Pitch-Adjustable (TPP) Mount

BEFORE YOU BEGIN

• WARNING: TO PREVENT PERSONAL INJURY, THOROUGHLY STUDY ALL INSTRUCTIONS AND ILLUS-

TRATIONS BEFORE YOU BEGIN TO INSTALL THE UNIT. PAY PARTICULAR ATTENTION TO THE “IMPOR-

TANT WARNINGS AND CAUTIONS” ON PAGE 1.

• CAUTION: To prevent damage to the mount, which could affect or void the Factory warranty, thoroughly

study all instructions and illustrations before you begin to install the unit. Pay particular attention to the

“IMPORTANT WARNINGS AND CAUTIONS” on Page 1.

• The maximum weight to be installed on the TPP is 150 pounds (68.04 Kg).

• If you have any questions about this assembly, contact Chief Manufacturing at 1-800-582-6480 or 952-582-6480.

I N S T R U C T I O N M A N U A L

The Truss Pitch-Adjustable (TPP) mount is a perfect

solution exhibit, retail and digital signage applications.

The mount is quick, easy and versatile.

The TPP accommodates a large range of truss dimen-

sions (up to 14” O.D.), includes security options and pro-

vides flexible feature to achieve a custom installation

installation. The exclusive Q-Latch™ Mounting System

secures the LArge Flat Panel Display with a lockable

latch to confirm mount stability and integrated security

allows the display to be locked to the mount by adding a

padlock.

Your display can be mounted portrait or landscape and

four pitch adjustments, up or down, are available as pre-

set, locking positions (0, 5, 10 or 15 degrees).

LOGO

CHIEF MANUFACTURING INC.

1-800-582-6480 952-894-6280 FAX 952-894-6918

8401 EAGLE CREEK PARKWAY

SAVAGE, MINNESOTA 55378 USA

PART NO. 8804-000010 (Rev. B)

www.chiefmfg.com

Printed in USA 05-04
