOT 10

Enterprise-Class PTZ Conferencing Camera.

Note

If you are responsible for configuring the equipment after installing it, please use the Complete

Manual instead of this guide. The product's Complete Manual includes all the information in this guide,

plus information on system administration, operation, and troubleshooting.

Features

n 2.14 Megapixel effective, native 1080p/60 full HD image sensor

n 10x optical zoom, horizontal field of view of 74° in super-wide mode

n Simultaneous uncompressed USB 3.0 and IP (H.264) streaming outputs at resolutions up to 1080p/60

n Selectable IP stream resolution; USB stream resolution auto-negotiated with conferencing client

n Precise pan and tilt movements at up to 90° per second

n Universal Video Class (UVC) drivers supported in Windows

, macOS

, and Linux operating systems,

compatible with most UC conferencing applications

n Integration-ready Telnet and serial RS-232 control

n Full administrative control via web interface; manage the camera remotely while monitoring the stream

separately

n Presenter-friendly IR remote control

Produkspesifikasjoner

Merke:	Vaddio
Kategori:	Videokonferansesystem
Modell:	ConferenceSHOT 10
Vekt:	1360 g
Bredde:	155 mm
Dybde:	145 mm
Høyde:	163 mm
Maksimal bildefrekvens:	- fps
Optisk zoom:	10 x
Maksimal videooppløsning:	- piksler
Hvitbalanse:	Auto, Manual, One push
Støyreduksjon:	Ja
Horisontalt synsfelt (tele):	7.6 °
Maksimal arbeidsavstand (tele):	1000 mm
Synkroniseringssystem:	Innvendig lys
Sensortype:	CMOS
Produktfarge:	Sort, sølv
Vippevinkelområde:	-30 - 90 °
Monteringssett:	Ja
Kabler inkludert:	AC, USB
Brennviddeområde:	3.8 - 38 mm
Støttede videofunksjoner:	1080i, 1080p
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	2
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-5 - 60 °C
Lagringsrelativ fuktighet:	20 - 80
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
CCD-sensorstørrelse:	1/2.8 "
Signal-til-støy-forhold (SNR):	50 dB
Megapiksel:	2.38 MP
Justering av fokus:	Automatisk/Manuell
Panoreringsomfang:	-165 - 165 °
DC-inngangskontakt:	Ja
Minimumsbelysning:	1 lx
Relativ luftfuktighet under drift (H-H):	20 - 80
Blenderåpning rekkevidde:	1.8 - 3.4
AC-adapter bunt:	Ja
Webbasert administrasjon:	Ja
Baklyskompensasjon (BLC):	Ja
Vinningskontrolltype (gain):	Automatisk/Manuell
DC inngående spenning:	12 V
Innput-strøm:	3 A
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-B-porter:	1
Effektiv sensor oppløsning:	2.14 MP
Maksimal arbeidsavstand (bred):	10 mm
Panoreringshastighet (min):	90 °/sek
Panoreringshastighet (maks):	90 °/sek
Lutningshastighet (min):	90 °/sek
Lutningshastighet (maks):	90 °/sek
Horisontalt synsfelt (bred):	67 °
Optisk zoom (super-bred modus):	11 x
Brennviddeområde (superbred modus):	3.8 - 41.8 mm
Visningsvinkel (bred-ende, superbred modus):	74 °
Visningsvinkel (tele-ende, superbred modus):	7.6 °
Antall blenderåpningstrinn:	16
Kontroll-adapter:	Ja
