RGS Series

Rugged Switch Series

Version 1

Edition 3, 07/2019

Hardware and Web User’s Guide

Default Login Details

LAN IP Address

http://192.168.1.1

User Name

admin

Password

1234

IMPORTANT!

READ CAREFULLY BEFORE USE.

KEEP THIS GUIDE FOR FUTURE REFERENCE.

This is a User’s Guide for a series of products. Not all products support all firmware features.

Screenshots and graphics in this book may differ slightly from your product due to differences in your

product firmware or your computer operating system. Every effort has been made to ensure that the

information in this manual is accurate.

Related Documentation

• CLI Reference Guide

The CLI Reference Guide explains how to use the Command-Line Interface (CLI) to configure

the Switch.

Note: It is recommended you use the Web Configurator to configure the Switch.

• Web Configurator Online Help

Click the help icon in any screen for help in configuring that screen and supplementary

information.

• More Information

Go to support.Zyxel.com to find other information on the Switch.

[CONTENTS]

1. Preface ............................................................................................................................. 8

1.1 Scope ............................................................................................................................... 8

1.2 Audience .......................................................................................................................... 8

1.3 Safety Instructions ............................................................................................................ 8

1.4 Documentation Conventions ............................................................................................ 8

2. Overview ........................................................................................................................ 10

2.1 Faceplate ....................................................................................................................... 10

2.2 Front Panel Introduction .................................................................................................. 11

2.3 Top Panel Introduction .................................................................................................... 12

3. Quick Installation ............................................................................................................ 14

3.1 Mounting the RGS Series (DIN-Rail) .............................................................................. 14

3.2 Mounting the RGS Series (Wall mount) .......................................................................... 15

3.3 Ground Connections ...................................................................................................... 16

3.4 Connecting the Ethernet Interface (RJ45 Ethernet) ........................................................ 19

3.5 Connecting the Ethernet Interface (Fiber) ....................................................................... 20

3.6 Power Connection .......................................................................................................... 21

3.7 Console Connection ....................................................................................................... 22

3.8 System Reset ................................................................................................................. 23

3.9 Web Interface Initialization (Optional) ............................................................................. 23

3.10 CLI Initialization and Configuration (Optional) ................................................................. 25

3.11 Monitoring the Ethernet Interface ................................................................................... 26

3.12 Upgrade Software .......................................................................................................... 26

3.13 Reset to Default and Save Configure ............................................................................. 27

3.14 DIP Switch Setting for RGS100-5P ................................................................................ 30

3.15 LED Status Indications ................................................................................................... 30

4. Introduction .................................................................................................................... 32

4.1 System Description ........................................................................................................ 32

4.2 Using the Web Interface ................................................................................................. 32

4.2.1 Web Browser Support ....................................................................................... 32

4.2.2 Navigation ......................................................................................................... 33

4.2.3 Title Bar Icons ................................................................................................... 33

4.2.4 Ending a Session .............................................................................................. 33

4.3 Using the Online Help .................................................................................................... 34

5. Using the Web ................................................................................................................ 35

5.1 Login .............................................................................................................................. 35

5.2 Tree View ....................................................................................................................... 35

5.2.1 Configuration Menu ........................................................................................... 36

5.2.2 Monitor Menu .................................................................................................... 37

5.2.3 Diagnostics Menu .............................................................................................. 38

5.2.4 Maintenance Menu ............................................................................................ 38

5.3 Configuration .................................................................................................................. 39

5.3.1 System Information ........................................................................................... 39

5.3.2 System IP .......................................................................................................... 40

5.3.3 System NTP ...................................................................................................... 42

5.3.4 System Time ..................................................................................................... 42

5.3.5 System Log ....................................................................................................... 45

Produkspesifikasjoner

Merke:	ZyXEL
Kategori:	Bryter
Modell:	RGS100-5P
Vekt:	500 g
Bredde:	29.1 mm
Dybde:	107.3 mm
Høyde:	139 mm
Pakkevekt:	700 g
Strømforbruk (maks.):	125 W
Inngangsspenning:	12 - 58 V
Nettverksstandard:	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Auto MDI/MDI-X:	Ja
10G støtte:	Nei
Multicast-støtte:	Ja
Varmespredning:	42625 BTU/t
Auto-forhandling:	Ja
Jumbo rammer:	9000
DIN-skinnemontering:	Ja
Fiberoptisk kontakt:	SFP
Produktfarge:	Sort
Pakkedybde:	177.8 mm
Pakkehøyde:	205 mm
Pakkebredde:	70 mm
Driftstemperatur (T-T):	-40 - 75 °C
Oppbevaringstemperaturomåde (Celsius):	-40 - 85 °C
Lagringsrelativ fuktighet:	5 - 90
Harmonisert system (HS)-kode:	85176990
Kroppsmateriale:	Metall
Strømbeskyttelsesfunksjoner:	Kortslutning
Kan monteres på vegg:	Ja
Internasjonal beskyttelses (IP)-kode:	IP30
Ethernet-kobberkabelteknologi:	10BASE-T, 100BASE-TX, 1000BASE-T
Relativ luftfuktighet under drift (H-H):	5 - 95
Rack-montering:	Ja
Gjennomsnittstid mellom feil (MTBF):	568430 timer
Svitsjtype:	Uhåndtert
Antall Basic switching RJ-45 Ethernet-ports:	4
Basic switching RJ-45 Ethernet ports-type:	Gigabit Ethernet (10/100/1000)
Strømningskontroll støtte:	Ja
Størrelse på adressetabell:	2000 oppføringer
Ruting/svitsjekapasitet:	10 Gbit/s
Strøm over Ethernet (PoE):	Ja
Antall Power over Ethernet plus (PoE+)-ports:	4
Plugg inn og spill:	Ja
DC inngående spenning:	12 - 58 V
Jumbo Frames-støtte:	Ja
Full tosidig:	Ja
Veggmonterings sett:	Ja
Total Power over Ethernet (PoE)-budsjett:	120 W
Lagre-og-videresend:	Ja
Bufferminne pakke:	0.25 MB
Rack-montert sett:	Ja
SFP module antall spor:	1
MAC-adresse automatisk læring støttes:	Ja
Strømbryterbelegg:	L2
Ethernet-fiberkabelteknologi:	1000BASE-X
Gjennomstrømming:	7.44 Mpps
Overføringsavstand (maks.):	40 km
