Use / Installation
MANUAL
Outdoor Access Doors, Dry Storage, and Storage Drawer
AD52820 / AD51320 / SD5300 / SD5360 / VDSA5420
CAD52820 / CAD51320 / CSD5300 / CSD5360 / CVDSA5420
2
IMPORTANT - Please Read and Follow
•Before beginning, please read these instructions completely and carefully.
•The installer should leave these instructions with the consumer for future reference.
UNPACK
1. Locate the unit near installation area.
2. Remove all banding from around carton.
3. Remove all tape and packaging material from the outside and inside of the access doors or storage drawer.
4. Keep all carton packaging until your access doors or storage drawers have been thorougly inspected and found to be
in good condition.
CUTOUT OUT DIMENSIONS
B
A
2”
(
5.
1 cm)
1”
(2.54 cm)
min.
Notch*
1”
(
2.
5 cm)
Access Doors
AD52820
CAD52820
AD51620
CAD51620
A
(includes notches)
28-1/4” (71.8 cm) Min.
30-1/4” (76.8 cm) Max.
16-1/4” (41.3 cm) Min.
18-1/4” (46.4 cm) Max.
B
(opening only)
20-1/4” (51.4 cm) Min.
20-1/2” (52.1 cm) Max
20-1/4” (51.4 cm) Min.
20-1/2” (52.1 cm) Max
*Before centering doors in opening, make the notches in
all four corners for double access doors and only in the
hinge side for single access doors. The notches need to
be 1” (2.5 cm) long x 2” (5.1 cm) wide. Attach with the
four screws that are provided.
For Single Access Doors only (AD51620/CAD51620):
Only notch the side where the hinge is located. Door
can be mounted with left or right door swing.
Storage Drawers /
Sealed Cabinet
D
C
E
SD5300
CSD5300
SD5360
CSD5360
VDSA5420
CVDSA5420
C 28” (71.1 cm) 33-3/4” (85.7 cm) 38” (96.5 cm)
D 9-1/4” (23.5 cm) 9-1/4” (23.5 cm) 19-1/2” (49.5 cm)
E 23-3/8” (59.4 cm) 23-3/8” (59.4 cm) 24-1/2” (62.2 cm)
3
IMPORTANT - Please Read and Follow!
ACCESS DOOR DIMENSIONS
19-3/16” (48.7 cm)
1
6-3/16” (41.1 cm)
23-1/16”
(58.6 cm)
20-3/16”
(50.9 cm)
L
atch
L
a
tch
mechanism
mecha
ni
s
m
location
locati
on
31
-
3/16”
(79.2 cm
)
28
-
3/16”
(71.6 cm
)
20
-
3/16”
(50.9 cm
)
23
-
1/16”
(58.6 cm
)
A
2-9/16”
(6.5 cm)
1-1/16”
(2.7 cm)
2-1/2”
(6.4 cm)
Double Doors
Single Door
STORAGE DOOR DIMENSIONS
SD5300
CSD5300
SD5360
CSD5360
A 15-7/16” (39.2 cm) 13-3/8” (34.0 cm)
26-29/32”
(68.3 cm)
23”
(58.4 cm)
1-13/32”
(3.6 cm)
24-1/2”
(62.2 cm)
24-13/32”
(62.0 cm)
26-29/32”
(68.3 cm)
8-31/32”
(25.4 cm)
10”
(25.4 cm)
B
SD5300
CSD5300
SD5360
CSD5360
B 29-1/2” (74.9 cm) 35-1/4” (89.5 cm)
