P-870M-I Series

VDSL2 Modem

User’s Guide

Version 1.00

Edition 1

5/2006

P-870M-Ix Series User’s Guide

1 Connections

Your P-870M-I Series (“P-870M-I”) is a VDSL2 modem.

VDSL2 provides high-speed Internet access up to 100 Mbits

per second (each way) through a telephone line. As a result,

your P-870M-I is an ideal modem for Triple Play services,

such as voice, video, high definition television (HDTV), and

interactive gaming.

The P-870M-I Series consists of the following models:

• P-870M-I1, a VDSL2 modem for regular (POTS) lines

• P-870M-I3, a VDSL2 modem for ISDN lines

Make the following connections to set up your P-870M-I.

P-870M-Ix Series User’s Guide

1Use a telephone wire to connect the P-870M-I DSL port to

the DSL (or MODEM) port on a splitter. If you do not have

a splitter, connect the DSL port directly to the telephone

jack.

2Use an Ethernet cable to connect the P-870M-I

ETHERNET port to the computer.

3Use the included power adaptor to connect the P-870M-I

POWER socket to an appropriate power source.

4After you’ve made these connections, push in the power

button.

If the POWER, ETHERNET, and VDSL lights are on (or

blinking), you have set up the P-870M-I correctly. Test your

Internet connection by visiting http://www.zyxel.com (or

another web site).

If the lights behave differently or if you cannot connect to the

Web site, make sure the connections are correct. If the lights

are still different, turn off the device, wait a few seconds, and

turn it on again. If the problem continues, contact your local

vendor.

Produkspesifikasjoner

Merke:	ZyXEL
Kategori:	Ruter
Modell:	P-870M-I3
Vekt:	275 g
Sertifisering:	FCC, EN, ANSI/UL, IEC
Type strømforsyning:	AC/DC
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
DC-inngangskontakt:	Ja
Relativ luftfuktighet under drift (H-H):	20 - 85
Nettverksgrensesnitt:	Raskt Ethernet
Videoopptaksgrensesnitt:	RJ-45/RJ-11
Intern:	Nei
Tilkoblingsdioder:	Ja
Modem (RJ-11)-porter:	1
Datalinkprotokoll:	VDSL2 (ITU G.993.1, ITU G.993.2)
Luftfuktighet, uvirksom:	20 - 95
