Corsair K83 Bruksanvisning

Corsair Tastatur K83

Les nedenfor 📖 manual på norsk for Corsair K83 (39 sider) i kategorien Tastatur. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/39

K83 WIRELESS

corsair.com/downloads

B E T�ER

TOG ETHE R

WEB: corsair.com

PHONE: (888) 222-4346

SUPPORT: support.corsair.com

BLOG: corsair.com/blog

FORUM: forum.corsair.com

YOUTUBE: youtube.com/corsairhowto

logo are registered trademarks in the United States and/or other countries. All other

trademarks are the property of their respective owners. Product may vary slightly

from those pictured. 49-001681 AB

ENTERTAINMENT KEYBOARD

ENGLISH ...................................................... 1

FRANÇAIS .................................................... 7

DEUTSCH ................................................... 13

ITALIANO .................................................... 19

ESPAÑOL ................................................... 25

PORTUGUÊS.............................................. 31

POLSKI ....................................................... 37

PУССКИЙ ..................................................... 43

日本語 .......................................................... 49

繁體中文 ...................................................... 55

简体中文 ...................................................... 61

한국어 ......................................................... 67

1 2

Ultra-fast 2.4GHz wireless is designed for gaming and other high-performance applications.The K83 Wireless Entertainment Keyboard offers the latest in living room media control. Reﬁned

aluminum design with white backlighting compliments any setup, while the integrated joystick and

touchpad make navigating menus and playing games smooth and intuitive. Connect to your PC via

ultra-fast 2.4GHz wireless, or to popular streaming media players and mobile devices via Bluetooth

wireless. Combining stylish design with the latest in living room control, the K83 gives you a front

row seat to your media.

CONGRATULATIONS!

READ THIS FIRST – POWER AND CHARGING

SETTING UP BLUETOOTH

WIRELESS FOR WINDOWS

OR ANDROID

™

SETTING UP 2.4GHz WIRELESS FOR WINDOWS

USB WIRED MODE FOR WINDOWS

The K83 must be fully charged before its ﬁrst use. Connect the K83 to an available USB 2.0 or 3.0 port

on your PC with the USB charging / data cable until the status LED turns solid green.

Bluetooth wireless is great for typing, navigation, and media playback control.

While the K83 is connected to your PC and charging, it will automatically enter USB wired mode.

You can switch to a wireless mode at any time.

*Rechargeable batteries have a limited life

STATUS LED INDICATOR

SOLID GREEN

PULSING GREEN

BATTERY STATUS

CHARGED

CHARGING

LOW

CRITICALPULSING RED

SOLID RED

ENGLISH

Visit www.corsair.com/K83-FAQ for advanced functionality and device compatibility.

> Connect the keyboard to a USB 3.0 or 3.1 (Type-A) port on a PC running iCUE for the fastest

charging speed

> The status LED indicator will change to signal battery status when the keyboard is turned on,

charging, charged, or low on power

> Reducing brightness, unplugging power when charged, and not leaving the battery

discharged for long periods of time will help to maximize battery life*

> Turn on the keyboard by pressing the power button

> Connect the USB wireless receiver to an available front panel USB 2.0 or 3.0 port on your PC

> The status LED indicator will turn solid white when connected

If reconnection is required, initiate USB wireless receiver pairing via the iCUE software settings menu

and hold FN + F5 on the keyboard for 2 seconds.

IMPORTANT: If the 2.4GHz connection isn’t automatic, move the USB wireless receiver to a

different front panel USB port and away from devices that may cause interference including

other USB wireless adapters, wireless networking equipment, and USB storage devices

such as ﬂash drives.

> Initiate Bluetooth pairing mode on your Bluetooth 4.0 or higher enabled product

> Hold FN + F6 on the keyboard until the status LED indicator rapidly blinks blue

> Input the code from your Bluetooth product on the keyboard and press the Enter key

> The status LED indicator will turn solid blue when connected

The K83 has two Bluetooth keys (F6 and F7) allowing you to remember and easily switch between more

than one Bluetooth host device.

KEY

CONNECTIVITY MODE

2.4GHz WIRELESS

BLUETOOTH WIRELESS 1

BLUETOOTH WIRELESS 2

USB WIRED (AUTO)

STATUS LED INDICATOR

WHITE

BLUE

CYAN

YELLOW

Produkspesifikasjoner

Merke:	Corsair
Kategori:	Tastatur
Modell:	K83
Baklys:	Ja
Bruksanvisning:	Ja
Bluetooth-versjon:	4.2
Strømkildetype:	Battery, USB
Anbefalt bruk:	Universell
Numerisk tastatur:	Nei
Trådløst mottakergrensesnitt:	USB Type-A
Tastaturvekt:	480 g
Batteriteknologi:	Lithium Polymer (LiPo)
Multimedietaster:	Ja
Tastaturbatteritype:	Innebygd batteri
Rollover:	20-key rollover
Produktfarge:	Black, Grey
Batteriliv (maks.):	40 timer
Tastaturspråk:	Tysk
Tastaturstil:	Rett
Mus inkludert:	Nei
Tastaturlayout:	QWERTZ
Antall medfølgende produkter:	1 stykker
Frekvensbånd og driftskanaler:	2.4 GHz
Prøvingshastighet:	1000 Hz
Fargebehandling overflate:	Monokromatisk
Mottaker medfølger:	Ja
Tastaturets formfaktor:	Mini
Håndleddshvilepute:	Nei
Pekeenhet:	Touchpad + pekestokk
Antall taster:	78
