Digital Projector

MP780 ST+/MW860USTi

Table of contents2

Ta b l e o f c o n t e n t s

Important safety

instructions ................... 3

Introduction.................. 7

Projector features.....................................7

Shipping contents ......................................8

Projector exterior view.........................10

Controls and functions ..........................11

Positioning your

projector ..................... 16

Choosing a location................................16

Obtaining a preferred projected image

size..............................................................17

Connection ................. 21

Connecting a computer or monitor...23

Connecting Video source devices.......26

Operation ................... 30

Starting up the projector ......................30

Adjusting the projected image .............32

Using the menus......................................34

Securing the projector...........................35

Switching input signal .............................37

Magnifying and searching for details ...38

Optimizing the image .............................40

Creating your own startup screen......44

Setting the presentation timer .............45

Remote paging operations ....................46

Hiding the image......................................46

Utilizing FAQ function ...........................47

Locking control keys ..............................47

Operating in a high altitude

environment.............................................48

Adjusting the sound................................48

Personalizing the projector menu

display........................................................ 49

Controlling the projector through a LAN

environment.............................................50

Displaying image through Q Presenter ..

.................................................................... 60

Using the Web Control Lock.............. 64

Using the Projection Login Code ....... 64

Presenting From a USB Reader...........65

Remote Desktop Control through Q

Presenter .................................................. 68

PointDraw™ Pen 2.0............................. 70

Shutting down the projector ............... 75

Menu operation ...................................... 76

Maintenance ............... 90

Care of the projector............................ 90

Lamp information ................................... 91

Troubleshooting......... 97

Specifications.............. 98

Dimensions .............................................. 99

Ceiling mount installation ...................100

Timing chart...........................................101

Warranty and Copyright

information............... 104

Important safety instructions 3

Important safety instructions

Your projector is designed and tested to meet the latest standards for safety of information

technology equipment. However, to ensure safe use of this product, it is important that

you follow the instructions mentioned in this manual and marked on the product.

Safety Instructions

1. Please read this manual before

you operate your projector. Save

it for future reference.

2. Do not look straight at the

projector lens during operation.

The intense light beam may damage

your eyes.

3. Refer servicing to qualified

service personnel.

4. Always open the lens shutter or

remove the lens cap when the

projector lamp is on.

5. In some countries, the line voltage is

NOT stable. This projector is

designed to operate safely within a

mains voltage between 100 to 240

volts AC, but could fail if power cuts

or surges of ±10 volts occur. In

areas where the mains voltage

may fluctuate or cut out, it is

recommended that you connect

your projector through a power

stabilizer, surge protector or

uninterruptible power supply

(UPS).

6. Do not block the projection lens with

any objects when the projector is

under operation as this could cause

the objects to become heated and

deformed or even cause a fire.

Produkspesifikasjoner

Merke:	BenQ
Kategori:	videoprosjektor
Modell:	MW860USTi
Innebygd skjerm:	Nei
Vekt:	4100 g
Bredde:	330 mm
Dybde:	278 mm
Høyde:	154 mm
Støynivå:	27 dB
Strømkilde:	AC
Bruksanvisning:	Ja
USB-kontakttype:	USB Type-A, USB Type-B
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Pakkevekt:	6200 g
Antall farger:	1.073 milliarder farger
Antall USB 2.0-porter:	4
Antall HDMI-porter:	1
DVI-port:	Nei
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	2
Full HD:	Nei
HDCP:	Nei
3D:	Ja
Lydutgang:	1
Støyreduksjon:	Ja
On Screen Display (OSD):	Ja
Forhåndsinnstilte moduser:	Cinema, Dynamic, Presentation, sRGB
Dimensjoner (B x D x H):	330 x 278 x 154 mm
Kontrastforhold:	2600:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Strømforbruk (standby):	1 W
Projektorens lysstyrke:	3000 ANSI lumen
Projektoroppløsning:	WXGA (1280x800)
Støttede bildeformater:	BMP, GIF, JPG, PNG, TIF
Produktfarge:	Black, White
Støttede grafikkoppløsninger:	1280 x 800 (WXGA), 1600 x 1200 (UXGA), 640 x 480 (VGA)
Analogt signalformatsystem:	NTSC, PAL, SECAM
Kabler inkludert:	AC, VGA
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	60 - 300 "
Projeksjonsavstand:	- m
Hjørnesteinsrettelse, vertikal:	±40 °
Horisontalt frekvensområde:	31 - 102 kHz
Støynivå (økonomisk funksjon):	25 dB
Brennviddeområde:	5.45 mm
RS-232-port:	1
Lyskildens tjenestetid:	2500 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	310 W
Støttede videofunksjoner:	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Antall VGA (D-Sub)-porter:	3
Lydinngang (V/H) inn:	1
Mikrofon, linje-inn-støpsel:	Ja
Strøminngang/AC (strøm) inn:	Ja
Seriell grensesnittype:	RS-232
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
OSD-språk:	BUL, CHI (SIMPL), CHI (TR), CZE, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR
Antall S-Video-innganger:	1
Ethernet/bredbåndsforbindelse:	Ja
Komposittvideo inn/sammensatt video inn:	1
RMS-rangert strøm/utgangseffekt:	20 W
Lampens effekt:	225 W
Lyskildens tjenestetid (økonomisk modus):	4000 timer
Projeksjonsfaktor:	0.37 - 0.78:1
Størrelseforhold:	16:10
Kabellåsport:	Ja
Vertikal scanningsratio:	23 - 120 Hz
Kabellåstype:	Kensington
Lydkontakter:	1
Zoom-forhold:	Fiksert
Videoformat som støttes:	M-JPEG
3D Ready:	Ja
