REV 8 and REV 10
TM
Owner’s Manual & “Limited” Warranty
Technology Specifications:
Thank You for purchasing this Wet Sounds product. Wet Sounds marine audio products
represent the ultimate in high performance standards. The Revolution Series is specifically
engineered to withstand the rigorous marine environment. Utilizing the state of the art
acoustic engineering and three dimensional computer aided design, our “Revolution
Technology” represents the most advanced technologies available for wakeboard tower
speaker systems. The Revolution series also provides multiple fitment options from direct
cast mount to fixed clamp mount to our revolutionary (Patent Pending) stainless steel TC3
Quick Disconnect Swivel clamp.
Please take a moment to read the instruction manual before starting your installation. This
manual will explain the benefits of the technologies developed by Wet Sounds and will help
you understand the correct installation methods and use of this product. If you have any
questions or concerns please contact a certified Wet Sounds dealer. You may also contact
Wet Sounds technical support by dialing 1-877-WET-SPKR (1-877-938-7757)
SPEAKER SPECIFICATIONS REV 8
RMS: 200 watts
Peak: 400 watts
Mid Bass: 8 inch Kevlar reinforced EFG™ cone woofers with polyurethane surround
High Frequency: Pro-Axial™ Driver - Coaxially mounted Titanium Diaphragm High Output
Horn Loaded Compression Driver
Impedance: 4 ohm
Frequency Response: 20Hz to 20 kHz
Sensitivity: 92DB at 1W/1M
SPEAKER SPECIFICATIONS REV 10
RMS: 300 watts
Peak: 600 watts
Mid Bass: 10 inch Kevlar reinforced EFG™ cone woofers with polyurethane surround
High Frequency: Pro-Axial™ Driver - Coaxially mounted Titanium Diaphragm High Output
Horn Loaded Compression Driver
Impedance: 4 ohm
Frequency Response: 20Hz to 20 kHz
Sensitivity: 92DB at 1W/1M
The Revolution™ series uses our proprietary REV TEC™ technology. Unlike most
conventional designs, REV TEC technology provides remarkable volume and amazing full
range sound quality on axis and off axis at long distances. Extensive acoustic testing has
confirmed these speakers ability to project volume at 80 feet and beyond without any loss of
detail or information. Not only does the Revolution series achieve volume and sound quality
at a minimum of 80 ft, but with the REV TEC technology the rider can enjoy quality sound
while riding outside the wake and being almost parallel to boat. Taking high performance
wakeboard tower speakers to the next level, Wet Sounds has consulted with experts who
spent countless hours examining the human auditory system to find out which frequencies
affect your ears the most at loud volumes. The Revolution series has been designed from the
ground up to provide stunning output while eliminating certain frequencies that give that
“ringing” or harsh sound associated with loud volumes. This allows the Revolution speakers
to provide maximum output while still providing world class sound quality without the
listener fatigue usually associated with high volumes.
The driver compliment in each REV 8 combines one 8 inch Kevlar reinforced EFG™ driver
and one concentrically mounted HLCD (Horn Loaded Compression Driver). The driver
compliment in each REV 10 also combines one 10 inch Kevlar reinforced EFG™ driver and
one concentrically mounted HLCD (Horn Loaded Compression Driver) which provide stellar
performance and higher performance for the marine environment, Wet Sounds™ developed a
proprietary cone material called EFG™, which is an epoxy and fiberglass composite mix.
Adding a reinforcement of Kevlar, the mid bass cones become more rigid without any added
weight. This cone material incorporates characteristic values that are impermeable to
damage from intermittent Ultra Violet exposure and minimal moisture exposure. Like the
EFG™ cone material, the Polyurethane that is used for the surround will provide protection
against Ultra Violet exposure and moisture. This will prevent deterioration of the surround
yielding longer life and better reliability. We do, however, encourage you to either remove or
cover your tower speakers when they are not in use. Limiting exposure to Ultra Violet Rays
and to moisture will help extend the life of your tower speakers.
The high frequency transducer is our proprietary titanium Wet Sounds HLCD (horn loaded
compression driver). This driver was designed to provide a wide; horizontal trajectory that
would not only produce sound in the directed path but will disperse sound off axis with little
to no degradation. The HLCD is considered to be one of the most efficient transducer designs
providing remarkable output while using less power. Our unique (patent protected) design
incorporates the HLCD mounted to the rear of the mid bass driver. Our Pro-Axial™ design
allows the compression sound to travel through the voice coil former and out of the (patent
protected) horn flare that is mounted coaxially. This provides phenomenal volume and
accurate clarity.
***Caution: Do not spray any of the speakers directly with any liquid base substance.
Warranty will be voided if improper care is discovered during extensive examination of the
product.

Produkspesifikasjoner

Merke: Wet Sounds
Kategori: Høyttaler
Modell: REV 8
