MS502/MX503

Digital Projector

User Manual

Table of contents2

Ta b l e o f c o nt e n t s

Important safety

instructions ........................... 3

Introduction.......................... 7

Projector features.....................................7

Shipping contents ......................................8

Projector exterior view...........................9

Controls and functions ..........................10

Positioning your

projector..............................13

Choosing a location................................13

Obtaining a preferred projected

image size..................................................14

Connection .........................15

Connecting video source devices........16

Operation............................17

Starting up the projector ......................17

Adjusting the projected image .............18

Using the menus......................................20

Securing the projector...........................21

Switching input signal .............................23

Magnifying and searching for details ...24

Selecting the aspect ratio ......................24

Optimizing the image .............................27

Setting the presentation timer.............30

Remote paging operations ....................31

Freezing the image ..................................31

Hiding the image......................................31

Locking control keys ..............................31

Operating in a high altitude

environment.............................................32

Adjusting the sound................................32

Shutting down the projector................33

Direct power off..................................... 33

Menu operation ...................................... 34

Maintenance........................ 43

Care of the projector............................ 43

Lamp information ................................... 44

Troubleshooting ................ 50

Specifications ...................... 51

Projector specifications......................... 51

Dimensions .............................................. 52

Ceiling mount installation..................... 52

Timing chart............................................. 53

Warranty and Copyright

information ......................... 55

Important safety instructions 3

Important safety instructions

Your projector is designed and tested to meet the latest standards for safety of information

technology equipment. However, to ensure safe use of this product, it is important that

you follow the instructions mentioned in this manual and marked on the product.

Safety Instructions

1. Please read this manual before

you operate your projector. Save

it for future reference.

2. Do not look straight at the

projector lens during operation.

The intense light beam may damage

your eyes.

3. Refer servicing to qualified

service personnel.

4. Always open the lens shutter (if

any) or remove the lens cap (if

any) when the projector lamp is

on.

5. In some countries, the line voltage is

NOT stable. This projector is

designed to operate safely within a

mains voltage between 100 to 240

volts AC, but could fail if power cuts

or surges of ±10 volts occur. In

areas where the mains voltage

may fluctuate or cut out, it is

recommended that you connect

your projector through a power

stabilizer, surge protector or

uninterruptible power supply

(UPS).

6. Do not block the projection lens with

any objects when the projector is

under operation as this could cause

the objects to become heated and

deformed or even cause a fire. To

temporarily turn off the lamp, press

ECO BLANK on the projector or

remote control.

Produkspesifikasjoner

Merke:	BenQ
Kategori:	videoprosjektor
Modell:	MS502
Produkttype:	Standard stråleprojektor
Innebygd skjerm:	Nei
Vekt:	2300 g
Bredde:	287.3 mm
Dybde:	232.6 mm
Høyde:	114.4 mm
Støynivå:	33 dB
Strømkilde:	AC
Bruksanvisning:	Ja
Bluetooth:	Nei
Plassering:	Desktop
Wi-Fi:	Nei
USB-kontakttype:	Mini-USB B
Antall farger:	1.073 milliarder farger
Antall USB 2.0-porter:	1
DVI-port:	Nei
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	1
Full HD:	Nei
HDCP:	Nei
3D:	Ja
On Screen Display (OSD):	Ja
Horisontal synkronisering (min):	31 kHz
Vertikal synkronisering (min):	23 kHz
Kontrastforhold:	13000:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Strømforbruk (standby):	0.5 W
Projektorens lysstyrke:	2700 ANSI lumen
Projektoroppløsning:	SVGA (800x600)
Produktfarge:	Grå
Støttede grafikkoppløsninger:	1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Analogt signalformatsystem:	NTSC, PAL, SECAM
Kabler inkludert:	AC, VGA
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	40 - 300 "
Projeksjonsavstand:	- m
Hjørnesteinsrettelse, vertikal:	-40 - 40 °
Horisontalt frekvensområde:	31 - 102 kHz
Støynivå (økonomisk funksjon):	26 dB
Brennviddeområde:	21 - 23.1 mm
RS-232-port:	1
Lyskildens tjenestetid:	4500 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	275 W
Støttede videofunksjoner:	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Antall VGA (D-Sub)-porter:	3
Lydinngang (V/H) inn:	1
Strøminngang/AC (strøm) inn:	Ja
Seriell grensesnittype:	RS-232
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
forskyvning:	120
Antall S-Video-innganger:	1
Ethernet/bredbåndsforbindelse:	Nei
Komposittvideo inn/sammensatt video inn:	1
Lydutgang (venstre/høyre):	1
RMS-rangert strøm/utgangseffekt:	2 W
Batterier medfølger:	Ja
Horisontal synkronisering (maks):	102 kHz
Vertikal synkronisering (maks):	120 kHz
Lampens effekt:	190 W
Lyskildens tjenestetid (økonomisk modus):	6500 timer
Blenderåpning rekkevidde:	2.56 - 2.8
Projeksjonsfaktor:	1.86 - 2.04:1
Størrelseforhold:	4:3
Vertikal scanningsratio:	23 - 120 Hz
Zoom-forhold:	1.1:1
