Item No. 2350097-1 en Rev 08/11
ξ¨ξ±ξͺξ―ξ¬ξΆξ«
ξ²ξξξξξξξξ·ξξξ°ξξξξξ
ξ°ξ²ξ§ξΈξ―ξ€ξ΅ξξ§ξ΅ξ²ξ³ξξ¬ξ±
ξ₯ξ²ξ·ξ·ξ²ξ°ξξ°ξ²ξΈξ±ξ·ξξ©ξ€ξ₯ξ΅ξ¬ξ¦ξ€ξ·ξ²ξ΅ξξΊξ¨ξ―ξ―
Thank you for purchasing this Vollrath equipment. Before operating the equipment, read and familiarize yourself with the following operating
and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. Save the original box and packaging. Use this
packaging to ship the equipment if repairs are needed.
ξ¬ξξξ ξ§ξξξξξξξξξξ ξ¦ξξξξξξ ξΉξξξξξξ ξ€ξξξ ξΊξξξ
36352 Drop-In, Bottom Mount Thermostatic Control 120V 8.3 Industry Well
36353 Drop-In, Bottom Mount Thermostatic Control 120V 8.3 Industry Well
36354 Drop-In, Bottom Mount Thermostatic Control 208-240V 3.6-4.2 Industry Well
36355 Drop-In, Bottom Mount Thermostatic Control 208-240V 3.6-4.2 Industry Well
36356 Drop-In, Bottom Mount Thermostatic Control 120V 8.3 Vollrath Well
36357 Drop-In, Bottom Mount Thermostatic Control 120V 8.3 Vollrath Well
36358 Drop-In, Bottom Mount Thermostatic Control 208-240V 3.6-4.2 Vollrath Well
36359 Drop-In, Bottom Mount Thermostatic Control 208-240V 3.6-4.2 Vollrath Well
Fabricator components
OperatOrβs Manual
2
Unpacking the eqUipment and initial SetUp
When no longer needed, dispose of all packaging and materials in an
environmentally responsible manner.
1. Remove all packing material and tape, as well as any protective plastic
from the equipment.
2. Clean any glue residue left over from the plastic or tape.
The equipment must be installed only by qualiξΏed service personnel. The
equipment must be installed by following local codes and ordinances.
The clearance to the sides is 0β (0 mm).
The minimum distance between wells is 1-1/2β (38 mm).
ξ°ξξξξξξΆξξξ ξΊξξξξξ²ξξξξξξ
All 19-7/8β x 11-7/8β
ξ±ξ²ξ·ξ¨ξ
ξ€ξξξξξξξξξξξξξξξξξξξξξξξξξ
ξξξξξξξξξξξξξ΅ξξξξξξξξξξξξξξξξξξξξξξξξξξξξξ
ξξξξξξξξξξξξξξξξξξξξξξξξξξξξ΅ξ
3. Hold unit in place and drill holes through the holes in the well through the
mounting surface.
4. Place the bead of silicone sealer rated at a minimum of 450 Β°F (232 Β°C)
between the countertop and the inside of the well to prevent water from
leaking into control areas. Place the bead of silicone sealer rated at a
minimum of 450 Β°F (232 Β°C) in mounting holes when using rivets or
other fasteners.
FeatUreS and controlS
1
0
9
8
7
6
5
4
3
2
1
0
a
B
c
ξ©ξξξξξξξξξξ©ξξξξξξξξξξξξξ¦ξξξξξξξξ
a
ξ·ξ¨ξ°ξ³ξ¨ξ΅ξ€ξ·ξΈξ΅ξ¨ξξ¦ξ²ξ±ξ·ξ΅ξ²ξ― dial. Used to set or adjust the
temperature of the well. The higher the number the higher the
temperature, the lower the number the lower the temperature. On
models with no On/Off switch, the β0β position is off.
B
ξ³ξ¬ξ―ξ²ξ· light. Illuminates when the well is in the heating mode.
c
ξ²ξ±ξξ²ξ©ξ©ξξΆξΊξ¬ξ·ξ¦ξ«ξξξξξξξξξξξξξξ. Switches the equipment power ON
or OFF.
a
ξ§ξ΅ξ€ξ¬ξ±ξξΉξ€ξ―ξΉξ¨ξξξξξξξξξξξξ. Used to empty water from the well.
SaFety precaUtionS
To ensure safe operation, read the following statements and
understand their meaning. Please read carefully.
WarnInG
Warning is used to indicate the presence of a hazard that can cause
severe personal injury, death, or substantial property damage if the
warning is ignored.
cautIon
Caution is used to indicate the presence of a hazard that will or can
cause minor personal injury or property damage if the caution is
ignored.
ξ±ξ²ξ·ξ¨
Note is used to notify people of installation, operation, or
maintenance information that is important but not hazard-related.
ξ©ξξξξΌξξξξξΆξξξξξξ
These precautions should be followed at all times. Failure to follow
these precautions could result in injury to yourself and others.
To reduce risk of injury or damage to the equipment:
ξ Use only grounded electrical outlets matching the nameplate rated
voltage.
ξ Have the equipment installed by qualiξΏed personnel.
ξ Do not use an extension cord with this equipment. Do not plug this
equipment into a power strip or multi-outlet power cord.
ξ Do not operate without water.
ξ Do not spray controls or outside of equipment with liquids or cleaning
agents.
ξ Do not clean the equipment with steel wool.
ξ Keep equipment and power cord away from open ξames, electric
burners or excessive heat.
ξ Do not operate unattended.
ξ Do not operate equipment in public areas and/or around children.
ξ Do not operate if equipment has been damaged or is malfunctioning in
any way.
FUnction and pUrpoSe
This unit is intended to hold containers of hot food at the proper serving
temperature. This unit is not designed or intended to cook raw food or reheat
prepared food.
Before using this equipment it must be cleaned and dried thoroughly.
This equipment is not intended for household, industrial or laboratory use.
