Table of Contents
1 Specifications.................................................................................................................... 2
2 Safety Information.............................................................................................................. 2
3 Operation........................................................................................................................... 2
4 Maintenance...................................................................................................................... 2
5 Part Information................................................................................................................. 3
5.1 Pump Part Diagram.......................,......................................................................... 3
5.2 Pump Part List......................................................................................................... 4
5.3 Frame Assembly Part Diagram..,............................................................................. 5
5.4 Frame Assembly Part List........................................................................................ 6
๎˜ƒ
WESCO๎˜ƒINDUSTRIAL๎˜ƒPRODUCTS,๎˜ƒINC
๎˜ƒ
Instruction๎˜ƒManual
Hydraulic๎˜ƒDie๎˜ƒTable๎˜ƒ
๎˜ƒ
Part๎˜ƒNumber: 273265๎˜ƒ
Note: Operator MUST read and understand these operating instructions before
using this Table.
Page๎˜ƒ2๎˜ƒof๎˜ƒ6๎˜ƒ
๎˜ƒ๎˜ƒ
๎˜ƒ
๎˜ƒ
๎˜ƒ
๎˜ƒ
๎˜ƒ
๎˜ƒ
Hydraulic Die Table
(Part # 273265)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO HYDRAULIC
TABLE, READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
1. SPECIFICATIONS
Part Number
273265
Model
DT-2436
Capacity
2,000 lbs
Table Size (L x W)
36โ€ x 24โ€
Table Thickness
.2โ€
Lowered Height
24.25โ€
Lifting Height
36โ€
Overall
Dimensions
Height
36.75โ€
Width
24โ€
Depth
49.5โ€
Wheel
Load Wheel Diameter
5โ€ x 1.5โ€
Steering Wheel Diameter
4.75โ€ x 1.5โ€
Weight
265 lbs
Materials and specifications are subject to change without notice.
2. SAFETY INFORMATION
1ใ€ Do not load the hydraulic table beyond its rated capacity (2,000 lbs).
2ใ€ Do not allow people to sit or ride on the hydraulic table.
3ใ€ Secure load before raising or lowering the hydraulic table.
4ใ€ Do not transport loads while the hydraulic table is in a raised position.
5ใ€ Use only on smooth surfaces.
6ใ€ Keep hands and feet clear when raising or lowering lift.
7ใ€ Press the small pedal slowly, to avoid dropping the load too quickly.
8ใ€ Failure to comply with the instructions and warnings in this manual may result in personal injury or
property damage.
3. OPERATION
1) Push the table to the area where desired for operation.
2) Engage the brake bar with hand to fix the table in place.
3) Press the big pedal and to raise the table.
4) Press the small release pedal and the table will lower slowly.
4. MAINTENANCE
1
ใ€
Lubricate each friction point monthly with a good, quality grease.
2
ใ€
Check the free movement and wear of wheels. Replace if needed.
3
ใ€
Check caster brake function. It should lock firmly and release completely.
4
ใ€
Check
for oil leakage from hydraulic cylinder.
Page๎˜ƒ3๎˜ƒof๎˜ƒ6๎˜ƒ
๎˜ƒ๎˜ƒ
๎˜ƒ
Hydraulic Die Table
(Part # 273265)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO HYDRAULIC
TABLE, READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
5. PART INFORMATION
5.1 PUMP PART DIAGRAM
๎˜ƒ
๎˜ƒ
41
99
101
40
44
10043
42
45
46
47
88
89
90
91
92
93
94
95
81
82
83
84
85
86
87
96
97
98
56
57
58
102
103
61
62
59
104
60
63
105
106
107
108
64
67
68
66
65
70
71
69
74
75
76
73
72
77
78
79
80
