Side 1/4

PRODUCT MANUAL

Designed, Manufactured and Supported in the USA

COMMUNICATION & SECURITY SOLUTIONS

Gooseneck Pedestal Mounting Kit for the

E-1600A, E-1600-45A, E-1600-60A and E-1600-65A

Features

The model E-1600A-MK-GNP is a mounting kit

for attaching the E-1600A, E-1600-45A, E-

1600-60A or E-1600-65A Emergency Phone to

a Viking VE-GNP gooseneck pedestal.

The kit includes stainless steel mounting hard-

ware, two gaskets to seal the back of the Emer-

gency Phone and a durable powder coated 12

gauge steel mounting plate.

• E-1600A-MK-GNP allows the E-1600A,

E-1600-45A, E-1600-60A or E-1600-65A

Emergency Phone to be mounted directly

to a Viking VE-GNP gooseneck pedestal

• Durable 12 gauge steel mounting plate

• Plate is powder coat primed then top

coated with a UV stable black textured

powder coat

• Stainless steel mounting hardware is in-

cluded

• Two gaskets are included for sealing the

back of the Emergency Phone to the

gooseneck pedestal

• For mounting the following Viking Emer-

gency Phones to a Viking VE-GNP

gooseneck pedestal for emergency pool

phone applications etc.

- E-1600A Red Emergency Phone

- E-1600-45A Yellow Emergency Phone

- E-1600-60A “Police” Emergency Phone

- E-1600-65A Blue Emergency Phone

For more information on Viking Emer-

gency Phones, see DOD# 215

Dimensions: 5.37” x 3.40” x 0.105” (136.4mm x

86.4mm x 2.67mm)

Shipping Weight: 1.2 lbs (0.544 kg)

Environmental: -40°F to 150°F (-40°C to 65°C)

with up to 100% humidity

Included Hardware: (4) #10-24 x 5/8 stainless

steel truss head screws, (4) 10-24 stainless steel

nylock nuts

E-1600A-MK-GNP

E-1600A Gooseneck

Pedestal Mounting Kit

December 20, 2016

Applications

Specifications

www.vikingelectronics.com

Information: (715) 386-8861

VIKING

E-1600A-MK-GNP Mounting Plate

Model E-1600A

Emergency Phone

shown with VE-GNP

Pedestal and

E-1600A-MK-GNP

Mounting Kit
