INSTALLATION INSTRUCTIONS

ИНСТРУКЦИИ ПО УСТАНОВКЕ

Instrucciones de instalación

Installationsanleitung

Istruzioni di installazione

Installatie-instructies

MSA

MTA

FUSION MEDIUM FLAT PANEL MOUNTS

MSA/MTA Series

MSA/MTA Series Installation Instructions

DISCLAIMER

Milestone AV Technologies, and its affiliated corporations and

subsidiaries (collectively "Milestone"), intend to make this

manual accurate and complete. However, Milestone makes no

claim that the information contained herein covers all details,

conditions or variations, nor does it provide for every possible

contingency in connection with the installation or use of this

product. The information contained in this document is subject

to change without notice or obligation of any kind. Milestone

makes no representation of warranty, expressed or implied,

regarding the information contained herein. Milestone assumes

no responsibility for accuracy, completeness or sufficiency of

the information contained in this document.

Chief® is a registered trademark of Milestone AV Technologies.

IMPORTANT WARNINGS AND

CAUTIONS!

WARNING: A WARNING alerts you to the possibility of

serious injury or death if you do not follow the instructions.

CAUTION: A CAUTION alerts you to the possibility of

damage or destruction of equipment if you do not follow the

corresponding instructions.

WARNING: Failure to read, thoroughly understand, and

follow all instructions can result in serious personal injury,

damage to equipment, or voiding of factory warranty! It is the

installer’s responsibility to make sure all components are

properly assembled and installed using the instructions

provided.

WARNING: Failure to provide adequate structural strength

for this component can result in serious personal injury or

damage to equipment! It is the installer’s responsibility to

make sure the structure to which this component is attached

can support five times the combined weight of all equipment.

Reinforce the structure as required before installing the

component. The wall to which the mount is being attached

may have a maximum drywall thickness of 5/8" (1.6cm).

WARNING: Exceeding the weight capacity can result in

serious personal injury or damage to equipment! It is the

installer’s responsibility to make sure the combined weight of

all components located between the MSA/MTA up to (and

including) the display does not exceed 125 lbs (56.7 kg) for

dual stud attachment and concrete, and 75 lbs (34.0 kg) for

single stud attachment.

Installation Instructions MSA/MTA Series

DIMENSIONS

12.00 304.8

9.58 243.4

.75 19.1

1.50 38.1

25.57 649.5

18.75 476.2

1.50 38.1

.34 8.6

11.00 279.4

16.00 406.4

8.00 203.2

13.50 342.9

4.83 122.6

12°

1.40 35.5

1.06 27

.32

8.1

.38

9.5

16.50

419.1

.45 11.5

1.97 50

2.42 61.5

3.94 100

4.39

111.5

5.91 150

6.36

161.5

7.87 200

.45 11.5

1.97 50

2.42 61.5

3.94

NOTES:

MAX MOUNTING PATTERN IS 22"[558.8mm] WITHOUT REVERSING UPRIGHTS.

MAX MOUNTING PATTERN IS 26.5"[673.1mm] WITH REVERSING UPRIGHTS.2.

FOR RECESSED APPLICATIONS, MINIMUM VERTICAL LIFT FOR HOOK 3.

ENGAGEMENT IS .56"[14.2mm].

MOUNT RAILS CAN BE SLID LEFT OR RIGHT FOR OFFSET APPLICATIONS.4.

MOUNT IS 1.99"[50.5mm] DEEP WHEN FLAT TO WALL.

MTA

DIMENSIONS: [MILLIMETERS]

INCHES

25.57 649.5

18.75 476.2

.75 19.1

1.50 38.1

.34 8.6

9.58 243.4

11.00 279.4 13.50 342.9

16.00 406.4

8.00 203.2

1.96 49.8

13.50 342.9

16.78 426.1

.32

8.1

.38

9.6

.65

16.5

.98 25

.49

12.5

1.97 50

2.46

62.5

3.94 100

4.43

112.5

5.91 150

6.40

162.5

7.87 200

.49 12.5

1.97 50

2.46 62.5

3.94

NOTES:

MAX MOUNTING PATTERN IS 22.9"[581.6mm] WITHOUT REVERSING UPRIGHTS.

MAX MOUNTING PATTERN IS 25.5"[647.7mm] WITH REVERSING UPRIGHTS.2.

FOR RECESSED APPLICATIONS, MINIMUM VERTICAL LIFT FOR HOOK 3.

ENGAGEMENT IS .56"[14.2mm].

MOUNT RAILS CAN BE SLID LEFT OR RIGHT FOR OFFSET APPLICATIONS.4.

MOUNT IS 1.96"[49.8mm] DEEP WHEN FLAT TO WALL.

DIMENSIONS: [MILLIMETERS]

INCHES

MSA

Produkspesifikasjoner

Merke:	Chief
Kategori:	Flatpanelstøtte
Modell:	MSA3029
Bredde:	646 mm
Dybde:	50 mm
Høyde:	343 mm
Sertifisering:	UL
Maksimal skjermstørrelse:	47 "
Minimum skjermstørrelse:	26 "
Produktfarge:	Sort
Montasjetype:	Vegg
Maksimalvekt (kapasitet):	56.7 kg
Antall medfølgende produkter:	1 stykker
Monteringsgrensesnitt, kompatibilitet (min):	100 x 100 mm
Monteringsgrensesnitt, kompatibilitet (maks):	100 x 100 mm
