Side 1/25

Features

Applications

Specifications

Information: 715-386-8861

www.VikingElectronics.com

• Vandal Resistant Features: 14 gauge louvered 316 stainless steel faceplate with

permanent laser etched graphics. Speaker/mic screen. Heavy duty metal keypad

buttons and T-10 Security Torx drive mounting screws.

• Weather Resistant Features: Marine grade 316 stainless steel faceplate and screws.

Keypad internally sealed per IP67. Mylar speaker. Self-draining mic mount. Faceplate,

mic and speaker gaskets.

• Built-in 125KHz 26-bit Wiegand proximity card reader with LED and beep card read

confirmation and EWP board protection

• Two sets of SPDT 2 Amp relay contacts for door/gate or camera control

• Optional RC-4A for Secure Remote Relay Control, see DOD 582

• Blue “Call /Status” LED indicator

• SIP compliant (see page 2 for compatible SIP servers and IP phone systems)

• Outbound Proxy, Authentication ID, Peer to Peer, VLAN Tagging

• PoE powered (class 2, <6.5 Watts)

• Automatic Noise Canceling (ANC) feature for operation in noisy environments

• Viking’s proprietary VOX switching eliminates the need for “Push to Talk” mode

• Network downloadable firmware

• Programmable to speed dial up to twelve numbers

Power: PoE class 2 (<6.5 Watts)

Dimensions: Overall: 5” x 10” x 2.5” (127 mm x 254 mm x 63.5 mm)

Rough-in box: 4.5” x 9.12” x 2.5” (114 mm x 232 mm x 64 mm)

Shipping Weight: K-1270-IP: 4.3 lbs (1.95 kg), K-1270-IP-EWP: 4.5 lbs (2.04 kg)

Operating Temperature: -30°F to 140°F (-34°C to 60°C)

Humidity - Standard Products: 5% to 95% non-condensing

Humidity - EWP Products: Up to 100%

Audio Codecs: G711u, G711a, G722

Network Compliance: IEEE 802.3 af PoE, SIP 2.0 RFC3261, 100BASE-TX with

auto cross over

Regulatory Compliance: CE, FCC Part 15 and Canada ICES-003 Class A

Connections: (1) RJ45 10/100 Base-T, (10) gel-filled butt connectors

Installation requires the assistance of a

Network Administrator / IT Technician.

The K-1270-IP entry phones provide a durable and attractive hands-free phone for apartment and residential

door entry or applications requiring a vandal resistant VoIP speaker phone with an integrated 125 KHz

Proximity Card Reader. The K-1270-IP phone is designed to provide quick and reliable handsfree

communication for SIP VoIP phone systems or cloud based service providers. The unit can be programmed

from any PC on the same LAN or remotely using a Static IP Address. The K-1270-IP entry phone can dial

up to 12 programmable numbers and 12 rollover numbers. The brushed stainless steel faceplate has a

built-in 12 resident directory with a waterproof, scratch resistant lens and 12 buttons for single push auto-

dialing of a tenant’s phone number or business extension.

When the K-1270-IP phone is connected to an apartment or business tenant, a built-in contact closure may

be activated to control an electric gate or door strike. Up to 1,000 keyless entry codes may be programmed,

providing tenants with keyless entry. The K-1270-IP has a built-in Proximity Card Reader with capacity to

program up to 1,000 card numbers. Keyless entry codes and card numbers can be programmed to only

allow access at specific times and/or day of the week. The K-1270-IP includes a request for exit (REX)

input and also offers event logging with time and date stamp.

The K-1270-IP-EWP shares all of the features of the K-1270-IP in addition to Enhanced Weather Protection

(EWP) for outdoor installations where the unit is exposed to precipitation or condensation. EWP products

are designed to meet IP66 standards and may feature foam rubber gaskets, sealed connections, gel-filled

butt connectors, as well as potted circuit boards. For more information on EWP, see DOD 859.

K-1270-IP

(shown in optional VE-5x10-SS

surface mount box)

• Cycles to rollover phone number on busy or no-answer

• Program up to 1,000 keyless entry codes and/or proximity card numbers

• Keyless entry codes and proximity card numbers can be programmed to only allow

access at specific times and days of week

• Event logging with time and date stamp

• Optional Enhanced Weather Protection (EWP), EWP products are designed to meet IP66

Ingress Protection Rating, see DOD 859

• Hangs up on busy signal, time-out or touch tone command

• Remotely programmable

• Extended temperature range -40°F to 140°F

• Programmable volume adjustments for microphone and speaker

• Selectable auto-answer feature for monitoring

• Flush mount with included Zinc plated steel rough-in box,

• Surface mount using an optional VE-5x10 surface mount box (not included, see DOD 424)

• Optional LRR-4 Long Range RFID receiver, see DOD 226

• Optional VE-LIGHT kit to illuminate the front panel at night, see DOD 428

• Diagnostics for testing mic, speaker, relays, and proximity cards

Vandal Resistant VoIP Entry Phone System with Built-In

Directory, 12 Button Auto Dialer & Proximity Card R eader

K-1270-IP

“Brushed 316 Stainless Steel”

(similar to brushed nickel)

• Residential Gate Entrance

• Courtesy Assistance Phone

• Customer Service Phone

• Automated Teller (ATM) Phone

• Use with LRR-4 Long Range RFID Transmitter DOD 226

• Use with any of Viking’s Proximity Credentials: PRX-C, PRX-C-ISO,

PRX-FOB, and LRT-4 see DOD 198 and 226

• Kiosk Phone

• Door Entry Phone

• Apartment Entry Phone

PRODUCT

MANUAL

Designed, Manufactured and Supported in the USA

K-1270-IP Series

VoIP Entry Phone System

with Proximity Card Reader

September 28, 2021

SECURITY & COMMUNICATION

VIKING

VoIP SIP System Compatibility

For compatibility and vendor specific detailed configuration instructions, see the Viking VoIP

SIP System Compatibility List, DOD 944. To open and download this PDF file:

1. Go to www.vikingelectronics.com

and enter 944 in the search box

2. Click Application Note (DOD 944)

to open and download the PDF

Scan the QR code below to open

and download the Viking VoIP

SIP System Compatibility List

- OR -

Important: Exclusion from this list means only that compatibility has not been verified, it does not mean

incompatibility. If you have questions, please call Viking Electronics at 715-386-8861.

Definitions

Client: A computer or device that makes use of a server. As an example, the client might request a particular file from the server.

DHCP: Dynamic Host Configuration Protocol. In this procedure the network server or router takes note of a client’s MAC address and assigns an IP address to allow

the client to communicate with other devices on the network.

DNS Server: A DNS (Domain Name System) server translates domain names (ie: www.vikingelectronics.com) into an IP address.

Ethernet: Ethernet is the most commonly used LAN technology. An Ethernet Local Area Network typically uses twisted pair wires to achieve transmission speeds up

to 1Gbps.

Host: A computer or device connected to a network.

Host Name: A host name is a label assigned to a device connected to a computer network that is used to identify the device in various forms of network communication.

Hosts File: A file stored in a computer that lists host names and their corresponding IP addresses with the purpose of mapping addresses to hosts or vice versa.

Internet: A worldwide system of computer networks running on IP protocol which can be accessed by individual computers or networks.

IP: Internet Protocol is the set of communications conventions that govern the way computers communicate on networks and on the Internet.

IP Address: This is the address that uniquely identifies a host on a network.

LAN: Local Area Network. A LAN is a network connecting computers and other devices within an office or building.

Lease: The amount of time a DHCP server reserves an address it has assigned. If the address isn’t used by the host for a period of time, the lease can expire and

the address can be assigned to another host.

MAC Address: MAC stands for Media Access Control. A MAC address, also called a hardware address or physical address, is a unique address assigned to a device

at the factory. It resides in the device’s memory and is used by routers to send network traffic to the correct IP address. You can find the MAC address of your K-

1270-IP phone printed on a white label on the top surface of the PoE LAN port.

Router: A device that forwards data from one network to another. In order to send information to the right location, routers look at IP Address, MAC Address and

Subnet Mask.

RTP: Real-Time Transport Protocol is an Internet protocol standard that specifies a way for programs to manage the real-time transmission of multimedia data over

either unicast or multicast network services.

Server: A computer or device that fulfills requests from a client. This could involve the server sending a particular file requested by the client.

Session Initiation Protocol (SIP): Is a signaling communications protocol, widely used for controlling multimedia communication sessions such as voice and video

calls over Internet Protocol (IP) networks. The protocol defines the messages that are sent between endpoints, which govern establishment, termination and other

essential elements of a call.

Static IP Address: A static IP Address has been assigned manually and is permanent until it is manually removed. It is not subject to the Lease limitations of a Dynamic

IP Address assigned by the DHCP Server. The default static IP Address is: 192.168.154.1

Subnet: A portion of a network that shares a common address component. On TCP/IP networks, subnets are defined as all devices whose IP addresses have the

same prefix. For example, all devices with IP addresses that start with 100.100.100. would be part of the same subnet. Dividing a network into subnets is useful for

both security and performance reasons. IP networks are divided using a subnet mask.

TCP/IP: Transmission Control Protocol/Internet Protocol is the suite of communications protocols used to connect hosts on the Internet. TCP/IP uses several protocols,

the two main ones being TCP and IP. TCP/IP is built into the UNIX operating system and is used by the Internet, making it the de facto standard for transmitting data

over networks.

TISP: Telephone Internet Service Provider

WAN: Wide Area Network. A WAN is a network comprising a large geographical area like a state or country. The largest WAN is the Internet.

Wireless Access Point (AP): A device that allows wireless devices to connect to a wired network using Wi-Fi, or related standards. The AP usually connects to a

router (via a wired network) as a standalone device, but it can also be an integral component of the router itself.

Wireless Repeater (Wireless Range Extender): takes an existing signal from a wireless router or access point and rebroadcasts it to create a second network. When

two or more hosts have to be connected with one another over the IEEE 802.11 protocol and the distance is too long for a direct connection to be established, a wireless

repeater is used to bridge the gap.

Power: PoE powered from K-1270-IP PCB

Maximum Cable Length: 500 ft 24 Awg stranded shielded (Belden 9537)

Frequency: 125KHz

Format: 26 bit Wiegand

Read Range: 1.25” to 2.0”

Technologies Supported: Viking PRX-C, PRX-C-ISO, PRX-FOB, LRT-4,certain legacy

HID® proximity protocols* and certain AWID 125Khz proximity protocols**

Transducer: Beeps during card read

LED: Red, turns off during card read

Humidity: Up to 100% (fully potted EWP)

Operating Temperature: -34° C to 65° C (-30° F to 150° F)

* HID and the HID logo are registered trademarks of HID Global Corporation, an ASSA

ABLOY company. All other trademarks are the property of their respective owners.

** AWID is a trademark of Applied Wireless Identification Group.

Proximity Card Reader Specifications
