Side 1/33

Arecont Vision MegaView

2 Installation Manual

Installation Manual

Wide Angle Models:

AV1225PMIR-S

AV2225PMIR AV2225PMIR-S

AV2225PMIR-A AV2225PMIR-SA

AV2226PMIR AV2226PMIR-S

AV3225PMIR AV3225PMIR-S

AV3226PMIR AV3226PMIR-S

AV3226PMIR-A AV3226PMIR-SA

AV5225PMIR AV5225PMIR-S

AV5225PMIR-A AV5225PMIR-SA

AV10225PMIR AV10225PMIR-S

Telephoto Models:

AV2225PMTIR AV2225PMTIR-S

AV2226PMTIR AV2226PMTIR-S

AV3225PMTIR AV3225PMTIR-S

AV3226PMTIR AV3226PMTIR-S

AV5225PMTIR AV5225PMTIR-S

AV10225PMTIR AV10225PMTIR-S

Telephoto Model Wide Angle Models

Arecont Vision MegaView

2 Installation Manual

Page | 2 support@arecontvision.com

MegaView

2 Installation

Contents

Contents ................................................................................................................................................................... 2

Package Contents ................................................................................................................................................... 3

Warranty Information .............................................................................................................................................. 4

Install MegaView

2 Camera ................................................................................................................................. 5

SD Card Installation ................................................................................................................................................ 8

Replacing the IR LED board: ................................................................................................................................. 9

Camera Discovery ................................................................................................................................................. 10

Web Interface Quick Guide .................................................................................................................................. 14

SD Card Functionality ........................................................................................................................................... 22

Electrical Box Adapter (SV-EBA) Installation Instructions (Sold Separately) .............................................. 25

Pole Mount Adapter (AV-PMA) Installation Instructions (Sold Separately) .................................................. 26

Corner Mount Adapter (AV-CRMA) Installation Instructions (Sold Separately) .......................................... 27

Installation Best Practices .................................................................................................................................... 30

LED Indicators (Camera Signal) ......................................................................................................................... 31

Support ................................................................................................................................................................... 32

Mounting Template ............................................................................................................................................... 33

Arecont Vision MegaView

2 Installation Manual

Page | 3 support@arecontvision.com

Package Contents

MegaView

2 Camera Package:

A. Arecont Vision MegaView

2 Camera

B. Junction box adapter

C. Mounting Template for Junction box adapter

D. Mounting Template for MegaView

2 Camera

E. CD with AV100 software and user manuals (license key required for recording)

F. Security L-key

G. Pack of four (4) screws and four (4) anchors

NOTE: Anchors and screws are good to be used for concrete, wall block and red bricks.

NOTE: Screws by themselves can be used in wood.

H. Rubber plug

I. Pack of four (4) machine screws, #8-32, ½” Phillips Pan Head

Image 1

Produkspesifikasjoner

Merke:	Arecont Vision
Kategori:	Sikkerhetskamera
Modell:	AV10225PMIR-S
Bruksanvisning:	Ja
Bluetooth:	Nei
Wi-Fi:	Nei
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	3648 x 2752 piksler
Strømkildetype:	PoE
Antall kameraer:	1
LED-type:	IR
Fokus:	Motorisert
Støttede nettverksprotokoller:	DHCP, QoS, IPv6
Dag/natt-modus:	Ja
Antall linser:	1
AC-inngangsspenning:	24 V
Bildefrekvens:	7 fps
Produktfarge:	Hvit
Monteringssett:	Ja
Minnekortenhet:	SDHC
Zoomfunksjon:	Ja
Innebygd kortleser:	Ja
Formfaktor:	Skjult
Modell/Type:	Overvåkningskamera
Bithastighetskontroll:	Konstant bithastighet (CBR)
Minimumsbelysning:	- lx
Ethernet/bredbåndsforbindelse:	Ja
Støttede plasseringer/plasseringer som kan benyttes:	Inne & Ute
Montasjetype:	Tak/Vegg
Totale megapiksler:	10 MP
DC-ut, volt:	12, 48
Privacy maske:	Ja
Videobasert bevegelsesdeteksjon:	Ja
Streaming-metode:	Multicast
