Side 1/14
SPEAKER SYSTEM
SYSTÈME D’ENCEINTES
LAUTSPRECHERANLAGE
·›`n „¤t†˛
GTR
OWNER’S MANUAL
MODE D’EMPLOI
BEDIENUNGSANLEITUNG
¤ˇ¥˛»¡'œfi
NS-120
2
Thank you for selecting this YAMAHA NS-120 speaker system.
Read these precautions carefully before using your speaker.
●
Any time you note distortion, reduce the volume control on
your amplifier to a lower setting. Never allow your amplifier to
be driven into “clipping”. Otherwise the speaker may be
damaged.
●
When using an amplifier with a rated output power higher
than the nominal input power of the speaker, care should be
taken never to exceed the speaker’s maximum input.
●
Do not attempt to clean the speaker with chemical solvents
as this might damage the finish. To clean, wipe with a dry,
soft cloth.
●
To prevent the enclosure from warping or discoloring, do not
place the speaker where it will be exposed to direct sunlight
or excessive humidity.
●
Do not place the speaker where it is liable to be knocked
over or struck by falling objects. Stable placement will also
ensure better sound performance.
●
Secure placement or installation is the owner’s responsibility.
YAMAHA shall not be liable for any accident caused by
improper placement or installation of the speaker.
PRECAUTIONS
The speaker is constructed with the majority of the weight
located in its upper portion, and is thus susceptible to falling
over if proper care is not taken to insure its stability. If the
speaker falls over, it may damage the speaker or be the cause
of injury (or even death) to persons and/or damage to personal
property.
For safe and proper use of the speaker:
• Position the speaker in a location that is solid, level, smooth,
and low (with respect to the floor).
• Do not push or apply pressure to the side of the speaker
when moving, or lean objects against the side of the speaker.
• Do not sit on or set objects on top of the speaker.
Vibrations or jolts associated with earthquakes and other
phenomena or activities may cause the speaker to fall over.
For safety reasons, using commercially available products that
increase stability in the speaker is recommended (metal fittings
or chains, etc.).
PRECAUTIONS WHEN POSITIONING THE SPEAKERS
Use the stands included with the speakers to increase
stability:
●
Stands
Be sure to use the stands regardless of where the speakers
are positioned. Attaching the stands included with the
speakers reinforces the base of the speaker not to fall over.
Please be cautioned that even though the stands are
connected, this does not guarantee that the speakers will not
fall over.
English
3
■ Attaching the spike
When setting up the speakers on a thick carpet, use the spikes
instead of the stand. With 4 points set in place to achieve
increased stability and improvements in sound quality.
Procedure:
➀
Set the nut close to the tip of the spike and screw them
into the bottom of the speaker at each of the four specified
holes.
➁
Place the speaker in the desired location in an upright
position and adjust the length of the spike to match the
depth of the carpet.
➂
When adjustment is complete, twist the nut up to the base
of the speaker firmly.
Notes
●
The tips of the spikes may scratch or otherwise damage
the flooring. Please be careful when positioning the
speakers.
●
If force is applied to the side of the speaker, it may fall
and damage the speaker or cause personal injury.
Please be careful.
HOW TO USE THE ACCESSORIES INCLUDED WITH THE SPEAKERS
■ Attaching the stand
When positioning the speakers, be sure to use the stand to
increase stability.
Use the 8 specified holes located on the base of the speaker.
Procedure:
➀
Put the 6 mm screw through the larger hole on the stand,
and attach to the speaker at one of the outside holes on
the base of the speaker. At this time, attach the stand to
the speaker so that it can still be moved slightly.
➁
Put the 4 mm wood screw through the smaller hole on the
stand, and screw it into the inside hole on the base of the
speaker.
➂
When both screws have been attached, tighten both of the
screws so that the stand is firmly in place.
Be sure to check that the stand is firmly attached.
➃
Attach the pads to the bottom of the end portion of the
stand.
➄
Attach the other stands in the same manner and confirm
that all 4 stands have been firmly attached.
➅
Place the speaker in the desired location.
Note
If force is applied to the side of the speaker, it may fall and
damage the speaker or cause personal injury. Please be
careful.
Spike x 4
Pad x 4
Wood screw
(4 mm) x 4
Screw (6 mm) x 4
Stand x 4
