Digital Projector

MS513/MX514/MW516

Table of contents2

Ta b l e o f c o n t e n t s

Important safety

instructions ................... 3

Introduction.................. 7

Projector features.....................................7

Shipping contents ......................................8

Projector exterior view...........................9

Positioning your

projector ..................... 15

Choosing a location................................15

Obtaining a preferred projected image

size..............................................................16

Connection ................. 19

Connecting a computer or monitor...20

Connecting Video source devices.......21

Operation ................... 25

Starting up the projector ......................25

Adjusting the projected image .............26

Using the menus......................................29

Securing the projector...........................30

Switching input signal .............................33

Magnifying and searching for details ...34

Selecting the aspect ratio ......................34

Optimizing the image .............................36

Creating your own startup screen......39

Setting the presentation timer .............40

Remote paging operations ....................41

Hiding the image......................................42

Freezing the image ..................................42

Operating in a high altitude environment

.....................................................................43

Adjusting the sound................................43

Use Teaching Template .........................44

Personalizing the projector menu display

.................................................................... 45

Select the lamp saver mode.................45

Shutting down the projector ............... 46

Menu operation ...................................... 47

Maintenance ............... 59

Care of the projector............................ 59

Lamp information ................................... 60

Troubleshooting......... 66

Specifications.............. 67

Dimensions .............................................. 68

Ceiling mount installation ..................... 68

Timing chart............................................. 69

Warranty and Copyright

information................. 72

Important safety instructions 3

Important safety instructions

Your projector is designed and tested to meet the latest standards for safety of information

technology equipment. However, to ensure safe use of this product, it is important that

you follow the instructions mentioned in this manual and marked on the product.

Safety Instructions

1. Please read this manual before

you operate your projector. Save

it for future reference.

2. Do not look straight at the

projector lens during operation.

The intense light beam may damage

your eyes.

3. Refer servicing to qualified

service personnel.

4. Always open the lens shutter or

remove the lens cap when the

projector lamp is on.

5. In some countries, the line voltage is

NOT stable. This projector is

designed to operate safely within a

mains voltage between 100 to 240

volts AC, but could fail if power cuts

or surges of ±10 volts occur. In

areas where the mains voltage

may fluctuate or cut out, it is

recommended that you connect

your projector through a power

stabilizer, surge protector or

uninterruptible power supply

(UPS).

6. Do not block the projection lens with

any objects when the projector is

under operation as this could cause

the objects to become heated and

deformed or even cause a fire.
