The E-65 Series Video Entry phones are compact, weather and vandal resistant speaker phones designed to provide two-way hands-

free audio communication and color composite video of who is at your door or gate. The E-65's compact size allows it to be mounted

in a standard single gang electrical box. The E-65 is available in five different attractive finishes to match your door hardware, light fix-

tures, etc. Replacement E-65 faceplates (PNL65) can be purchased separately and are available in all five standard finishes. The E-

65 entry phones can share a single phone line with house or small business telephones when used with a Viking model C-200, C-250,

C-500 or C-2000B Entry Phone controller. The E-65 entry phones can also be connected to an unused analog station port (pro-

grammed for ring down) on a phone system or connected directly to a telephone line when used with a Viking K-1900-5 or K-1900-30

dialer. The E-65 features a built-in high resolution color video camera, microphone and speaker volume controls, selectable auto

answer for monitoring and intelligent call progress detection for automatic hang-up when the call is completed.

For outdoor installa-

tions where the unit is exposed to precipitation or condensation, the E-65 Series is available with Enhanced Weather Protection

(EWP). For more information on EWP, see DOD 859.

Standard Double Gang Box Video Entry Phones

• Built-in high resolution color video camera with wide viewing angle,

tilt/swivel adjustments, and wide operating temperature of -30° F to 150° F

• Audio and video transmission on one CAT5E cable (see page 5)

• Compact size: Front panel is the size of a typical double gang mid-

size wall plate

• Mounting: Flush mounts in a double gang electrical box (2.25” deep

x 3.65” wide x 2.84” tall minimum) or surface mounts in a Viking

model VE-5x5 (not included, see DOD 424) for mounting to a wall,

post or VE-GNP Gooseneck Pedestal (EWP recommended)

• Available in 5 standard faceplate finishes: Brushed Stainless Steel,

Oil Rubbed Bronze, Polished Brass, Satin Black and Satin White

• PNL-65 faceplates: Replacement faceplates with matching screws

available in all five standard finishes

• Vandal Resistant Features: 16 gauge polished brass or 18 gauge

304 stainless steel faceplate, 316 stainless steel push button,

stainless steel speaker screen, scratch resistant powder coating,

impact and scratch resistant camera lens, hex drive mounting screws

• Weather Resistant Features: Mylar speaker, faceplate gasket, mic

and speaker gasket, internally sealed (IP67) push button switch,

sealed camera lens, potted camera circuit board, stainless steel phone

and camera mounting hardware and UV stable weather resistant

powder coating (excludes E-65-SS)

• E-65-EWP is designed to meet IP66 Ingress Protection Rating (see

DOD 859)

• Blue LED helps locate the push button, indicate ringing and off-hook

• Telephone line powered

• Microphone and speaker volume controls

• Programmable Intelligent call progress detection for automatic

hang-up on CPC, silence, busy signal, or time out

TECHNICAL

Dimensions: Faceplate: 4.875” x 4.938” x 0.17” (123.8mm x 125.4mm x 4.3mm), Phone:

2.84” x 1.8” x 1.65” (72mm x 46mm x 42mm)

Shipping Weight: 1.2 lbs (0.55 kg)

Operating Temperature: -30° F to 150° F (-34° C to 65° C)

Connections: (2) gel-filled butt connectors

(3M Scotchlok UR2)

(See page 2 for complete specifications)

E-65 Series

Double Gang Entry

Phones with Color

Video Camera

April 26, 2018

E-65-SS

“Brushed Stainless Steel” (similar to

brushed nickel) Optional VE-5x5 surface

mount box shown (not included)

E-65-BN

“Oil Rubbed Bronze”

(satin dark brown powder

paint with fine copper metallic)

E-65-PB

“Polished Brass”

(with clear gloss powder

paint to prevent tarnishing)

E-65-WH

“Satin White”

(satin white powder paint)

E-65-BK

“Satin Black”

(fine texture satin black

powder paint)

• Door or gate communication, business delivery entrances

• Use with a Viking C-200 or C-250 to control one E-65 on a single

phone line

• Use with a Viking C-500 to control 1 or 2 (expandable to 8) E-65’s

and door/gate control on a single phone line

• Use with a Viking C-2000B to control 1 to 4 E-65’s and door/gate

control on a single phone line

• Provide unique front and back door chimes and paging when used

with a Viking SLP-1 or SLP-4 and C-2000B

• Residential, commercial and industrial door security

• Use with a Viking K-1900-5 or K-1900-30 for automatic speed

dialing on telephone lines or analog PABX/KSU station ports

• Use on any analog PABX station port with programmable ringdown

capability

Produkspesifikasjoner

Merke:	Viking
Kategori:	Intercomsystem
Modell:	E-65-SS-EWP
Vekt:	550 g
Bredde:	125.4 mm
Dybde:	4.3 mm
Høyde:	123.8 mm
Støynivå:	62 dB
Plassering:	Vegg
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Antall knapper:	1
Dimensjoner (B x D x H):	125.4 x 4.3 x 123.8 mm
Antall utendørsenheter:	1
Autentiseringstype:	Nøkkel chip/kort
Produktfarge:	Rustfritt stål
Driftstemperatur (T-T):	-34 - 65 °C
Kroppsmateriale:	Rustfritt stål
Internasjonal beskyttelses (IP)-kode:	IP66
Utendørsenhetens strømtype:	AC/DC
Utendørsenhet medfølger:	Ja
Enkel installering:	Ja
Kamera inkludert:	Ja
