Side 1/24

Vari-focal Dome Network Camera

Quick Start Guide

V1.0.1

ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD

Table of Contents II

Foreword

General

This Quick Start Guide (hereinafter referred to be "the Guide") introduces the functions,

installation and operations of the camera.

Safety Instructions

The following categorized signal words with defined meaning might appear in the guide.

Signal Words

Meaning

Indicates a medium or low potential hazard which, if not avoided,

could result in slight or moderate injury.

Indicates a potential risk which, if not avoided, may result in

property damage, data loss, lower performance, or unpredictable

result.

Provides additional information as the emphasis and supplement

to the text.

Revision History

No.

Version

Revision Content

Release Date

V1.0.0

First release.

2018.03

V 1.0.1

Add structural component figure and alarm port

description

2018.08

Privacy Protection Notice

As the device user or data controller, you might collect personal data of others such as face,

fingerprints, car plate number, Email address, phone number, GPS and so on. You need to be

in compliance with the local privacy protection laws and regulations to protect the legitimate

rights and interests of other people by implementing measures include but not limited to:

providing clear and visible identification to inform data subject the existence of surveillance

area and providing related contact.

About this Guide

 The Guide is for reference only. If there is inconsistency between the Guide and the actual

product, the actual product shall prevail.

 We are not liable for any loss caused by the operations that do not comply with the Guide.

 The Guide would be updated according to the latest laws and regulations of related

regions. For detailed information, see the paper manual, CD-ROM, QR code or our official

Table of Contents III

website. If there is inconsistency between paper manual and the electronic version, the

electronic version shall prevail.

 All the designs and software are subject to change without prior written notice. The product

updates might cause some differences between the actual product and the Guide. Please

contact the customer service for the latest program and supplementary documentation.

 There still might be deviation in technical data, functions and operations description, or

errors in print. If there is any doubt or dispute, please refer to our final explanation.

 Upgrade the reader software or try other mainstream reader software if the Guide (in PDF

format) cannot be opened.

 All trademarks, registered trademarks and the company names in the Guide are the

properties of their respective owners.

 Please visit our website, contact the supplier or customer service if there is any problem

occurred when using the device.

 If there is any uncertainty or controversy, please refer to our final explanation.

Produkspesifikasjoner

Merke:	Dahua Technology
Kategori:	Sikkerhetskamera
Modell:	DH-IPC-HDBW5442E-ZE
Vekt:	950 g
Høyde:	117.9 mm
Bluetooth:	Nei
Wi-Fi:	Nei
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	2688 x 1520 piksler
Videokomprimeringsformater:	H.264, H.265, M-JPEG
Diameter:	159 mm
Strømkildetype:	AC, DC, PoE
Antall kameraer:	1
LED-type:	IR
Pakkevekt:	1200 g
Fokus:	Motorisert
Strømforbruk (maks.):	12.4 W
Sertifisering:	CE-LVD: EN60950-1\nCE-EMC: Electromagnetic Compatibility Directive\n2014/30/EU\nFCC: 47 CFR FCC Part 15, Subpart B\nUL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
Bildestabilisator:	Ja
Internminne:	1000 MB
Nettleser:	Ja
Støyreduksjon:	Ja
Nettverksstandard:	IEEE 802.3af
Antall brukere:	20 bruker(e)
Støttede nettverksprotokoller:	IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP ;RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP ;NTP;Multicast;ICMP;IGMP;NFS;PPPoE;802.1x;SNMP
ROM-kapasitet:	128 MB
Progressiv skanning:	Ja
Rotasjonsvinkel:	355 °
Dag/natt-modus:	Ja
Antall linser:	1
Antall sensorer:	1
Videostreaming:	Ja
Wide Dynamic Range (WDR):	Ja
AC-inngangsspenning:	24 V
Linsesynsvinkel, horisontal:	114 °
Lydinngangskanaler:	1 kanaler
Støyreduksjonsteknologi:	3D-støyreduksjon
Linsesynsvinkel, vertikal:	62 °
Smart IR:	Ja
Bildefrekvens:	25 fps
Sensortype:	CMOS
Produktfarge:	Hvit
Vippevinkelområde:	0 - 65 °
Minnekortenhet:	MicroSD (TransFlash)
Støttede grafikkoppløsninger:	352 x 240,352 x 288,640 x 480 (VGA),704 x 480,704 x 576,1280 x 720 (HD 720),1280 x 960,1920 x 1080 (HD 1080),2304 x 1296,2560 x 1440,2688 x 1520
Analogt signalformatsystem:	PAL
Brennviddeområde:	2.7 - 12 mm
Støttede videofunksjoner:	720p, 1080p
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	-30 - 60 °C
Oppbevaringstemperaturomåde (Celsius):	-30 - 60 °C
Innebygd kortleser:	Ja
Lukkerhastighet:	1/3 - 1/100000 s
nattsyn:	Ja
IK-kode:	IK10
Beskyttelsesfunksjoner:	Dust resistant, Vandal proof, Water resistant
Formfaktor:	Kuppel
Quality of Service (QoS) støtte:	Ja
CCD-sensorstørrelse:	1/1.8 "
Modell/Type:	IP-sikkerhetskamera
Innebygd harddisk:	Nei
Panoreringsomfang:	0 - 355 °
Internasjonal beskyttelses (IP)-kode:	IP67
Flip og speil:	Ja
Bithastighetskontroll:	Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Minimumsbelysning:	0.003 lx
Ethernet/bredbåndsforbindelse:	Ja
Ethernet-grensesnittype:	Raskt Ethernet
Relativ luftfuktighet under drift (H-H):	0 - 95
Lyd-utgang kanaler:	1 kanaler
Støttede plasseringer/plasseringer som kan benyttes:	Inne & Ute
Montasjetype:	Tak/Vegg
Totale megapiksler:	4 MP
Webbasert administrasjon:	Ja
DC-ut, volt:	12
Region of Interest (ROI)-koding:	Ja
Bit-rate:	H.264: 32 - 8192Kbps; H.265: 19 - 8192Kbps
Privacy maske:	Ja
Effektiv distanse for nattsyn:	40 m
Avstandsdeteksjon (bred):	58 m
Observere aavstand (bred):	23 m
Gjenkjenne avstand (bred):	12 m
Avstandsidentifikasjon (bred):	6 m
Maksimal blenderåpning:	1.8
Panoreringskontroll:	Ja
Vippekontroll:	Ja
Intelligent Video Surveillance (IVS)-systemfunksjoner:	Abandoned object, Face detection, Intrusion, Missing object, People counting, Scene change, Tripwire
Videobasert bevegelsesdeteksjon:	Ja
Infrarød (IR) avbruddsfilter:	Ja
Baklyskompensasjon (BLC):	Ja
Alarminngang/-utgang:	Ja
Highlight Compensation (HLC):	Ja
Vinningskontrolltype (gain):	Automatisk/Manuell
Aktiv tuklealarm:	Ja
Streaming-metode:	Multicast, Unicast
Tåkesikker:	Ja
Lydkodekser:	G.711a, G.711Mu, G726, AAC, G.723
Ekstern visning:	Ja
Nærmeste fokuseringsavstand:	1.2 m
Antall lysende LED:	3
Avstandsdeteksjon (tele):	131 m
Observere avstand (tele):	52 m
Gjenkjenne avstand (tele):	26 m
Avstandsidentifikasjon (tele):	13 m
