Control panel for swing gates at 24 V DC with encoder EKKO 204D

RS17.P

Table of Contents ......................................................................................................................................................................................................Page

Product features ..........................................................................................................................................................................................................1

System type .................................................................................................................................................................................................................1

Description of the terminal blocks................................................................................................................................................................................2

Connecting accessories 4 ..............................................................................................................................................................................................

Trimmer functions ........................................................................................................................................................................................................5

Button functions ...........................................................................................................................................................................................................5

DIP-switch functions 6 ....................................................................................................................................................................................................

LED functions ..............................................................................................................................................................................................................6

Time setting .................................................................................................................................................................................................................7

Programming the remote controls 8 ...............................................................................................................................................................................

Troubleshooting ...........................................................................................................................................................................................................9

WARNINGS FOR THE INSTALLER

Carefully read all the instructions and warnings in this document as they provide important information regarding safe installation, operation and mainte-

nance.

After removing the packaging, check the condition of the equipment. The packaging must not be left within reach of children as it is potentially harmful.

Installation must be carried out in accordance with national safety regulations.

This equipment must be used only for the purpose for which it was expressly intended, i.e. for the automation of motors for roller blinds and for controlling

resistive loads such as lights. Any other use is considered improper and therefore hazardous. The manufacturer declines all liability for damage caused

by improper, incorrect or unreasonable use.

Always disconnect the equipment from the power supply at the main switch before performing maintenance or cleaning procedures.

In the event of faults and/or malfunctions, disconnect the equipment from the power supply at the switch and do not tamper with it. For repairs, contact only

a service centre authorized by the manufacturer. Failure to observe the above may jeopardize the safety of the equipment.

All equipment within the system must be used exclusively for the purpose for which it is intended.

This document must always be kept with all paperwork regarding the installation.

Directive 2002/96/EC (WEEE).

The crossed out wheelie bin symbol marked on the equipment indicates that, at the end of its useful working life, the product must be handled

separately from household refuse and must therefore be assigned to a di󰀨erentiated collection centre for electrical and electronic equipment or

returned to the dealer upon purchase of a new, equivalent item of equipment.

The user is responsible for ensuring the equipment is disposed of through the correct channels when no longer in service. Proper sorted waste collection

for subsequent recycling, processing and environmentally conscious disposal of the old equipment helps to prevent any possible negative impact on the

environment and human health while promoting the practice of recycling materials used in manufacture. For further details regarding available collection

systems, contact your local waste disposal service or the shop from which the equipment was purchased.

Risks associated with substances considered hazardous (WEEE).

According to the new WEEE Directive, substances which for some time have been widely used in electrical and electronic equipment are considered

hazardous to human heath and the environment. Proper sorted waste collection for subsequent recycling, processing and environmentally conscious dis-

posal of the old equipment helps to prevent any possible negative impact on the environment and human health while promoting the practice of recycling

materials used in manufacture.

Enclosure sizes
