Operator’s Manual
35 Inch Cheese Melters
Model JW30
©
2017 The Vollrath Company L.L.C. Part No. 351019-1 en 12/5/17
Register your product at Vollrath.com/registration and become eligible to win a free 10" Vollrath Tribute® fry pan.
Thank you for purchasing this Vollrath equipment. Before operating the
equipment, read and familiarize yourself with the following operating
and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE
to ship the equipment if repairs are needed.
SAFETY PRECAUTIONS
To ensure safe operation, read the following statements and understand
their meaning. This manual contains safety precautions which are
explained below. Please read carefully.
Warning is used to indicate the presence of a hazard that will or can
cause severe personal injury or death.
Caution is used to indicate the presence of a hazard that will or can
cause minor or major personal injury if the caution is ignored.
NOTICE: Notice is used to note information that is important but not
hazard-related.
To reduce risk of injury or damage to the equipment
Plug only into grounded electrical outlets matching the voltage on
the rating plate.
Use this equipment in a flat, level position.
Unplug equipment and let it cool before cleaning or moving.
Equipment remains hot after it is turned off.
Unplug when not in use.
Keep equipment and power cord away from open flames, electric
burners or excessive heat.
Do not operate unattended.
Closely supervise equipment operating in public areas and/or
around children.
Do not operate if equipment has been damaged or is malfunctioning.
FUNCTION AND PURPOSE
This equipment is intended to melt cheese, finish cooked food such as
nachos, cheese fries, potato skins and garlic bread in higher-volume
food service operations and large restaurants. It is not intended to bake
food or cook raw food. It is intended for use in commercial foodservice
operations only. It is not intended for household, industrial or
laboratory use.
CLEARANCE AND ENVIRONMENT REQUIREMENTS
Do not place oven on surfaces or near walls, partitions or kitchen
furniture unless they are made of non-combustible material or clad with
non-combustible heat-insulating material. Ovens must not be used near
or below curtains and other combustible materials.
Do not place the oven adjacent to a heat producing appliance.
Allow a minimum of 8 inches (20.3 cm) of clearance on the left and
right sides of the oven.
WARNING
CAUTION
Item No. Model Description
CM4-20835
JW30
Cheese Melter, 35" wide, 208V
CM4-24035 Cheese Melter, 35" wide, 240V
2 35 Inch Cheese Melters Operator’s Manual Model JW30
SET UP
Install the legs
NOTICE: Legs must be installed. Failure to install the legs will
restrict airflow and cause the oven to overheat.
Screw the legs onto the threaded nuts below the cheese melter.
Install the Shelf
Insert the pins on the shelf into the slots on the brackets on the sides of
the oven.
FEATURES
BEFORE FIRST USE
Clean the oven. See “Cleaning” on page 3.
OPERATION
Preheat
1. Plug the oven into a grounded electrical outlet that matches the
rating on the name plate found on the oven.
NOTICE: Using a voltage other than the nameplate rated voltage
will cause damage to the unit. Incorrect voltage,
modification to the power cord or electrical components
can damage unit and will void the warranty.
2. Adjust the shelf to the desired position.
3. Press the On/Off switch to the ON position. The front and rear heater
elements will turn on and the oven will be in standby mode.
4. Set the timer for 10 minutes. The center elements turn on and the
oven is full power.
Melt Cheese, Finish Cooked Food
1. Place the food on or in an oven-proof pan and place the pan on the
shelf.
2. Set the timer to the appropriate length of time to melt cheese, brown
or finish cooked food items.
3. When the time on the timer has expired, the oven will enter a
standby mode.
4. When finished using the oven, press the On/Off switch to the OFF
position.
Bypass the Standby Mode (Optional)
By default, the oven is in standby mode until the timer is set. This
feature can be bypassed to allow all four elements to activate when
power is switch ON.
To bypass the feature, move the toggle switch on the back of the oven
to the up position.
The timer can still be used. But the oven will not enter standby mode
when the time is expired. When time is expired, press the On/Off switch
to the OFF position.
A Fan
B Adjustable Shelf
C Timer
D On/Off Switch
E Reset Button
F Standby Mode Bypass Switch
Front View
Back View
A
B
C
D
E
F
CAUTION
Burn Hazard
Do not touch the equipment while it is heating or operating.
Hot surfaces can burn skin.
35 Inch Cheese Melters Operator’s Manual Model JW30 3
CLEANING
NOTICE: Do not use abrasive materials, scratching cleansers or
scouring pads to clean the equipment. These can damage
the finish.
1. Press the On/Off switch to the OFF position.
2. Unplug the oven.
3. Let the oven cool completely.
4. Slightly dampen a soft cloth with a warm water.
5. Use the dampened cloth to clean the interior and exterior of the
oven, and the air intake on the side of the oven
6. Remove the shelf and clean with warm soapy water.
WARNING
Electrical Shock Hazard
Do not spray water or cleaning products. Liquid could contact
the electrical components and cause a short circuit or an
electrical shock.
CAUTION
Burn Hazard
Allow equipment to cool before moving or cleaning.
TROUBLESHOOTING
Problem Might be Caused By Course of Action
Oven does not heat. Oven is not plugged in. Plug in the oven.
The timer has not been set. Set the timer. The timer must be set to turn on all the heater tubes.
The wall breaker may be tripped. Reset the breaker.
The reset may be tripped. Look on the side of the oven to see if an object is preventing the fan
blades from turning.
1. Press the On/Off switch to the OFF (O) position.
2. Unplug the oven.
3. Wait 30 minutes for the oven cool.
4. Remove the object.
5. Plug in the oven.
6. Press the On/Off switch to the ON (|) position.
7. Press the reset button.
8. If the problem persists call Vollrath Technical Services.
Inspect the fan blades to see if they are dirty.
1. Press the On/Off switch to the OFF (O) position.
2. Unplug the oven.
3. Wait 30 minutes for the oven cool.
4. Clean the fan blades.
5. Plug in the oven.
6. Press the On/Off switch to the ON (|) position.
7. Press the reset button.
8. If the problem persists call Vollrath Technical Services.
One or more heater tubes may have
burned out.
Contact Vollrath Technical Services.
There may be a problem with the heat
switch.
Oven repeatedly overheats. The fan may be dirty. Verify the fan blades are clean.
There may be a problem with the fan. Run the oven for 10 minutes. If the fan does not run, contact
Vollrath Technical Services.
The fan is not running. There may be a problem with the fan or
fan switch.
Run the oven for 10 minutes. If the fan does not run, contact
Vollrath Technical Services.
