Side 1/7
Page1of7
Note: Operator MUST read and understand these operating instructions before
using this Truck.
TABLE OF CONTENTS
1 General Information ......................................................................................................... 2
1.1 Description.............................................................................................................. 2
1.2 Specifications.......................................................................................................... 2
2 Safety Information.............................................................................................................. 2
3 Daily Inspection ................................................................................................................ 3
4 Operation........................................................................................................................... 3
4.1 Braking..................................................................................................................... 3
4.2 Lifting....................................................................................................................... 3
4.3 Lowering.................................................................................................................. 3
5 Maintenance...................................................................................................................... 3
6 Part Information................................................................................................................. 4
6.1 Frame Part Diagram................................................................................................ 4
6.2 Frame Part List........................................................................................................ 5
6.3 Pump Part Diagram................................................................................................. 6
6.4 Pump Part List......................................................................................................... 7
WESCOINDUSTRIALPRODUCTS,INC
InstructionManual
FoldingHandleScissorLiftTables
PartNumber: 272974
Page2of7

Folding Handle Scissor Lift Tables
(Part # 272974)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO SCISSOR LIFT
TABLE, READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
1. GENERAL INFORMATION
1.1 DESCRIPTION
Thank you for purchasing a Wesco Folding Handle Scissor Lift Table. This table is made of
high quality steel and is designed for horizontal lifting and transportation of loads on a level, fixed base.
For safe operation of this unit, please carefully read these instructions before use and keep it on file for
reference.
1.2 SPECIFICATIONS
Part Number 272974
Model Number LT-660FHSL
Capacity 660 lbs
Table Size 19.5” x 32”
Table Thickness .1”
Raised Height 35”
Lowered Height 14”
Caster Size 5” x 1.5”
Locking Caster (LC) Yes
Weight 170 lbs
Materials and specifications are subject to change without notice.
2. SAFETY INFORMATION
1) Read these instructions carefully before operation and get to know the performance and operation
requirements of the lift table.
2) Do not overload the hydraulic lift table. Overloading will cause damage to the hydraulic lift table.
3) It is forbidden for operators to stand or sit on the table during operation.
4) Do not insert hands or feet under the lowering table.
5) Brake the table when loading goods to prevent it from moving.
6) Off-set loading is forbidden when loading goods, goods should be distributed uniformly over the
table.
7) Loose or unstable goods are not permitted to be loaded.
8) The table can’t be moved when goods are being lifted.
9) The table can only be moved on flat and hard ground, do not use on sloped or rugged ground;
10) When putting goods on the table which has been hoisted, the weight of goods should be within rated
load.
Note: The safety valve only works in the hoisting process, if the table has been hoisted, and then has
overweight load on it, the safety valve will not work (also possibly damaging the unit).
11) When loading and unloading goods on hoisted table, don’t drag goods in cross direction, which may
cause serious off-set loading and make the table turn over.
12) When maintaining and repairing the table, the stand bar should be used to support fork arm in order
to prevent table from falling (there should be no load on the table).
Page3of7

3. DAILY INSPECTION
Daily inspection is an effective method to find any malfunctions or faults on the lift table. Check lift table
on the following points before operation.
1) Check for scratches, bending or cracking on the lift table.
2) Check for any oil leakage from the cylinder.
3) Check the vertical creep of the table.
4) Check for smooth movement of the wheels.
5) Check the function of brake.
6) Check to make sure all the bolts and nuts are tightened firmly.
4. OPERATION
4.1 Braking
CAUTION: Lift the brake when not moving it in order to prevent sudden movement.
The brake is equipped with the swivel caster on the right side.
1) Brake the wheel by pressing the brake pedal.
2) Release the brake by lifting up the brake pedal.
4.2 Lifting
Warning
1) Do not overload lift table. Stay within its rated capacity.
2) Do not side or end. Load must be distributed on at least 80% of table area.
Press the lifting pedal several times until the table reaches the desired position. The table does not
elevate after reaching the highest position even if the lifting pedal is pressed. The table lowers slightly
after reaching the highest position.
Model LT-660FHSL
Part Number 272974
Max Capacity (lbs) 660
Note: The hydraulic cylinder is designed to hold the table. The nature of hydraulic systems cause the
table to lower very slowly over an extended period of time. Please note the table does not stay at the
same position indefinitely.
4.3 Lowering
Warning: Do not put foot or hand in scissors mechanism
1) Rotating the knob lowers the table.
5. MAINTENANCE
5.1 Lubricate each point described below every month
5.2 Change hydraulic oil every 12 months.
Lubricating Points
1) Fitting of Cylinder – Oil
2) Roller Friction Surface – Grease
3) Link Pin – Oil
4) Pedal Fitting Point – Oil
5) Grease Nipple - Grease
Folding Handle Scissor Lift Tables
(Part # 272974)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO SCISSOR LIFT
TABLE, READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
