Side 1/15

I N S T A L L A T I O N I N S T R U C T I O N S

Instrucciones de instalación

Installationsanleitung

Instruções de Instalação

Istruzioni di installazione

Installatie-instructies

Instructions d´installation

K4G210

K4G310

Kontour™ Articulating Array Arm Grommet Series

Spanish Product Description

German Product Description

Portuguese Product Description

Italian Product Description

Dutch Product Description

French Product Description

K4G210-310

K4G210-310 Installation Instructions

DISCLAIMER

Milestone AV Technologies and its affiliated corporations and

subsidiaries (collectively “Milestone”), intend to make this

manual accurate and complete. However, Milestone makes no

claim that the information contained herein covers all details,

conditions or variations, nor does it provide for every possible

contingency in connection with the installation or use of this

product. The information contained in this document is subject

to change without notice or obligation of any kind. Milestone

makes no representation of warranty, expressed or implied,

regarding the information contained herein. Milestone assumes

no responsibility for accuracy, completeness or sufficiency of

the information contained in this document.

Chief® is a registered trademark of Milestone AV Technologies.

IMPORTANT SAFETY INSTRUCTIONS

WARNING: A WARNING alerts you to the possibility of

serious injury or death if you do not follow the instructions.

CAUTION: A CAUTION alerts you to the possibility of

damage or destruction of equipment if you do not follow the

corresponding instructions.

WARNING: Failure to read, thoroughly understand, and

follow all instructions can result in serious personal injury,

damage to equipment, or voiding of factory warranty! It is the

installer’s responsibility to make sure all components are

properly assembled and installed using the instructions

provided.

WARNING: Failure to provide adequate structural strength

for this component can result in serious personal injury or

damage to equipment! It is the installer’s responsibility to

make sure the structure to which this component is attached

can support five times the combined weight of all equipment.

Reinforce the structure as required before installing the

component.

WARNING: Exceeding the weight capacity can result in

serious personal injury or damage to equipment! It is the

installer’s responsibility to make sure the combined weight of

all components located on the K4G210-310 mounts up to

(and including) the display does not exceed 15 lbs (6.8 kg)

per display.

WARNING: Use this mounting system only for its intended

use as described in these instructions. Do not use

attachments not recommended by the manufacturer.

WARNING: Never operate this mounting system if it is

damaged. Return the mounting system to a service center for

examination and repair.

WARNING: Do not use this product outdoors.

--SAVE THESE INSTRUCTIONS--

Installation Instructions K4G210-310

DIMENSIONS

7.13

181.1

16.20

411.5

EXTENSION

15.28

388.2

+ 3.00 [76.2]

- 3.75 [95.3]

37.13

943.2

MAX DISTANCE

7.11

180.7

2.27

57.6

20° MAX

ANGLE

TILT ADJUSTMENT

±12°

TILT ADJUSTMENT

VESA

100 X 100

75 X 75

COMPATIBLE

INTERFACES

7.74

196.7

4.94

125.5

MAX

SURFACE

DEPTH

K4G210

15.22

386.6

+ 3.00" [76.2]

- 3.75" [95.3]

612.7

24.12

48.36

1228.4

MAX DISTANCE

16.20

411.5

EXTENSION

57.6

2.27

180.7

7.11

181.6

7.15

13.34

338.8

TILT ADJUSTMENT

±12°

TILT ADJUSTMENT

±12°

VESA

100 X 100

75 X 75

COMPATIBLE

INTERFACES

125.5

MAX

SURFACE

DEPTH

4.94

7.74

196.7

20° MAX

ANGLE

K4G310

Produkspesifikasjoner

Merke:	Chief
Kategori:	Flatpanelstøtte
Modell:	K4G210B
Antall skjermer som støttes:	2
Maksimal skjermstørrelse:	24 "
Minimum skjermstørrelse:	10 "
Produktfarge:	Sort
Vippevinkelområde:	-12 - 12 °
Harmonisert system (HS)-kode:	85299097
Svingvinkel:	-20 - 20 °
Montasjetype:	Bord
Maksimalvekt (kapasitet):	6.8 kg
Justerbar:	Ja
Monteringsgrensesnitt, kompatibilitet (min):	75 x 75 mm
Monteringsgrensesnitt, kompatibilitet (maks):	100 x 100 mm
