Side 1/4

Provide Convenient Handsfree Communication

Features

The E-10A, E-10-WHA and E-20B are telephone line

powered speaker phones that provide straightforward

two-way handsfree communication. All units function

identically, but are available in different housings to

better suit the application. When the “Call” button is

pressed, the speaker phone will come off-hook and

will remain off-hook until one of the following happens:

a CPC signal is detected, the programmed timeout

has elapsed, a busy signal is detected, or the call goes

silent, making the unit automatically disconnect.

The speaker phone can be connected directly to a

C.O. line or analog PABX/KSU station when

programmed as a ringdown circuit, or used with a

Viking Dialer. If a line or station is not available,

Viking’s DLE-200B ring down circuit can be used.

One to four speaker phones can share an existing

phone line in a house or small business when used

with a Viking C-200, C-250, C-500, or C-2000B

Controller.

For outdoor installations models E-10A-EWP,

E-10-WHA-EWP and E-20B-EWP come eqipped with

Enhanced Weather Protection (EWP). EWP products

are designed to meet IP66 standards and may feature

foam rubber gaskets and boots, sealed connections,

gel-filled butt connectors, as well as potted circuit

boards with internally sealed, field-adjustable trim pots

and DIP switches for easy on-site programming. For

more information, see DOD 859.

• Alternate action call button to place or cancel a call

• Intelligent call progress detection for automatic hang-

up on CPC, silence, busy signal, or time out

• Telephone line powered

• Weather resistant features: mylar speaker, gaskets,

internally sealed push button switch, UV stable

exterior, enamel coated PCB

• E-10A-EWP, E-10-WHA-EWP and E-20B-EWP are

designed to meet IP66 Ingress Protection Rating

• Adjustable microphone and speaker volume

• Programmable maximum call length

• Selectable auto-answer feature allows remote

monitoring

• Two way handsfree communication

• Programmable VOX (mic/speaker) switching speed

E-10A, E-10WHA Features:

- Vandal resistant, black or white powder painted,

aluminum face plate with heavy duty 316 stainless

steel call button and mounting gasket

- Flush mountable using included plastic rough-in box

part number - 259576

- Surface mount with optional VE-5x5 (DOD 424)

- T-10 Torx Security Screws

E-20B/E-20B-EWP Features:

- Light gray colored, impact resistant, U.V. stable,

plastic chassis

- Surface mountable only

Power: Telephone line powered (18 VDC/20mA minimum)

Dimensions: E-10A: Overall: 5” x 5” x 2.25” (127mm x 127mm

x 57.2mm), Rough-in box: 4” x 4” x 2.25” (102mm x 102mm x

57mm) E-20B: 5.5” x 4.5” x 1.7” (140mm x 115mm x 43mm)

Shipping Weights:

E-10A: 2 lbs (0.91 kg), E-20B: 1.5 lbs (.75 kg)

Operating Temperature:-30° F to 150° F (-34° C to 65° C)

Humidity - Standard Models: 5% to 95% non-condensing

Humidity - EWP Models: up to 100% condensing

Speaker Volume: Approximately 70db maximum @ 1m

Ring Voltage: 25V AC RMS minimum

CPC Disconnect Time: 300ms minimum

REN: 0.8A

Connections: (2) gel-filled butt connectors

Applications

Specifications

www.VikingElectronics.com

Information: 715-386-8861

Use as a Handsfree Speaker Phone for:

• Courtesy communication

• Delivery entrances

• Parking lots and ramps

• ATM machines

• Convention centers

• Stadiums

• Building lobbies

• Pedestrian gates

• Residences

• Businesses

DESIGNED, MANUFACTURED AND SUPPORTED IN THE USA

E-10A/EWP Series

E-20B/EWP

Speaker Phones

February 9, 2021

PRODUCT

MANUAL

SECURITY & COMMUNICATION

VIKING

E-10-WHA

E-10-WHA-EWP

Flush Mount, White or Black

Powder Painted Aluminum

E-10A

E-10A-EWP

E-20B / E-20B-EWP

Surface Mount,

Light Grey UV Stable

Plastic Chassis

Produkspesifikasjoner

Merke:	Viking
Kategori:	Intercomsystem
Modell:	E-20B
Bredde:	115 mm
Dybde:	38 mm
Høyde:	140 mm
Støynivå:	70 dB
Plassering:	Vegg
Pakkevekt:	750 g
Sertifisering:	FCC Part 68\nFCC Part 15
Antall knapper:	1
Produktfarge:	Hvit
Driftstemperatur (T-T):	-34 - 65 °C
Enkel installering:	Ja
