Side 1/11
Page1of11
TABLE OF CONTENTS
1 General Information ............................................................................................................... 2
1.1 Description..................................................................................................................... 2
1.2 Specifications................................................................................................................. 2
2 Safety Information..................................................................................................................... 2
3 Daily Inspection…................................................................................................................... 3
4 Operation.................................................................................................................................. 3
4.1 Braking............................................................................................................................ 3
4.2 Lifting.............................................................................................................................. 3
4.3 Lowering......................................................................................................................... 3
5 Maintenance..............................................................................................................................3
6 272970 Part Information............................................................................................................4
6.1 272970 Frame Diagram.................................................................................................. 4
6.2 272970 Frame Part List.................................................................................................. 5
6.3 272970 Pump Diagram................................................................................................... 6
6.4 272970 Pump Part List................................................................................................... 7
7 272973 Part Information............................................................................................................8
7.1 272973 Frame Diagram.................................................................................................. 8
7.2 272973 Frame Part List.................................................................................................. 9
7.3 272973 Pump Diagram................................................................................................... 10
7.4 272973 Pump Part List................................................................................................... 11
WESCOINDUSTRIALPRODUCTS,INC
InstructionManual
HeavyDutyScissorsLiftTables
PartNumber: 272970&272973
Note: Operator MUST read and understand these operating instructions before using
this Heavy Duty Scissors Lift Table.
Page2of11

Heavy Duty Scissors Lift Tables
(Part # 272970 & 272973)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR SCISSORS LIFT TABLE,
READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
1. GENERAL INFORMATION
1.1 DESCRIPTION
Thank you for purchasing a Heavy Duty Scissor Lift Table. These tables feature a fixed,
chrome plated lever release handle, a foot operated pump and locking swivel casters.
1.2 SPECIFICATIONS
Part Number
272970 272973
Model
LT-1650-SL LT-2200SL
Capacity
1650 lbs 2200 lbs
Table Size
20” x 39” 20” x 40”
Table Thickness
.1” .12”
Raised Height
35.5” 39”
Lowered Height
16.5” 15”
Caster Size
5” x 2” 5” x 2”
Locking Caster
Yes Yes
Weight
276 lbs 269 lbs
Materials and specifications are subject to change without notice.
2. SAFETY INFORMATION
1) Read this operation manual carefully and understand completely operating procedures for this lift
table.
2) This lift table is a movable lifter designed to lift or lower rated loads on table. DO NOT use the lift
table for uses other than its intended use.
3) Do not put feet or hands in scissors mechanism.
4) Do not move lift table when table is in raised position.
5) Do not position yourself under the table.
6) Do not overload the lift table.
7) Do not use lift table on sloped or inclined surface, the lift table may become unstable.
8) Do not lift people.
9) Do not lower table too rapidly.
10) Do not place loads on the side or end of table. A load must be distributed on at least 80% of table
area.
11) Do not use the lift table with unstable, unbalanced load.
12) Do not modify the lift table without manufacturer’s written consent.
13) Use swivel locks to prevent the table from lowering when loading, unloading or servicing it.
Page3of11

Heavy Duty Scissors Lift Tables
(Part # 272970 & 272973)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR SCISSORS LIFT TABLE,
READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
3. DAILY INSPECTION
Daily inspection is effective to find any malfunction or fault on the lift table. Check the lift table for the
following before operation:
1) Check for any scratches, bending or cracking on the lift table.
2) Check if there is any oil leakage from the cylinder.
3) Check the vertical creep of the table.
4) Check the smooth movement of the wheels.
5) Check the brake.
6) Check all bolts and nuts are tightened firmly.
CAUTION: Do not use lift table if any malfunction or fault is found.
4. OPERATION
4.1 Braking
CAUTION: Lift the brake when not moving it in order to prevent sudden movement.
The brake is equipped with the swivel caster on the right side.
1) Brake the wheel by pressing the brake pedal.
2) Release the brake by lifting up the brake pedal.
4.2 Lifting
Warning
1) Do not overload lift table. Stay within its rated capacity.
2) Do not side or end. Load must be distributed on at least 80% of table area.
Press the lifting pedal several times until the table reaches the desired position. The table does not
elevate after reaching the highest position even if the lifting pedal is pressed. The table lowers slightly
after reaching the highest position.
Model LT-1650SL LT-2200SL
Part Number 272970 272973
Max Capacity (lbs) 1,650 2,200
Note: The hydraulic cylinder is designed to hold the table. The nature of hydraulic systems cause the
table to lower very slowly over an extended period of time. Please note the table does not stay at the
same position indefinitely.
4.3 Lowering
Warning: Do not put foot or hand in scissors mechanism
1) Rotating the knob lowers the table.
5. MAINTENANCE
5.1 Lubricate each point described below every month
5.2 Change hydraulic oil every 12 months.
Lubricating Points
1) Fitting of Cylinder – Oil
2) Roller Friction Surface – Grease
3) Link Pin – Oil
4) Pedal Fitting Point – Oil
5) Grease Nipple - Grease
