Compact Entry Phones available in Four Attractive Finishes

Features

Applications

Specifications

• Compact size: Front panel is the size of a typical single gang mid-size

wall plate

• Mounting: Flush mounts in a single gang electrical box (2.25” deep x

2.00” wide x 2.84” tall minimum) or surface mounts in a Viking model

VE-3x5 (not included, see DOD 424) for mounting on a wall, post or

VE-GNP Gooseneck Pedestal (EWP recommended)

• Available in 4 standard faceplate finishes: Brushed Stainless Steel,

Oil Rubbed Bronze, Satin Black and Satin White

• PNL-40 faceplates: Replacement faceplates with matching screws

available in all four standard finishes

• Vandal Resistant Features: 18 gauge 304 stainless steel faceplate,

316 stainless steel push button, fiberglass reinforced plastic speaker

screen, scratch resistant powder coating, hex drive mounting screws

• Weather Resistant Features: Mylar speaker, faceplate gasket,mic

and speaker gasket, internally sealed (IP67) push button switch, self

draining mic mount and UV stable weather resistantpowder coating

(excluding E-40-SS 304 Stainless Steel faceplate)

• E-40-EWP is designed to meet IP66 Ingress Protection Rating (see

DOD 859 for more information)

• Telephone line powered

• Microphone and speaker volume controls

• Programmable intelligent call progress detection for automatic hang-up

on CPC, silence, busy signal, or time out

• Selectable auto answer feature for monitoring

• Programmable VOX (mic/speaker) switching speed

• Blue LED helps locate push button, indicate ringing and off hook

• Door or gate communication, business delivery entrances

• Use with a Viking C-200 or C-250 to control E-40 on a single line

• Use with a Viking C-500 to control 1 or 2 (expandable to 8) E-40’s

and door/gate control on a single phone line

• Use with a Viking C-2000B to control 1 to 4 E-40’s and door/gate

control on a single phone line

• Provide unique front and back door chimes and paging when

used with a Viking SLP-1, SLP-4 and C-2000B

• Residential, commercial and industrial door security

• Use with a Viking K-1900-5 or K-1900-30 for automatic speed

dialing on telephone lines or analog PABX/KSU station ports

• Use on any analog PABX station port with programmable

ringdown capability

The E-40 Series entry phones are compact,

weather and vandal resistant, telephone line

powered speaker phones designed to provide

two-way handsfree audio communication. The

E-40's compact size allows it to be mounted in

a standard single gang electrical box. The E-

40 is available in four different attractive

finishes to match your door hardware, light

fixtures, etc. Replacement E-40 faceplates

(PNL40) can be purchased separately and are

available in all four standard finishes. The

E-40’s blue LED continually provides light for

locating the push button in dark locations, dims

to indicate off hook and flashes during incoming calls.The E-40 entry phones can share a single phone line with house or small

business telephones when used with a Viking model C-200, C-250, C-500 or C-2000B Entry Phone controller. The E-40 entry

phones can also be connected to an unused analog station port (programmed for ring down) on a phone system or connected

directly to a telephone line when used with a Viking model K-1900-5 or K-1900-30 auto dialer. The E-40 features microphone and

speaker volume controls, selectable auto answer for monitoring and intelligent call progress detection for automatic hang-up when

the call is completed. For outdoor installations where the unit is exposed to precipitation or condensation, the E-40 Series is available

with Enhanced Weather Protection (EWP). For more information on EWP, see DOD 859.

Power: Telephone line powered. Minimum 18V DC talk battery

voltage with a minimum loop current of 20mA. Loop current may be

boosted on low current lines with a Viking model TBB-1B Talk Battery

Booster (see DOD 632).

Dimensions: Faceplate: 4.875” x 3.125” x 0.18” (123.8mm x 79.4mm

x 4.6mm), Phone: 2.84” x 1.8” x 1.65” (72mm x 46mm x 42mm)

Shipping Weight: 1.0 lbs (0.45 kg)

Operating Temperature: -30° F to 150° F (-34° C to 65° C )

Humidity: Standard model: 5% to 95% non-condensing humidity,

EWP model: up to 100% humidity

Speaker Volume: Approximately 62db maximum @ 1m

Ring Voltage: 25V AC RMS minimum (for auto answer)

CPC Disconnect Time: 300ms minimum

REN: 0.8A

Connections: (2) gel-filled butt connectors

E-40-SS

“Brushed Stainless Steel”

(similar to brushed nickel) Shown

with optional VE-3x5 surface

mount box

E-40-BK

“Textured Black”

(fine texture black

powder paint)

E-40-WH

“Satin White”

(satin white

powder paint)

E-40-BN

“Oil Rubbed Bronze”

(satin dark brown

powder paint with fine

copper metallic)

www.VikingElectronics.com

Information: 715-386-8861

DESIGNED, MANUFACTURED AND SUPPORTED IN THE USA

E-40 Series

Compact Single Gang

Entry Phone with LED

September 2, 2021

PRODUCT

MANUAL

SECURITY & COMMUNICATION

VIKING

Produkspesifikasjoner

Merke:	Viking
Kategori:	Intercomsystem
Modell:	E-40-SS-EWP
Vekt:	450 g
Bredde:	79.4 mm
Dybde:	4.6 mm
Høyde:	123.8 mm
Støynivå:	62 dB
Plassering:	Vegg
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Sertifisering:	EWP\nIP66\nFCC Part 68\nFCC Part 15
Antall knapper:	1
Dimensjoner (B x D x H):	79.4 x 4.6 x 123.8 mm
Antall utendørsenheter:	1
Produktfarge:	Rustfritt stål
Driftstemperatur (T-T):	-34 - 65 °C
Kroppsmateriale:	Rustfritt stål
Internasjonal beskyttelses (IP)-kode:	IP66
Utendørsenhetens strømtype:	AC/DC
Utendørsenhet medfølger:	Ja
Enkel installering:	Ja
